VOR1121A6, VOR1121B6
www.vishay.com
Vishay Semiconductors
1 Form A Solid-State Relay (Normally Open)
FEATURES
• Isolation test voltage 5300 V
RMS
A 1
6
S
1
• Typical R
ON
12
• Load voltage 250 V
• Load current 200 mA / 370 mA
• Clean bounce free switching
• Current limit protection
• Low power consumption
• Wide temperature range
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
C 2
5 DC
3
4
S
2
APPLICATIONS
DESCRIPTION
The VOR1121 is a 250 V single channel normally open
optically isolated solid-state relay (SPST - 1 form A). Based
on hybrid architecture which allows fast switching times
with a wide operating ambient temperature range. A high
efficient GaAlAs IRED enables low forward current on the
input side. On the output side high performance MOSFET
switches provide a low R
ON
and can switch both DC and AC
signals.
• General telecom switching
• Metering
• Security equipment
• Instrumentation
• Industrial controls
• Battery management systems
• Automatic test equipment
AGENCY APPROVALS
• UL1577, file no. E52744
• DIN EN 60747-5-5 (VDE0884-5)
ORDERING INFORMATION
V
O
R
1
PART NUMBER
PACKAGE
SMD-6, tape and reel
SMD-6, tube
DIP-6, tube
1
2
1
B
6
PACKAGE
CONFIGURATION
UL, VDE
VOR1121B6T
VOR1121B6
VOR1121A6
#
DIP-6
SMD-6
Rev. 1.1, 29-Aug-16
Document Number: 84298
1
