Optimized for harsh environments in industrial/railway applications, the IRH
DC-DC converter series offer regulated outputs in an industry-standard half
brick fully encased package.
FEATURES
DC input range: 57.6-160V
(Covers 96V and 110V input range)
Encapsulated circuitry for optimal thermal/vibration
performance
Meet requirements of EN50155
Size: 61.0mm X 57.9mm X 12.7mm (2.4” X 2.28”
X 0.5”)
Industry standard pinout options
5 sided metal shielding for improved EMI
performance
Fixed Frequency operation, simplifies input filter
design
Hiccup output over current protection (OCP)
Latch mode output over voltage protection (OVP)
Over Temperature Protection (OTP)
No Minimum Load Required
Tested to EN61373 for Mechanical Shock and
vibration
Meets EN60068 Damp Heat & Dry Heat
requirements
Extensive reliability qualification, see Page 24 for
details
PRODUCT OVERVIEW
The IRH series delivers the latest technology
in fixed frequency power conversion
designed for Industrial/railway applications.
The IRH series delivers 5V, 12V or 24Vout
from an input voltage range of 57.6V – 160V
with reinforced I/O galvanic I/O isolation
rated at 3,000Vrms. The Half Brick, industry
standard packaging offers options for
electrical connections & mounting for
thermal management in your latest system
designs.
The IRH series is designed for the highest
reliability, incorporating the latest circuit
technologies along with proprietary
packaging & thermal management
techniques to deliver a product that meets
critical environmental requirements for
Industrial & Railway applications. The
modules incorporate many features to protect
the power module from fault conditions and
also expensive end use equipment.
Protection features include input under
voltage lockout, output overvoltage
protection, output current limit, short circuit
(hiccup mode) and over temperature
shutdown.
Available options include various pin lengths,
pin functions and baseplate cooling options.
SAFETY FEATURES
Reinforced insulation
3000Vrms input to output isolation
UL 60950-1, 2
nd
Edition
CAN/CSA-C22.2 No. 60950-1
EN 60950-1
RoHS compliant
Slotted / Flanged Baseplate
“V” Option Pins / Pinout
Pin Diameter: 0.080/ 0.15
Slotted / Flanged Baseplate
DOSA Pins / Pinout
Pin Diameter: 0.040 / 0.080
Standard Baseplate
DOSA Pins / Pinout
Pin Diameter: 0.040 / 0.080
For full details go to
ww w.murata-ps.com/rohs
www.murata-ps.com/support
SDC_IRH_A04
Page 1
of
30
IRH Series
Encapsulated 150-Watt Isolated DC-DC Converter
PERFORMANCE SPECIFICATIONS SUMMARY AND ORDERING GUIDE
① ②
Output
Root Model
①
VOUT IOUT
(V) (A, max)
Total
Power
(W)
150
150
150
Ripple & Noise
(mVp-p)
Typ.
IRH-5/30-T110
IRH-12/12.5-T110
IRH-24/6.3-T110
5
12
24
30
12.5
6.25
60
100
100
Max.
100
160
240
Input
Efficiency
Regulation (max.)
VIN Nom.
(V)
Range
(V)
IIN, no load
(mA)
IIN, full load
(A)
Min.
110
110
110
57.6-160
57.6-160
57.6-160
60
60
60
2.92
3
3
89.0%
87.0%
88.0%
Typ.
91.0%
89.5%
89.0%
Line
±0.2%
±0.5%
±0.2%
Load
±0.3%
±0.5%
±0.3%
①
Please refer to the part number structure for additional options and complete ordering part numbers.
②
All specifications are at nominal line voltage and full load, +25 ºC. Unless otherwise noted. See detailed specifications. Output capacitors are 1 μF ceramic in parallel with 10 μF
electrolytic. I/O caps are necessary for our test equipment and may not be needed for your application.
Part Number Structure
IR H
-
Vout
/
Iout
-
Input Voltage N V
Industrial-Railway
F
-
C
RoHS 6 Compliant
Package/Cooling Configuration
F = Slotted/Flanged Baseplate
Blank = Standard Baseplate
(only available for Pin option #2)
Please see mechanical drawings for details
H = Half-Brick
Nominal OutputVoltage
Voltage in Volts (V)
Maximum Rated Output Currrent
Current in Amps (A)
InputVoltage Range
T110
= 57.6V-160V (110V Nominal)
Pin Options
V (option #1)
= V Optinal Pins/Pinout
Blank (option #2) = Optinal DOSA Pins/Pinout
Please see mechanical drawings for details
N= Negative Logic (Standard Configuration for Pin option #2)
P= Positive Logic (Standard Configuration for Pin option #1)
Examples:
IRH-5/30-T110N-C
stands for Industrial Railway Half Brick, 5Vout @ 30A, 57.6V – 160Vin, Negative Logic, Option #2 Pin Option, Standard
Baseplate, RoHS Compliant
IRH-5/30-T110PVF-C
stands for Industrial Railway Half Brick, 5Vout @ 30A, 57.6V – 160Vin, Positive Logic, V pin option with Slotted/Flanged
Baseplate, RoHS Compliant
Note: Special order applies to Positive Logic version. Some model number combinations may not be available. See website or contact your local
Murata sales representative.
www.murata-ps.com/support
SDC_IRH.A04
Page
2
of
30
IRH Series
Encapsulated 150-Watt Isolated DC-DC Converter
IRH SERIES FUNCTIONAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Input Voltage, Continuous
Input Voltage, Transient
100 mS max. duration
Input to output
Isolation Voltage(Test voltage)
Input to Baseplate
Output to Baseplate
On/Off Remote Control
Operating Temperature Range
Storage Temperature Range
Absolute Baseplate Temperature
Referred to -Vin
Ambient Temperature
Baseplate Temperature
-0.1
-40
-55
Conditions
Minimum
0
Typical/Nominal
Maximum
160
170
3000
1500
1500
15
85
125
100
Units
Vdc
Vdc
Vrms
Vrms
Vrms
Vdc
°C
°C
°C
Absolute maximums are stress ratings. Exposure of devices to greater than any of these conditions may adversely affect long-term reliability. Proper operation under conditions other
than those listed in the Performance/Functional Specifications Table is not implied nor recommended.
INPUT
Operating Input Voltage Range
Turn-on Voltage Threshold
Turn-off Voltage Threshold
57.6
52
50
54.5
52
160
57
56
Vdc
Vdc
Vdc
FEATURES and OPTIONS
Conditions
Minimum
Typical/Nominal
Maximum
Units
Primary On/Off control (designed to be driving with an open collector logic, Voltages referenced to -Vin)
“P” suffix: Standard on the V Option #1, V Option Pins/Pinout
Positive Logic, ON state
Positive Logic, OFF state
Control Current
ON = pin open or external voltage
OFF = ground pin or external voltage
open collector/drain
3.5
0
1
15
1
2
V
V
mA
“N” suffix: Standard on the Option #2, DOSA Pin Option
