Features
Regulated
Converters
●
●
●
●
●
●
●
●
●
Compact AC-DC Power Supply
15 Watt PCB Mount Package
Universal Input Voltage Range
4000VAC Isolation
Low Output Ripple and Noise
Short Circuit Protected
Triple Output with Independent Outputs
UL-60601 Certified for Medical Applications
CE Marked
POWERLINE
AC/DC-Converter
with 3 year Warranty
Description
Selection Guide
Part
Number
RAC15-3.3SB
RAC15-05SB
RAC15-09SB
RAC15-12SB
RAC15-15SB
RAC15-24SB
Compact switching power module for PCB or DIN-rail mounting with medical certification
UL-60601-1.
Input
Range
(VAC)
90-264
90-264
90-264
90-264
90-264
90-264
90-264
90-264
90-264
90-264
90-264
Output
Voltage
(VDC)
3.3
5
9
Output
Current
(mA)
3000
3000
1666
Efficiency
(%)
75
79
80
Max.
Capacitive
Load
40000µF
10000µF
3000µF
1100µF
1000µF
820µF
±4700µF
±560µF
±500µF
10000/±470µF
10000/±600µF
15 Watt
Single/Dual
&
Triple
Output
RAC15-05DB
RAC15-12DB
RAC15-15DB
NOT RECOMMENDED
FOR
NEW DESIGNS
12
15
24
1250
1000
625
81
82
83
±5
±1500
±625
±500
+2000/±200
+2000/±150
79
±12
±15
5/±12
5/±15
82
82
78
78
RAC15-0512TB
RAC15-0515TB
2002/95/EC
6/6
RoHS
E314885
*add suffix “-E” for extended temperature range, e.g. RAC15-05SB-E
*add suffix "-ST” for screw terminal module e.g. RAC15-05SB-ST, RAC15-05DB-ST, RAC15-0512TB-ST
UL-60601-1 Certified
RAC15-B
Specifications
(typical at 25°C and after warm up time unless otherwise specified )
Input Voltage Range
Rated Power
Input Frequency Range (for AC Input)
Input Current (full load)
115VAC/230VAC
No Load Power Consumption
115VAC/230VAC
Inrush Current (<2ms)
115VAC/230VAC
Leakage Current
115VAC/230VAC
Output Voltage Accuracy (Full load)
(Note 5)
Line Voltage Regulation (low line, high line at full load) Single&Dual
See Note 1
Triple
Load Voltage Regulation (10% to 100% symmetric load) Single&Dual
See Note 2
Triple
Output Ripple and Noise - See Note 3
Operating Frequency
Efficiency at Full Load
RMS Isolation Voltage (input to output)
Temperature Coefficient
Over-Current Protection
Short Circuit Protection
Over-Voltage Protection
Over-Temperature Protection
Operating Temperature Range
Standard
(free air convection, with derating)
Suffix -E
Storage Temperature Range
90-264VAC or 100-370VDC
15 Watts max.
47-440Hz
220mA / 118mA max.
590mW max.
10A / 20A max.
100µA/ 200µA max.
Single and Dual ±2% max.
Triple ±2% / ±3% max.
±0.5% max.
±2% / ±3% max.
±1% max.
1% / 5% max.
1% Vout max.
132kHz typ.
see table
4kVAC / 1minute
±0.01%/°C typ.
105% typ.
Hiccup, Automatic Restart
Zener Diode Clamp
100°C
-25°C to +70°C
-40°C to +70°C
-40°C to +100°C
continued on next page
REV: 0/2012
RAC15-B
Derating Graph
(Ambient Temperature)
125
100
Output Power (%)
75
50
25
0
-40 -25 -10 0
60 70 80 90
E-Version
Natural Convection
50
Ambient Temperature Range (°C)
Please Read Application Notes
PA-22
www.recom-electronic.com
POWERLINE
AC/DC-Converter
Specifications
continued
Case Material
Package Weight
Packing Quantity
EMC
MTBF (+25°C)
using MIL-HDBK-217F
RAC15-S_D_TB
Series
Epoxy with Fibreglass (UL94V-0)
120g
5 pcs (-ST Version: 1 pc)
EN 55011 Class B / EN60601-1-2
200~400 x 10
3
hours
Screw Terminal Module Option (suffix -ST)
29.0
5.5
Removable DIN-Rail
Mounting Bracket
3rd angle
projection
Pin Connections
dia.3.5 x 4
4
5
6
7
8
46.0
53.9
Pin #
1
2
3
4
5
6
7
Single Out
NC
VAC in (L)
VAC in (N)
NC
-VDC Out
NC
+VDC out
NC
Dual Out
NC
VAC in (L)
VAC in (N)
NC
-VDC Out
Com
+VDC out
NC
Triple Out
NC
VAC in (L)
VAC in (N)
+5V Ret.
+5V Out
-VDC out
Com
+VDC out
1
2
3
Fuse
RAC15-xxS_D_TB
86.1
96.0
8
NC = No Connection
RAC15-B
Package Style and Pinning
64.00
23.50
6.00
54.00
1.0
Pin Connections
Pin #
1
Single Out
VAC in (L)
VAC in (N)
-VDC out
No Pin
No Pin
+VDC out
No Pin
No Pin
Dual Out
VAC in (L)
VAC in (N)
-VDC out
Com
No Pin
+VDC out
No Pin
No Pin
Triple Out
VAC in (L)
VAC in (N)
+5V Ret.
+5V out
-VDC out
No Pin
Vout Com
+VDC out
45.60
3rd angle
projection
4.0
22.50
17.5
2
6.0
8
7
6
5
Bottom View
4
3
2
3
4
1
7.5
17.5
10.0 12.5
10.0
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
5
6
7
8
Notes
Note 1: Line Regulation = 2% max. for triple output +Vout and -Vout.
Note 2: Load Regulation = 5% max. for triple output +Vout and -Vout.
Note 3: Ripple & Noise measured with 20MHz BW probe and 0.1µF + 47µF capacitors in parallel across the outputs.
Note 4: Suggested input fuse rating = 2A Slow Blow
Note 5: Triple output version has +/-Vout common that is not connected to +5V Return pin internally.
www.recom-international.com
REV:0/2012
PA-23
