First Sensor High Voltage Supply Data Sheet
Part Description MOD50138101 and MOD50138201
Order # 50138101; 50138201
Version 30-10-2015
MOD 50138101 &
MOD50138201
Features
• Low ripple <10mVpp
• On-board reference source
• Easy adjustment
• Shielded, HF safe package
• up to 500 V maximum voltage
Description
Precission regulated power module
for APD and PIN diodes with very
low ripple.
Application
• High voltage for APD
• High voltage for PIN-PD
RoHS
2011/65/EU
Absolute maximum ratings
Symbol
T
STG
T
OP
Vcc
Parameter
Storage temp
Operating temp
Supply Voltage
Min
-10
-10
0
Max
125
70
6
Unit
°C
°C
V
Voltage Control
500
450
400
#50138101
#50138201
Output Voltage (V)
350
300
250
200
150
100
50
0
0
0,5
1
1,5
2
2,5
Block diagram
Control / Programming Voltage (V)
Electrical characteristics @ 23°C
Symbol
V
CC
Characteristic
Input voltage
Input current w/o load
Input capacitance
Control voltage
Set point accuracy
Deviation from linearity
Reference output
Temperature coefficient
Ripple
Short circuit protected
Output voltage
Output voltage
Output current
Test Condition
@ 500 V
200
0
1
0.5
2.5
7.5
2.5
Min
+4.5
Typ
Max
+5.5
70
Unit
V
mA
µF
V
%
%
V
ppm/K
mVpp
s
V
V
mA
V
control
V
ref
T
K
2.475
peak to peak
order number 50138101
order number 50138201
HV
out
2.525
50
10
5
500
200
1
European, International Sales:
First Sensor AG
Peter-Behrens-Strasse 15
12459 Berlin
Germany
T +49 30 6399 2399
F +49 30 639923-752
sales.opto@first-sensor.com
USA:
First Sensor Inc.
5700 Corsa Avenue #105
Westlake Village
CA 91362 USA
T +1 818 706 3400
F +1 818 889 7053
sales.us@first-sensor.com
ta Sheet
First Sensor High Voltage Supply Data Sheet
Part Description MOD50138101 and MOD50138201
Order # 50138101; 50138201
Version 30-10-2015
50138201
50138201
n 30-10-2015
Application hints
Technical drawing
A = 50,5
B = 31,5
C = 13
D= 48
E= 29
Mechanical characteristics
Parameter
Length
Width
Height
Volume
Weight
Case material
Disclaimer:
Pin connections
Unit
mm
mm
mm
cm³
g
Part
1
2
3
4
5
6
Symbol
V
control
V
ref
HV
out
HV
GND
GND
V
CC
Function
Control voltage
Reference output
High voltage output
High voltage ground
Ground
Input voltage
Parameter
50,5
31,5
13
20,70
40
Tinplate
Due to our strive for continuous improvement, specifications are subject to change within our PCN policy according to JESD46C.
First Sensor AG
Peter-Behrens-Strasse 15
12459 Berlin
Germany
T +49 30 6399 2399
F +49 30 639923-752
sales.opto@first-sensor.com
European, International Sales:
USA:
First Sensor Inc.
5700 Corsa Avenue #105
Westlake Village
CA 91362 USA
T +1 818 706 3400
F +1 818 889 7053
sales.us@first-sensor.com
