100SWE48QFH datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Embedded solution> Ethernet and communication module> Network module> 100SWE48QFH

100SWE48QFH: DescriptionNetwork module Intel Omni-Path Edge Switch 100 Series 48 Port Managed Forward Hot Swap 100SWE48QFH; CategoryEmbedded solution Ethernet and communication module Network module; File Size97KB，6 Pages; ManufacturerIntel; Websitehttp://www.intel.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

100SWE48QFH Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	100SWE48QFH	-	-	View	Buy Now

100SWE48QFH Overview

Network module Intel Omni-Path Edge Switch 100 Series 48 Port Managed Forward Hot Swap 100SWE48QFH

100SWE48QFH Parametric

Parameter Name	Attribute value
Maker	Intel
Product Category	network module
Shipping restrictions	Mouser does not currently sell this product.
product	Edge Switches
Processor type	Intel Xeon
data rate	100 Gb/s
Number of ports	48 Port
Interface Type	Ethernet, USB
Working power voltage	100 VAC to 240 VAC
Minimum operating temperature	0 C
Maximum operating temperature	+ 40 C
size	17.3 in x 1.72 in x 17.15 in
Factory packaging quantity	1

Preview

Download Datasheet

View All

Product Brief

Intel® Omni-Path Fabric

Edge Switches 100 Series

48 and 24 port edge switches (100 Gbps per port)

Intel

Omni-Path Fabric Edge Switches,

an element of the Intel® Scalable System

Framework, are part of an end-to-end

product family for HPC fabrics that

delivers high performance with

breakthrough value. Intel

Omni-Path

Architecture (Intel® OPA) builds on

proven technologies from Intel® True

Scale Architecture, the Cray Aries*

interconnect, and open source software

to provide an evolutionary on-ramp to

revolutionary new fabric capabilities.

The Right Fabric for HPC

Key Benefits

Highly-integrated design reduces

space, power, and cost

•

48 ports, 1U chassis

•

24 ports, 1U chassis

Optimized for high message rates

and low end-to-end latency

Simple generational upgrades, with:

•

Binary compatible applications

•

FastFabric tools for easy

installation

•

All open source software

Higher Performance at Lower Cost

Intel

Omni-Path Edge Switches deliver

100 Gbps port bandwidth with latency

that stays low even at extreme scale.

Second generation Intel fabric switch

silicon, with market leading 48 port radix,

these switches can lower fabric

acquisition costs by as much as 50

percent, while simultaneously reducing

space and power requirements.

With

these savings, you can potentially

achieve higher total cluster performance

within the same hardware budget to

expand and accelerate your research.

Key Features

Up to 1.2 terabytes of aggregate

bandwidth

Out of band fabric management

(optional)

Redundant power (optional)

Redundant cooling

Reversible air flow

Next-generation fabric innovations

•

Packet Integrity Protection

(PIP)

•

Traffic Flow Optimization

(TFO)

•

Dynamic Lane Scaling (DLS)

•

New 8K and 10K MTUs for

improved storage efficiency

Flexible Fabrics at Every Scale

Intel

Omni-Path Fabric Edge Switches

support HPC clusters of all sizes, from

entry-level systems to supercomputers

with tens of thousands of server nodes.

You can use these switches in

562731-04

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY

RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND

INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A

PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics of any features or instructions marked

"reserved" or "undefined". Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The

information here is subject to change without notice. Do not finalize a design with this information.

The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are

available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-4725, or go to:

http://www.intel.com/design/literature.htm

Intel® and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.

Intel technologies’ features and benefits depend on system configuration and may require enabled hardware, software or service activation. Learn more at Intel.com, or from the OEM or retailer.

Software and workloads used in performance tests may have been optimized for performance only on Intel® microprocessors

Internal cost analysis based on a 256-node to 2048-node clusters configured with Mellanox* FDR and EDR InfiniBand* products. Mellanox component pricing from

kernelsoftware.com

Prices as of November 3, 2015. Compute node pricing based on Dell PowerEdge R730 server from

www.dell.com.

Prices as of May 26, 2015. Intel®

OPA (x8) utilizes a 2-1 over-subscribed Fabric. Intel® OPA pricing based on estimated reseller pricing using projected Intel MSRP pricing on day of launch.

562731-04

100SWE48QFH Related Products

	100SWE48QFH	100SWE48UFH
Description	Network module Intel Omni-Path Edge Switch 100 Series 48 Port Managed Forward Hot Swap 100SWE48QFH	Network module Intel Omni-Path Edge Switch 100 Series 48 Port Forward Hot Swap 100SWE48UFH
Maker	Intel	Intel
Product Category	network module	network module
Shipping restrictions	Mouser does not currently sell this product.	Mouser does not currently sell this product.
product	Edge Switches	Edge Switches
Processor type	Intel Xeon	Intel Xeon
data rate	100 Gb/s	100 Gb/s
Number of ports	48 Port	48 Port
Interface Type	Ethernet, USB	Ethernet, USB
Working power voltage	100 VAC to 240 VAC	100 VAC to 240 VAC
Minimum operating temperature	0 C	0 C
Maximum operating temperature	+ 40 C	+ 40 C
size	17.3 in x 1.72 in x 17.15 in	17.3 in x 1.72 in x 17.15 in
Factory packaging quantity	1	1
