12/5/2018
ABS Plastic Project Enclosures (RL Series) - Hammond Mfg.
Quality Products. Service Excellence.
ABS Plastic Project Enclosures
RL Series
Shallow Lid
Key Features
Designed to house P.C. boards for hand-held use or wall mount.
Molded in light grey or black general purpose ABS plastic with a light texture.
Two part construction. Both halves include smooth recessed area for membrane, label or
silkscreen (see chart below for recess size).
P.C. board standoffs are molded into both halves of the enclosure (see photo tables for
details).
Designed to meet IP54.
All sizes also available in a flanged lid version.
Includes four M2.6 assembly screws.
Photos
Available in black or gray, and with or without mounting flanges. Includes lid and PC board
screws.
No
Flanges
RL6105BK
RL6105
RL6115BK
RL6115
RL6165BK
RL6165
RL6175BK
RL6175
RL6215BK
RL6215
RL6225BK
RL6225
RL6335BK
RL6335
With
Flanges
RL6105-FBK
RL6105-F
RL6115-FBK
RL6115-F
RL6165-FBK
RL6165-F
RL6175-FBK
RL6175-F
RL6215-FBK
RL6215-F
RL6225-FBK
RL6225-F
RL6335-FBK
RL6335-F
Color
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Length
3.15
3.15
3.15
3.15
4.13
4.13
4.13
4.13
4.92
4.92
4.92
4.92
4.92
4.92
Width
2.36
2.36
2.36
2.36
2.56
2.56
2.56
2.56
3.15
3.15
3.15
3.15
3.94
3.94
Depth (with lid)
1.18
1.18
1.57
1.57
1.18
1.18
1.57
1.57
1.38
1.38
1.97
1.97
2.36
2.36
Lid Recess
Size
2.13 x 2.05
2.13 x 2.05
2.13 x 2.05
2.13 x 2.05
3.11 x 2.24
3.11 x 2.24
3.11 x 2.24
3.11 x 2.24
3.78 x 2.76
3.78 x 2.76
3.78 x 2.76
3.78 x 2.76
3.78 x 3.46
3.78 x 3.46
Bottom
Recess Size
2.13 x 2.05
2.13 x 2.05
2.13 x 2.05
2.13 x 2.05
3.11 x 2.24
3.11 x 2.24
3.11 x 2.24
3.11 x 2.24
3.78 x 2.76
3.78 x 2.76
3.78 x 2.76
3.78 x 2.76
3.78 x 3.46
3.78 x 3.46
PCB
Mounting Dim
2.52 x 1.18
2.52 x 1.18
2.52 x 1.18
2.52 x 1.18
3.5 x 1.38
3.5 x 1.38
3.5 x 1.38
3.5 x 1.38
4.21 x 1.57
4.21 x 1.57
4.21 x 1.57
4.21 x 1.57
4.17 x 2.56
4.17 x 2.56
Wall Mount
Dim (flanged lid only)
3.62
3.62
3.62
3.62
5.08
5.08
5.08
5.08
5.39
5.39
5.39
5.39
5.39
5.39
https://www.hammfg.com/electronics/small-case/plastic/rl
1/2
12/5/2018
No
Flanges
RL6365BK
RL6365
RL6435BK
RL6435
RL6465BK
RL6465
RL6555BK
RL6555
RL6585BK
RL6585
RL6655BK
RL6655
RL6685BK
RL6685
With
Flanges
RL6365-FBK
RL6365-F
RL6435-FBK
RL6435-F
RL6465-FBK
RL6465-F
RL6555-FBK
RL6555-F
RL6585-FBK
RL6585-F
RL6655-FBK
RL6655-F
RL6685-FBK
RL6685-F
Color
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Black
Grey
Length
4.92
4.92
5.91
5.91
5.91
5.91
6.89
6.89
6.89
6.89
7.87
7.87
7.87
7.87
ABS Plastic Project Enclosures (RL Series) - Hammond Mfg.
Lid Recess
Width
3.94
3.94
3.94
3.94
3.94
3.94
4.92
4.92
4.92
4.92
5.91
5.91
5.91
5.91
Depth (with lid)
3.54
3.54
2.36
2.36
3.54
3.54
2.76
2.76
3.94
3.94
2.76
2.76
3.94
3.94
Size
3.78 x 3.46
3.78 x 3.46
4.72 x 3.54
4.72 x 3.54
4.72 x 3.54
4.72 x 3.54
5.59 x 4.53
5.59 x 4.53
5.59 x 4.53
5.59 x 4.53
6.50 x 5.31
6.50 x 5.31
6.50 x 5.31
6.50 x 5.31
Bottom
Recess Size
3.78 x 3.46
3.78 x 3.46
4.72 x 3.54
4.72 x 3.54
4.72 x 3.54
4.72 x 3.54
5.59 x 4.53
5.59 x 4.53
5.59 x 4.41
5.59 x 4.41
6.50 x 5.31
6.50 x 5.31
6.50 x 5.31
6.50 x 5.31
PCB
Mounting Dim
4.17 x 2.56
4.17 x 2.56
5.20 x 2.36
5.20 x 2.36
5.20 x 2.36
5.20 x 2.36
6.06 x 2.76
6.06 x 2.76
6.06 x 2.76
6.06 x 2.76
7.01 x 3.94
7.01 x 3.94
7.01 x 3.94
7.01 x 3.94
Wall Mount
Dim (flanged lid only)
5.39
5.39
6.38
6.38
6.38
6.38
7.36
7.36
7.36
7.36
6.50
6.50
6.50
6.50
Data subject to change without notice
© 2018. Hammond Manufacturing Ltd. All rights reserved.
https://www.hammfg.com/electronics/small-case/plastic/rl
2/2
