RF-12-1
GRF1H–04–0300–1–CA1–S–02SP1
(5,00 mm) .197"
GRF1H SERIES
50Ω HYBRID MICRO-MINI RF CABLE
SPECIFICATIONS
For complete specifications see
www.samtec.com?GRF1H
Mates with:
GRF1-J, SMA,
MCX, SMB5, MMCX,
SSMB, BNC5, TNC
High performance
26 AWG RG 316
coax cable
RF Connector:
Shell Material:
Brass
Insulator Material:
PTFE
Contact Material:
BeCu
Pin Material:
Brass
Operating Temp Range:
-40°C to +90°C
Impedance:
50Ω
RoHS Compliant:
Yes
2, 4, 6 or 8
Positions
RG 316 Cable:
MMCX-Scale
Connectors
Optional Captive
Panel Screws
Impedance:
50Ω
Capacitance:
96.432 pF/meter
Propagation Delay:
4.83 nsec/meter
Max Attenuation
(cable only):
1.25dB @ 1GHz for 1 meter
Conductor Size:
26 AWG,
(0,51 mm) .020" dia.
Conductor Material:
Silver Plated Copper
Insulator Material:
PTFE
Shield Material:
Silver Plated
Copper Clad Steel
Jacket Material:
FEP
Jacket Diameter:
(2,54 mm) .100"
Jacket Color:
Amber
RoHS Compliant:
Yes
GRF1H
NO. OF
POSITIONS
ASSEMBLED
LENGTH
–“XXXX”
–02, –04, –06, –08
(6,00)
.236
(28,58) 1.125
(No. of
Positions
x
(5,00) (No. of Positions -1)
x (5,00) .197
.197)
+
(7,20)
.283
No.
Positions
x
(5,00)
.197
+
(11
(11,60)
.4
.457
(2 86)
(2,86)
.1 2
.112
(15,50)
(15,50)
.6
.610
(8
(8,89)
.35
.350
= Assembled Length in millimeters
–0100 (0100 mm) 3.94" minimum
Assembled Length = XXXX
–01SP1 END OPTION SHOWN
0
END OPTIONS
ND O
OPTIONS
–01SP1
–01SP1
= SMA,
Straight Plug
ra ght
(30µ (0,76 µm) Gold on
(30µ"
6
Center Contact, Gold Flash on Shell)
C
–01RP1
= SMA,
Right Angle Plug
(30µ" (0,76 µm) Gold on
Center Contact, Gold Flash on Shell)
–02SJ1
= MCX,
Straight Jack
(30µ" (0,76 µm) Gold on
Center Contact, Gold Flash on Shell)
END OPTIONS
–01PN1
= SMA,
Straight Panel Mount Jack
(30µ" (0,76 µm) Gold on
Center Contact, Gold Flash on Shell)
–02SP1
= MCX,
Straight Plug
(30µ" (0,76 µm) Gold on
Center Contact, Gold Flash on Shell)
Note:
Cable lengths longer than
40.00" (1 meter) are not
supported with S.I. test data.
Note:
This Series is non-standard,
non-returnable.
WWW.SAMTEC.COM
GRF1H–02–0500–1–CA1–S–01BJ1
GRF1H–04–0800–1–CA1–01SP1
Standard heat
shrink wraps
Choice of RF
connector styles
Variety of
Bulkhead Jacks
END 1
PLATING
CABLE
TYPE
SCREW
OPTION
END 2
OPTION
–1
= All Gold components
END OPTIONS
–01BJ1
= SMA,
Straight Bulkhead Jack
–01BR1
= SMA,
Straight Bulkhead Jack,
Reversed Polarity
–01SB1
= SMA,
Straight Bulkhead Jack, Sealed
–01SR1
= SMA,
Straight Bulkhead Jack, Sealed,
Reversed Polarity
(30µ" (0,76 µm) Gold on Center
Contact, Gold Flash on Shell)
–02RP1
= MCX,
Right Angle Plug
d
(30µ" (0,76 µm) Gold on Center
ntact,
Contact, Gold Flash o Shell)
on
1
–03SP1
= MMCX,
Straight Plug
" 76
(30µ" (0,76 µm) Gold on Center
ntact,
Contact, Gold Flash on Shell)
3RP1
–03RP1
= MMCX,
Right Angle Plug
30
m)
(30µ" (0,76 µm) Gold
on Center Co
Contact,
G
Gold Flash on Shell)
–S7SP4
= SSMB,
Straight Plug
(10µ" (0,25 µm) Gold on Center
Contact, Nickel on Shell)
–07BJ1
= SMB,
Straight Bulkhead Jack
(30µ" (0,76 µm) Gold on Center
Contact, Gold Flash on Shell)
–CA1
= RG 316 cable
–S
= Captive Panel Screws
(Leave blank for no Screw Option)
END OPTIONS
–04SP3
= BNC,
Straight Plug
(10µ" (0,25 µm) Gold
on Center Contact,
Nickel on Shell)
–04BJ3
= BNC,
Straight
Bulkhead Jack
(10µ" (0,25 µm) Gold
on Center Contact,
Contact,
Nickel on S
ickel
Sh
Shell)
5S
–05SP3
= TNC
TNC,
raight Plug
Straight Pl g
0,25
(10µ" (0,25 µm) G
Gold
on Center Con a
Center Contact,
ke
el
Nickel on Shell)
Shell)
–05BJ3
= TNC,
Straight
Bulkhead Jack
(10µ" (0,25 µm) Gold
on Center Contact,
Nickel on Shell)
S7RP4
= SSMB,
Right Angle Plug
(10µ" (0,25 µm) Gold
on Center Contact,
Nickel on Shell)
Specify END OPTIONS
from chart
END OPTIONS
–06BJ3
= N Type,
Straight
Bulkhead Jack
(10µ" (0,25 µm) Gold
r
on Center Contact,
ickel Shell)
Nickel on S
–07SP2
–0 P2
= SMB,
B,
Straight Plug
aight P
(30µ" (0,76 µm) Gold
30
)
d
on Center Contact,
Gold Flash on Shell)
–07RP2
= SMB,
Right Angle Plug
(30µ" (0,76 µm) Gold
on Center Contact,
Gold Flash on Shell)
–13GP1
= GRF,
Straight Plug
(30µ" (0,76 µm) Gold
on Center Contact,
Gold Flash on Shell)
–13GJ1
= GRF,
Straight Jack
(30µ" (0,76 µm) Gold
on Center Contact,
Gold Flash on Shell)
WWW.SAMTEC.COM
