TS10K40 - TS10K80
Taiwan Semiconductor
CREAT BY ART
10A, 400V - 800V Glass Passivated Bridge Rectifiers
FEATURES
- Glass passivated junction
- Ideal for printed circuit board
- Typical IR less than 0.1μA
- High surge current capability
- UL Recognized File # E-326243
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
+
~
~ –
TS4K
MECHANICAL DATA
Case:
TS4K
Molding compound, UL flammability classification rating 94V-0
Part no. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
Polarity as marked on the body
Mounting torque:
8.17 in-lbs maximum
Weight:
4 g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Rating for fusing (t<8.3ms)
Maximum instantaneous forward voltage I
F
=5A
(Note 1)
I
F
=10A
Maximum reverse current @ rated V
R
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
T
J
=25°C
T
J
=125°C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
V
F
I
R
R
θJC
T
J
T
STG
TS10K40
400
280
400
TS10K60
600
420
600
10
150
93
1.0
1.1
10
500
2.3
- 55 to +150
- 55 to +150
TS10K80
800
560
800
UNIT
V
V
V
A
A
A
2
s
V
μA
°C/W
°C
°C
Document Number: DS_D1312001
Version: E15
TS10K40 - TS10K80
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
TS10Kxx
(Note 1)
*: Optional available
PART NO.
SUFFIX
H
PACKING
CODE
D3
X0
PACKING CODE
SUFFIX
G
(*)
PACKAGE
TS4K
TS4K
PACKING
20 / TUBE
Forming
Note 1: "xx" defines voltage from 400V (TS10K40) to 800V (TS10K80)
EXAMPLE
PREFERRED P/N
TS10K80HD3G
PART NO.
TS10K80
PART NO.
SUFFIX
H
PACKING CODE
D3
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CURVE
100
12
10
8
6
4
2
0
50
60
70
80
90
100
110
120
130
140
150
RESISTIVE OR
INDUCTIVE LOAD
WITH HEATSINK
INSTANTANEOUS REVERSE CURRENT (μA)
10
T
J
=125°C
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
AVERAGE FORWARD
A
CURRENT (A)
1
0.1
0.01
T
J
=25°C
CASE TEMPERATURE (
°
C)
0.001
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
300
250
200
150
100
50
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
8.3ms Single Half Sine Wave
INSTANTANEOUS FORWARD CURRENT (A)
PEAK FORWARD SURGE CURRENT (A)
FIG. 4 TYPICAL FORWARD CHARACTERISTICS
100
10
1
0.1
0.4
0.6
0.8
1
FORWARD VOLTAGE (V)
1.2
1.4
Document Number: DS_D1312001
Version: E15
TS10K40 - TS10K80
Taiwan Semiconductor
FIG. 5 TYPICAL JUNCTION CAPACITANCE
300
J UNCTION CAPACITANCE (pF)
A
250
200
150
100
50
0
0.1
1
10
100
REVERSE VOLTAGE (V)
f=1.0MHz
Vsig=50mVp-p
PACKAGE OUTLINE DIMENSIONS
TS4K
DIM.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Unit (mm)
Min
24.70
2.00
0.90
7.30
3.00
14.70
3.30
17.00
4.40
3.40
9.30
3.10
3.10
0.50
Max
25.30
2.30
1.10
7.70
5.00
15.30
3.70
18.00
4.80
3.80
9.60
3.60
3.40
0.70
Unit (inch)
Min
0.972
0.079
0.035
0.287
0.118
0.579
0.130
0.669
0.173
0.134
0.366
0.122
0.122
0.020
Max
0.996
0.091
0.043
0.303
0.197
0.602
0.146
0.709
0.189
0.150
0.378
0.142
0.134
0.028
MARKING DIAGRAM
P/N
G
YWW
F
= Specific Device Code
= Green Compound
= Date Code
= Factory Code
Document Number: DS_D1312001
Version: E15
TS10K40 - TS10K80
Taiwan Semiconductor
CREAT BY ART
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Document Number: DS_D1312001
Version: E15
