The RAC10-K/277 series are multipurpose 10 watt AC/DC power supplies for an extended mains input
from 80VAC up to 305VAC. These modules are designed to power on-board applications in automa-
tion, Industry 4.0, IoT, lighting and smart buildings worldwide. The efficiency is constant over a wide
load range and the standby power consumption is less than 0.3W. With universal input voltage cover-
ing 100/115/230/277VAC or 113-430VDC, fully protected single or dual outputs and EMC Class B
emissions compliance without any external components, these are one of the easiest to use modular
power solutions in the industry.
Selection Guide
Part
Number
RAC10-3.3SC/277
RAC10-05SC/277
RAC10-12SC/277
RAC10-15SC/277
RAC10-24SC/277
RAC10-05DC/277
RAC10-12DC/277
RAC10-15DC/277
Input
Voltage Range
[VAC]
80-305
80-305
80-305
80-305
80-305
80-305
80-305
80-305
Output
Voltage
[VDC]
3.3
5
12
15
24
±5
±12
±15
Output
Current
[mA]
2500
2000
840
670
420
±1000
±420
±340
Efficiency
typ
(1)
[%]
75
78
80
78
80
77
79
79
Max. Capacitive
Load
(2)
[µF]
50000
36000
8600
6000
2700
±21000
±3700
±2900
Notes:
Note1: Measured @ 230VAC / 50Hz / Ta=25°C with constant resistant mode at full load
Note2: If used @ 115VAC / 60Hz with full load, max. capacitive load is less, please contact
RECOM Tech Support for detailed information
E224736
IEC/EN60950-1 certified
UL60950-1 certified
CAN/CSA-22.2 No. 60950-1-07 certified
EN55032 compliant
EN55024 compliant
Model Numbering
RAC10-__ C/277
nom. Output Power
Output Voltage
Single
or
Dual
Ordering Examples:
RAC10-05SC/277
10 Watt
RAC10-12DC/277 10 Watt
5Vout
12Vout
Single Output
Dual Output
www.recom-power.com
REV.: 4/2018
PA-1
RAC10-C/277
AC/DC Converter
Specifications
(measured @ Ta= 25°C, full load and after warm-up unless otherwise stated)
BASIC CHARACTERISTICS
Parameter
Input Voltage Range
(3,4)
Input Current
Inrush Current
No load Power Consumption
Input Frequency Range
Minimum Load
Hold-up Time
Internal Operating Frequency
Output Ripple and Noise
(5)
Notes:
Note3:
Note4:
Note5:
230VAC/50Hz
full load at nominal Vin
20MHz BW
3.3, 5Vout
12, 15, 24, ±12Vout
±5, ±15Vout
115VAC
230VAC
cold start at +25°C
230VAC
AC Input
47Hz
0%
60ms
100kHz
50mVp-p
125mVp-p
200mVp-p
115VAC
230VAC
Series
Condition
Min.
80VAC
113VDC
Typ.
277VAC
250mA
160mA
Max.
305VAC
430VDC
15A
30A
300mW
63Hz
The products were submitted for safety files at AC-Input operation
Refer to line derating graph on page PA-4
Ripple and Noise is the maximum peak-to-peak voltage value measured at the output with a 20MHz bandwidth, at rated line voltage
at full load and with a 0.1µF ceramic capacitor across output. Do not use scope ground lead to measure the output ripple and noise
Efficiency vs. Load
Single
100
90
80
100
90
80
Dual
Efficiency [%]
60
50
40
30
20
10
0
0
10
20
30
40
50
60
70
3.3Vout
5Vout
15Vout
12Vout
24Vout
80
90
100
Efficiency [%]
70
70
60
50
40
30
20
10
0
0
10
20
30
40
50
60
70
80
5Vout
15Vout
12Vout
90
100
Output Load [%]
Output Load [%]
REGULATIONS
Parameter
Output Accuracy
Line Regulation
Load Regulation
www.recom-power.com
Condition
3.3Vout
all others
low line to high line, full load
0% to 100% load
REV.: 4/2018
Value
±3.0% typ.
±2.0% typ.
±0.3% typ.
1.5% typ.
1.0% typ.
0.5% typ.
PA-2
3.3, 5Vout
12Vout
all others
RAC10-C/277
AC/DC Converter
Specifications
(measured @ Ta= 25°C, full load and after warm-up unless otherwise stated)
Deviation vs. Load
Single
2
1.5
1
2
1.5
1
Series
Dual
Deviation [%]
0.5
0
-0-5
-1
-1.5
-2
0
10
3.3Vout
5Vout
12Vout
24Vout
20
30
40
50
60
70
80
90
100
Deviation [%]
0.5
0
-0-5
-1
-1.5
-2
0
10
±5Vout
±12Vout
±15Vout
20
30
40
50
60
70
80
90
100
Output Load [%]
Output Load [%]
PROTECTIONS
Parameter
Short Circuit Protection (SCP)
Over Voltage Protection (OVP)
Over Current Protection (OCP)
Over Voltage Category
Isolation Voltage
Leakage Current
Notes:
Note6:
I/P to O/P
tested for 1 minute
Type
below 100mW
Value
Hiccup mode, automatic recovery
Latch off
automatic recovery
OVCII
3.75kVAC
230VAC/50Hz
0.25mA max.
Refer to local safety regulations if input over-current protection is also required. Recommended fuse: slow blow type
ENVIRONMENTAL
Parameter
Operating Temperature Range
Operating Humidity
MTBF
Condition
@ free air convection
non-condensing
according to MIL-HDBK-217F, G.B.
continued on next page
+25°C
+70°C
full load
Value
-20°C to +70°C
5% - 95% RH max.
320 x 10
3
hours
120 x 10
3
hours
www.recom-power.com
REV.: 4/2018
PA-3
RAC10-C/277
AC/DC Converter
Specifications
(measured @ Ta= 25°C, full load and after warm-up unless otherwise stated)
Derating Graph
(@ Chamber and free air convection)
100
90
80
100
90
80
75
70
60
50
40
30
20
10
-10
0
10
20
30
40
60
70
80
0
80
90
305
Series
Line Derating
Output Load [%]
60
50
40
30
20
10
0
-20
Ambient Temperature [°C]
Output Load [%]
70
Input Voltage [VAC]
SAFETY AND CERTIFICATIONS
Certificate Type (Safety)
Information Technology Equipment, General Requirements for Safety
Information Technology Equipment, General Requirements for Safety
EAC Safety of Low Voltage Equipment
RoHS2+
Report / File Number
E224736-A49-UL
SPCLVD1605077-05
RU-AT.49.09571
Standard
UL60950-1, 2nd Edition, 2011
CAN/CSA-C22.2 60950-1, 2nd Edition, 2011
EN60950-1:2006 + A2:2013
IEC60950-1:2005, 2nd Edition + A2:2013
TP TC 004/2011
RoHS-2011/65/EU + AM-2015/863
EMC Compliance
Electromagnetic compatibility of multimedia equipment – Emission Requirements
Information technology equipment - Immunity characteristics - Limits and methods
of measurement
ESD Electrostatic discharge immunity test
Radiated, radio-frequency, electromagnetic field immunity test
Fast Transient and Burst Immunity
Surge Immunity
Immunity to conducted disturbances, induced by radio-frequency fields
Power Magnetic Field Immunity
Voltage Dips and Interruptions
Limits of Voltage Fluctuations & Flicker
Condition
Standard / Criterion
EN55032:2015, Class B
EN55024:2010
±8kV Air, ±4kV Contact
3V/m
AC Power Port: +/-1.0kV
AC Power Port: L-N +/-1.0kV
AC Power Port 3V
50Hz, 1A/m
Voltage Dips >95%
Voltage Dips 30%
Voltage Interruptions >95%
EN61000-4-2:2009, Criteria B
EN61000-4-3:2006 + A2:2010, Criteria A
IEC61000-4-4:2004+A1:2010, Criteria A
IEC61000-4-5:2005, Criteria A
IEC61000-4-6:2008, Criteria A
EN61000-4-8:2010, Criteria A
EN61000-4-11:2004, Criteria A
EN61000-4-11:2004, Criteria A
EN61000-4-11:2004, Criteria B
EN61000-3-3:2013
DIMENSION AND PHYSICAL CHARACTERISTICS
Parameter
Material
Dimension (LxWxH)
Weight
continued on next page
www.recom-power.com
REV.: 4/2018
PA-4
Type
case
Value
epoxy with fibreglass, (UL94V-0)
52.5 x 27.4 x 23.5mm
62g typ.
RAC10-C/277
AC/DC Converter
Specifications
(measured @ Ta= 25°C, full load and after warm-up unless otherwise stated)
Dimension Drawing (mm)
Series
embossed logo
52.5
27.4
Pin Connections
Pin #
Single
1
VAC in (N)
2
VAC in (L)
3
no pin
4
-VDC out
5
+VDC out
Tolerance: xx.x= ±0.5mm
xx.xx= ±0.25mm
Dual
VAC in (N)
VAC in (L)
-VDC out
Com
+VDC out
6.0
Ø1.0
±0.1
23.5
Recommended Footprint Details
45.75
3
3.3
2.54
10.16
13.7
10.16
Bottom View
4
2.54
2
1
5
Top View
2
4
3
10.16
1
5
3.54
PACKAGING INFORMATION
Parameter
Packaging Dimension (LxWxH)
Packaging Quantity
Storage Temperature Range
Storage Humidity
non-condensing
10.16
Type
Value
520.0 x 56.0 x 32.0mm
16pcs.
-40°C to +75°C
95% RH max.
The product information and specifications may be subject to changes even without prior written notice.The product has been designed for various applications; its suitability lies in the responsibility of each customer. The
products are not authorized for use in safety-critical applications without RECOM’s explicit written consent. A safety-critical application is an application where a failure may reasonably be expected to endanger or cause
loss of life, inflict bodily harm or damage property. The applicant shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized
use of RECOM products in such safety-critical applications.
