ISDF-07-S-M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> ISDF-07-S-M

ISDF-07-S-M: DescriptionHeader and Wire Housing.050" Tiger Eye Discrete Wire Socket Housing; CategoryThe connector The connector; File Size130KB，2 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/

Download Datasheet Parametric View All

ISDF-07-S-M Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ISDF-07-S-M	-	-	View	Buy Now

ISDF-07-S-M Overview

Header and Wire Housing.050" Tiger Eye Discrete Wire Socket Housing

ISDF-07-S-M Parametric

Parameter Name	Attribute value
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	2 weeks
Other features	TIGER EYE CONTACT
body width	0.2 inch
subject depth	0.44 inch
body length	0.365 inch
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	GOLD OVER NICKEL (50)
Contact completed and terminated	GOLD OVER NICKEL (50)
Contact point gender	FEMALE
Contact material	BERYLLIUM COPPER
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
DIN compliance	NO
Filter function	NO
IEC compliance	NO
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e4
MIL compliance	NO
Plug contact pitch	0.05 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	1
Options	GENERAL PURPOSE
polarization key	POLARIZED HOUSING
Guideline	UL
reliability	COMMERCIAL
Total number of contacts	7
Base Number Matches	1

Preview

Download Datasheet

View All

F-219 SUPPLEMENT (Rev 12APR19)

ISDF–07–D–M

TSDF–10–D–S

CC03R–2830–01–G

T1M44-L–2830–01–G

(1.27 mm) .050"

ISDF, CC03R, CC03M, TSDF, T1M44-L, T1M44-R SERIES

DISCRETE WIRE COMPONENTS & TOOLING

SPECIFICATIONS

For complete specifications

see www.samtec.com?ISDF,

www.samtec.com?CC03R or

www.samtec.com?CC03M

Insulator Material:

Black LCP

Contact Material:

BeCu

TYPE

POSITIONS

PER ROW

ROW

OPTION

TYPE

WIRE

GAUGE

PLATING

= Housing

ISDF

RECOGNITIONS

For complete scope

of recognitions see

www.samtec.com/quality

FILE NO. E111594

(Standard sizes)

–03, –04,

–05, –07,

–10, –15,

–20, –25,

–40, –50

= Single Row

–S

= Double Row

(5.08)

.200

–D

= Metal

Retention

Latch

–M

–S

= Contact,

Full Reel

(35,000 Parts

per Reel)

CC03R

= 28 to 30 AWG

–2830

= Gold flash

on contact

–GF

–G

= Screw

Down

(–D only)

(11.18)

.440

CC03M

= Contact,

Mini Reel

(1,000-5,000

Parts per

Reel)

= 10 µ"

(0.25 µm)

Gold on

contact

TOOLING

• Hand Tool:

CAT-HT-203-2830-12

• Clamp for mounting

hand tool to work table:

CAT-HT-MNT-01

• Mini Applicator:

CAT-MC-203-2830-XX-01

• Extraction Tool:

CAT-EX-169-01

Note:

Some sizes, styles and

options are non-standard,

non-returnable.

No. of Positions

x (1.27) .050

+ (0.38) .015 (1.27)

.050

–S

(1.27)

.050

(2.03)

.080

(2.00)

.079

DIA

(3.68)

.145

(2.03) .080

(6.35)

.250

(1.27)

.050

(6.32)

.249

(0.38)

.015

(15.37)

.605

(1.27)

.050

DIA

(3.81)

.150

(1.91)

.075

(3.81)

.150

(1.78)

.070

–D

–M

–S

SPECIFICATIONS

For complete specifications

see www.samtec.com?TSDF,

www.samtec.com?T1M44-L or

www.samtec.com?T1M44-R

Insulator Material:

Black LCP

Contact Material:

BeCu

TYPE

POSITIONS

PER ROW

ROW

OPTION

TYPE

WIRE

GAUGE

PLATING

= Housing

TSDF

TOOLING

• Hand Tool:

CAT-HT-144-2830-12

• Mini Applicator

CAT-MC-144-2830-XX-01

• Extraction Tool:

CAT-EX-169-01

(Standard sizes)

No. of Positions x

(1.27) .050

+ (2.54) .100

–03, –04,

–05, –07,

–10, –15,

–20, –25,

–40, –50

(1.27)

.050

= Double Row

–D

= Contact, Loose

T1M44–L

= Contact,

Full Reel

(35,000 Parts

per Reel)

= 28 to 30 AWG

–2830

T1M44–R

= 10 µ"

(0.25 µm)

Gold on

contact

–G

(0.46) .018 DIA

(6.10)

.240

(4.83)

.190

(14.26)

.562

Note:

Some sizes, styles and

options are non-standard,

non-returnable.

(6.05)

.238

(3.81) .150

Due to technical progress, all designs, specifications and components are subject to change without notice.

All parts within this catalog are built to Samtec’s specifications.

Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.

WWW.SAMTEC.COM
