QFS-078-04.25-L-D-A-GP: DescriptionBoard-to-Board and Mezzanine Connectors 0.635 mm Q2 High-Speed Rugged Ground Plane Socket Strip; CategoryThe connector The connector; File Size1MB，2 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

QFS-078-04.25-L-D-A-GP Overview

Board-to-Board and Mezzanine Connectors 0.635 mm Q2 High-Speed Rugged Ground Plane Socket Strip

QFS-078-04.25-L-D-A-GP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Factory Lead Time	3 weeks
Other features	PICK&PLACE PAD
body width	0.32 inch
subject depth	0.293 inch
body length	3.01 inch
Body/casing type	SOCKET
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact style	CENTRONIC
Filter function	NO
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
Plug contact pitch	0.025 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	10u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	2.6 A
Guideline	UL
reliability	COMMERCIAL
Termination type	SURFACE MOUNT
Total number of contacts	156
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

F-219

QFS–026–04.25–L–D–A

QFS–026–04.25–L–D–A–GP

QFS–032–04.25–L–D–DP–A

(0.635 mm) .025"

QFS SERIES

RUGGED GROUND PLANE SOCKET

SPECIFICATIONS

For complete specifications and

recommended PCB layouts see

www.samtec.com?QFS

Insulator Material:

Liquid Crystal Polymer

Contact & Ground

Plane Material:

Phosphor Bronze

Plating:

Au over 50 µ" (1.27 µm) Ni

(Tin on Ground Plane Tail)

Current Rating:

Contact:

2.6 A per pin

(2 pins powered)

Ground Plane:

15.7 A per ground plane

(1 ground plane powered)

Voltage Rating:

300 VAC mated with QMS

Operating Temp:

-55 °C to +125 °C

RoHS Compliant:

Yes

Board Mates:

QMS

Cable Mates:

6QCD

Standoffs:

SO, JSOM

Increased insertion

depth for rugged applications

Integral metal plane

for power or ground

(1.60 mm)

.063"

NOMINAL

WIPE

POWER/SIGNAL

APPLICATION

ALSO

AVAILABLE

(MOQ Required)

HIGH-SPEED CHANNEL PERFORMANCE

Compatible with

UMPT/UMPS for flexible

two-piece power/signal solutions

QMS-DP/QFS-DP @ 10 mm Mated Stack Height

Rating based on Samtec reference channel.

For full SI performance data visit Samtec.com

or contact SIG@samtec.com

PROCESSING

Lead–Free Solderable:

Yes

SMT Lead Coplanarity:

(0.10 mm) .004" max (026-078)

Board Stacking:

For applications requiring more

than two connectors per board

contact ipg@samtec.com

G b p s

• Other platings

• Without PCB

Alignment Pins

• Hot Pluggable

• 4 banks

(104 -SE, 64 -DP)

QFS

PINS PER ROW

NO. OF PAIRS

LEAD

STYLE

Specify

LEAD

STYLE

from

chart

PLATING

OPTION

TYPE

OTHER

OPTION

RECOGNITIONS

For complete scope of

recognitions see

www.samtec.com/quality

FILE NO. E111594

(52 total pins per bank = –D)

–026, –052, –078

–016, –032, –048

(16 pairs per bank = –D–DP)

(–04.25 lead style only)

= 10 µ" (0.25 µm) Gold on Signal

Pins and Ground Plane

(Tin on Signal Pin tails, and

Ground Plane tails)

–L

= Single-Ended

–D

= Differential Pair

(–04.25 lead style only)

–D–DP

= Guide

Holes

( –04.25

lead style

only)

–GP

GP = No. of Banks x (21.34) .840 + (12.45) .490

No. of Banks x (21.34) .840 + (1.02) .040

(0.635)

(21.34) .840

.025

(8.13)

.320

STANDARDS

• SUMIT

™

• PCI/104-Express

™

• PCI/104-Express

™

OneBank

Visit www.samtec.com/standards

for more information.

(–06.25 lead style only)

= 10 µ" (0.25 µm) Gold on Signal

Pins and Ground Plane

(Tin on Signal Pin tails, and

Ground Plane tails)

–SL

APPLICATION

STACK

HEIGHT

(0.10)

.004

(0.44)

.017

(0.89)

.035

–D

(1.02) .040 DIA

–D–DP

(8.13)

.320

Requires Standoff

SO-1524-03-01-01-L or

JSOM-1524-02 for 15.24 mm

or SO-2215-02-01-01-L for 22 mm

board spacing. Connectors designed

to not fully seat when mated.

MATED HEIGHT*

LEAD

STYLE

(7.44) .293

(9.42) .371

QMS LEAD STYLE

INDUSTRY

STANDARD

SUMIT

™

PCI/104-Express

™

PCI/104-Express

™

PCI/104-Express

™

PCI/104-Express

™

PCI/104-Express

™

INTERCONNECTS

TERMINAL

ASP-129637-01

ASP-129637-03

ASP-129637-13

ASP-142781-01

ASP-142781-02

ASP-142781-03

SOCKET

ASP-129646-01

ASP-129646-03

ASP-129646-22

ASP-129646-01

ASP-129646-02

ASP-129646-03

–05.75 –06.75 –09.75

10 mm

12 mm

11 mm

13 mm

14 mm

16 mm

STACK

BANKS HEIGHT

15.24 mm

22 mm

–04.25

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

–06.25

*Processing conditions will affect mated height.

See SO Series for board space tolerances.

Due to technical progress, all designs, specifications and components are subject to change without notice.

All parts within this catalog are built to Samtec’s specifications.

Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.

WWW.SAMTEC.COM

Mouser Electronics

Authorized Distributor

Click to View Pricing, Inventory, Delivery & Lifecycle Information:

Samtec

QFS-026-04.25-L-D-A QFS-026-04.25-H-D-A QFS-052-01-SL-D-RA QFS-026-04.25-L-D-RF1 QFS-078-04.25-L-D-

PT4 QFS-026-04.25-L-D-A-RT1 QFS-052-01-SL-D-EM2 QFS-078-02-SL-D-RA QFS-026-06.25-SL-D-A QFS-078-

06.25-SL-D-A QFS-026-01-SL-D-RA QFS-016-04.25-L-D-DP-A QFS-026-04.25-L-D-PT4 QFS-026-04.25-L-D-A-P-TR

QFS-078-01-SL-D-RA QFS-026-04.25-L-D-A-GP QFS-026-04.25-L-D QFS-052-06.25-SL-D-A QFS-052-04.25-L-D-

A-GP QFS-078-04.25-L-D-A QFS-026-04.25-L-D-PC4 QFS-052-04.25-L-D-A QFS-052-04.25-L-D-A-GP-P-TR QFS-

032-04.25-L-D-DP-A QFS-052-04.25-H-D-A-P QFS-052-04.25-L-D-PT4 QFS-078-04.25-L-D-PC4 QFS-078-04.25-L-

D-A-GP QFS-052-04.25-L-D-PC4 QFS-016-04.25-L-D-DP-PC4 QFS-104-01-SL-D-RA QFS-052-01-S-D-EM2 QFS-

032-01-SL-D-DP-RA QFS-104-02-S-D-RA-K QFS-052-04.25-H-D QFS-016-01-L-D-DP-RA QFS-016-04.25-L-D-DP-

PC8 QFS-026-04.25-H-D-A-RT1 QFS-026-04.25-L-D-PT8 QFS-032-04.25-L-D-DP-PC4 QFS-032-04.25-L-D-DP-PC8

QFS-048-01-SL-D-DP-RA QFS-052-01-SL-D-RA-PC4 QFS-052-04.25-L-D-A-TR QFS-104-01-S-D-RA-K QFS-104-

04.25-H-D-A-GP QFS-016-04.25-L-D-DP-A-GP QFS-032-04.25-L-D-DP-A-P QFS-048-01-SL-D-DP-RA-K QFS-052-

01-SL-D-EM2-TR QFS-052-01-SL-D-RA-K-TR QFS-052-04.25-H-D-PC4 QFS-064-01-SL-D-DP-RA-K QFS-016-01-S-

D-DP-RA QFS-016-02-SL-D-DP-RA-K QFS-026-01-SL-D-EM2 QFS-026-01-SL-D-RA-K QFS-026-04.25-L-D-A-P

QFS-032-04.25-H-D-DP-A-RT1 QFS-048-04.25-L-D-DP-PC4 QFS-052-01-S-D-RA QFS-052-01-S-D-RA-PC4 QFS-

052-04.25-H-D-RF1 QFS-052-06.25-SL-D-A-P-TR QFS-078-01-SL-D-RA-PC8 QFS-078-04.25-L-D-RF2 QFS-016-

04.25-L-D-DP-A-P QFS-026-01-S-D-EM2 QFS-026-01-SL-D-RA-PC8 QFS-026-04.25-L-D-PC8 QFS-026-04.25-L-D-

RF1-TR QFS-032-04.25-L-D-DP-PT4 QFS-052-01-SL-D-RA-PC4-K QFS-052-04.25-L-D-P QFS-052-04.25-L-D-PC4-

P QFS-064-04.25-L-D-DP-A-P QFS-078-01-S-D-EM2 QFS-078-04.25-L-D-A-GP-P QFS-078-04.25-L-D-A-P QFS-

078-04.25-L-D-A-P-TR QFS-104-01-SL-D-EM2 QFS-104-01-SL-D-RA-K QFS-016-01-S-D-DP-RA-PC4 QFS-016-01-

SL-D-DP-RA-K QFS-032-04.25-H-D-DP-PC4 QFS-078-01-SL-D-RA-PC4 QFS-078-04.25-H-D-A QFS-078-04.25-H-D-

A-GP QFS-078-04.25-L-D-PT8 QFS-078-04.25-L-D-RF1 QFS-078-06.25-S-D-A QFS-026-04.25-H-D-PC4 QFS-026-

04.25-H-D-PC8 QFS-026-04.25-H-D-RF2 QFS-026-04.25-L-D-RF2-P QFS-032-04.25-L-D-DP-A-TR QFS-052-04.25-

L-D-A-P-TR QFS-052-04.25-L-D-RF2 QFS-078-01-S-D-RA-K QFS-078-04.25-H-D-PC4
