F-219
JW–13–04–T–S–550–150
FWJ–08–01–T–S
FWJ–05–02–T–S–RA
(3.96 mm) .156"
FWJ, HFWJ, JW SERIES
POWER HEADERS & BOARD STACKERS
Mates with:
FHP
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?FWJ,
www.samtec.com?HFWJ or
www.samtec.com?JW
Insulator Material:
FWJ = Black Glass
Filled Polyester
HFWJ, JW = Natural Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C
Voltage Rating:
600 VAC/845 VDC
Standard Creepage:
FWJ: (2.82 mm) .111"
HFWJ, JW: (3.92 mm) .154"
Standard Clearance:
(2.82 mm) .111
RoHS Compliant:
Yes
TYPE
STRIP
NO. OF
PINS
LEAD
STYLE
PLATING
OPTION
S
OTHER
OPTION
= Standard
Header
FWJ
PINS
1
2
3
4
24
= High Temp
Header
HFWJ
FHP/HFWJ
CURRENT RATING
(PER CONTACT)
13.1 A
11.2 A
10.3 A
9.2 A
6.7 A
= Matte Tin
–T
Leave
blank for
Through-hole
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
Specify LEAD STYLE
from chart below.
(0.51)
.020
= Right-angle
(Style –02 &
–04 only)
–RA
–VS
A
(6.35)
.250
C
(2.54)
.100
(1.02) .040
E
F
D
01 thru 24
(1.14) .045
SQ TYP
(3.96)
.156
TYP
B
LEAD
STYLE
A
(11.43)
.450
(12.70)
.500
(20.55)
.809
(3.81)
.150
B
(4.45)
.175
(3.96)
.156
(12.07)
.475
C
(10.46)
.412
(11.73)
.462
(19.10)
.752
––––––
D
––––––
(4.45)
.175
(3.96)
.156
––––––
E
––––––
(8.13)
.320
(13.56)
.534
––––––
F
––––––
(2.54)
.100
(4.95)
.195
––––––
= Surface Mount
Requires HFWJ
(2 pins/row
minimum)
Style –05
not available.
PROCESSING
Lead–Free Solderable:
FWJ = Wave only
HFWJ, JW = Yes
SMT Lead Coplanarity:
(0.20 mm) .008" max (02-16)*
(0.25 mm) .010" max (17-24)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
(3.18)
.125
–01
–02
–04
*
No. of Positions x (3.96) .156
–05
*FWJ Only
= Pick & Place
Pad (3 Pos. min.)
(6.98 mm) .275"
min. post height
(–VS only)
–P
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
JW
NO. OF
PINS
04
PLATING
OPTION
S
STACK
HEIGHT
POST
HEIGHT
OTHER
OPTION
Leave
blank for
Through-hole
CREEPAGE
AND CLEARANCE
Note:
This Series is
non-standard,
non-returnable.
= Matte Tin
–T
= Stacker Height
(in inches) (0.13 mm) .005" increments
Example: –250 = (6.35 mm) .250"
–“XXX”
02 thru 24
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
(3.96)
.156
TYP
POST
HEIGHT
(0.00)
.000
MIN
STACK
HEIGHT
(29.21) 1.15
MAX WITH
(0.00) .000 POST
(8.89) .350
MIN
STACK
HEIGHT
(27.43)
1.08 MAX
(6.35)
.250 MIN
= Post Height
(in inches)
–“XXX”
= Surface
Mount
(2 pins/row
minimum)
–VS
(31.75)
1.25
MAX
(3.18)
.125
(2.29)
.090
(1.14) .045 SQ
= Pick &
Place Pad
(3 Pos. min.)
(6.98 mm)
.275" min.
post height
(–VS only)
–P
