Product Brief
Avago SAS 9207-8i
8-port, 6Gb/s SAS+SATA to PCIe Host Bus Adapter
Key Features
■■
■■
■■
■■
8-port SAS HBA Provides High Performance for Internal Storage
Connections
Overview
Avago SAS 9207-8i host bus adapter provides high performance for internal drive connectivity
in 1U/2U servers and workstations. The SAS 9207-8i provides 8 lanes of 6Gb/s SAS and
is matched with 8 lanes of PCI Express (PCIe) 3.0, 8Gb/s performance to eliminate any
performance bottlenecks. Performance is based on the SAS 2308 6Gb/s SAS IO Controller that
highly integrates the latest enhancements in PCIe and SAS technology.
The SAS 9207-8i has two (x4) internal mini-SAS connectors (SFF8087) and provides SAS and
SATA data transfer rates of 1.5, 3, and 6Gb/s per lane and can achieve over 650K IOPs.
8 internal 6Gb/s SAS+SATA ports
8 lanes, PCI Express 3.0
Low profile form factor design
Two x4 internal mini-SAS connectors
(SFF8087)
SAS 2308 6Gb/s SAS+SATA Controller
Supports up to 256 SAS or SATA end
devices
Supports SSDs, HDDs and tape drives
■■
■■
■■
Key Advantages
■■
Provides internal connectivity in a low
profile form factor
8 lanes of PCIe 3.0 provides fast
signaling for high-bandwidth
applications
High performance with 6Gb/s data
transfer rates
Storage by LSI
™
Avago Technologies products serve four primary target markets: wireless communications,
wired infrastructure, enterprise storage, and industrial. Avago Storage by LSI offers the
industry’s broadest portfolio of storage solutions, backed by decades of experience and
trusted by the world’s leading server and storage suppliers. Avago provides the building blocks
for storage solutions that help customers understand, prioritize, store and protect critical data.
The Avago SAS portfolio includes MegaRAID
®
controller cards, host bus adapters (HBAs),
advanced software options, Syncro
®
shared DAS solutions and SAS storage ICs, including RAID-
on-Chip (ROCs), I/O controllers and expanders.
■■
■■
Fusion-MPT
™
Architecture
Fusion-MPT architecture marks the next generation of I/O architecture designed to deliver
the highest performance available today while reducing time to market, integration, and
certification time. Fusion-MPT devices are high performance, cost-effective protocol controllers
that represent the newest system- level integration technology in intelligent I/O processors
from Avago.
Product Brief
SAS 9207-8i Host Bus Adapter
IO Controller
Storage Connectivity Data Transfer Rates
SAS Bandwidth
Port Configurations
Host Bus
PCI Data Burst Transfer Rates
Physical Dimensions
Connectors
Brackets
Cable Support
PCI Card Type
Operating Voltage
PCI Power (Nominal)
Device Support
Environmental
SAS 2308/ Fusion MPT 2.0
8 ports, 6Gb/s SAS 2.1 Compliant
Half Duplex
600 MB/s per lane
8 ea, x1 ports (individual drives)
2 ea, x4 wide port
x8 lane, PCI Express 3.0 compliant
Half Duplex
x8, PCIe, 8000 MB/s
Low Profile (2.6” x 6.6”)
Two mini-SAS internal connectors (SFF8087)
Full height and low profile
Passive Copper
3.3 V Add-in Card
+12V +/-8%; 3.3V +/-9%
9.8W
256 Non-RAID devices
Operating
0oC to 55oC
MTBF
Regulatory Certifications
OS Support
Warranty
Storage
-45°C to 105°C
5 to 90% Non-condensing
5 to 90% Non-condensing
>2,000,000
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024);
Australia/New Zealand (AS/NZS 3548); Korea (N-B 2-0001-404); Safety: EN60950; RoHS; WEEE
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware, FreeBSD
See http://www.lsi.com/support/pages/download-search.aspx for details on versions
3 years; with advanced replacement option
Free technical support at http://www.lsi.com/support
Ordering Information
SAS 9207-8i SGL
MPN: H5-25412-00
OPN: LSI00301
