RF-18
IP5–04–01–L–S–RA1–TR
IP5–04–05.0–L–S–1–TR
IP5–08–05.0–L–S–1–TR
(4.00 mm) .1575"
IP5, IP5-RA SERIES
50
W
HIGH ISOLATION RF PLUGS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?IP5
Shell Material:
Copper Alloy
Insulator Material:
Black LCP
Contact Material:
Copper Alloy
Dielectric Material:
Black LCP
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (Vertical):
Signals: 2.36 A per pin
(2 adjacent pins powered)
Grounds: 4.4 A per pin
(2 adjacent pins powered)
Operating Temp Range:
-55 °C to +125 °C
Dielectric Withstanding
Voltage:
IP5 = 600 VAC
IP5-RA = 190 VAC
Working Voltage:
IP5 = 200 VAC
IP5-RA = 190 VAC
RoHS Compliant:
Yes
IP5
Mates with:
IJ5, IJ5C
PLUGS
PER ROW
05.0
PLATING
ROW
OPTION
TAIL
OPTION
TR
–TR
= Tape
& Reel
–01,
–02, –04,
–06, –08
Frequency
= 10 µ" (0.25 µm)
Gold on contact area,
Matte Tin on tail
–L
= Single Row
–S
= Double Row
(Not available
with –01)
A
–D
= (1.60 mm)
.062"
board
thickness
–1
= Cable
Latch
(Single
Row only)
NO. OF
PLUGS
–01
–02
(12.52)
.493
–L
A
(8.33)
.328
(12.32)
.485
(20.32)
.800
(28.32)
1.115
(36.32)
1.430
IP5/IJ5
10 mm Stack Height
Insertion Loss = 3 dB 10.5 GHz / 21.0 Gbps
Return Loss = 15 dB 5.5 GHz / 11.0 Gbps
Isolation = 60 dB
8.8 GHz / 17.6 Gbps
Isolation = 70 dB
7.6 GHz / 15.2 Gbps
Isolation = 80 dB
1.3 GHz / 2.6 Gbps
Complete test data available
at www.samtec.com?IP5
or contact sig@samtec.com
(8.53)
.336
(4.00) .1575
(1.52) .060
–04
–06
–08
(9.09)
.358
(1.52) .060
PROCESSING
Lead–Free Solderable:
Yes
–S
–D
(4.00).1575
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
IP5
Mates with:
IJ5, IJ5C
PLUGS
PER ROW
01
PLATING
S
TAIL
OPTION
OPTION
TR
–TR
= Tape
& Reel
FILE NO. E111594
ALSO AVAILABLE
(MOQ Required)
• Other stack heights
• Other PCB thicknesses
Contact Samtec.
–02, –04,
–06, –08
A
= 10 µ" (0.25 µm)
Gold on contact area,
Matte Tin on grounds,
tails & weld tabs
NO. OF PLUGS
–02
–04
–06
–08
A
B
–L
= (1.60 mm)
.062"
board
thickness
–RA1
(Leave blank
for no Cable
Latch)
= Cable Latch
–L
C
(15.64) .616 (13.27) .523 (12.32) .485
(23.64) .931 (21.27) .838 (20.32) .800
(31.64) 1.246 (29.27) 1.153 (28.32) 1.115
(39.64) 1.561 (37.27) 1.468 (36.32) 1.430
APPLICATION
IJ5
C
(4.00) .1575
(8.92)
.351
(14.72) .580
(12.52) .493
10 mm
(1.52)
.060
B
(8.34)
.328
(9.72) .383
–RA1 SHOWN
(0.64) .025
(4.76) .188
IP5
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
