This document was generated on 03/02/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0937698628
Active
MXMag Single-Port RJ45 Magnetic Jacks
MXMag Gigabit 8 Core Single-Port RJ45 Connector, 21.40mm Depth, 1.80mm Phy
Pin Length, Right Angle, Inverted Profile, with Shield Tabs, with Green/Yellow-Green/
Yellow LEDs, Industrial Temperature, Pin in Paste Capable, with Pick-and-Place
Option, with 2kV Shield Connection, Tape and Reel
Documents:
3D Model
Drawing (PDF)
Product Specification 934620001-N (PDF)
General
Product Family
Series
Component Type
Depth
Magnetic
Overview
Performance Category
Power over Ethernet (PoE)
Product Literature Order No
Product Name
UPC
Physical
Color - Resin
Durability (mating cycles max)
Inverted / Top Latch
Jack Height
Keying to Mating Part
Lightpipes/LEDs
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Plating min - Mating
Ports
Positions / Loaded Contacts
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Wire/Cable Type
Electrical
Current - Maximum per Contact
Grounding to PCB
Grounding to Panel
Shielded
Packaging Specification 934620002-K (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
Not Reviewed
Modular Jacks/Plugs
93769
PCB Jack
21.40mm
Yes
MXMag Single-Port RJ45 Magnetic Jacks
1000Mb
Non-PoE
987651-2501
Magnetic Jack, Modular Jack 8/8, MXMag, RJ45
889056789097
Black
2500
Yes
14.10mm
None
LEDs
Phosphor Bronze
Gold over Palladium Nickel
Tin
Liquid Crystal Polymer
6.473/g
Right Angle (Side Entry)
Yes
None
1.57mm
Embossed Tape on Reel
Spring
0.051µm (Au), 1.016µm (PdNi)
1
8/8
Yes
-40°C to +85°C
Through Hole
N/A
0.5A
Yes
Yes
Yes
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Search Parts in this Series
93769 Series
Mates With
IEC 60603 / TIA-1096-A
