MAXM17532 Evaluation Kit
Evaluates: MAXM17532
5V Output-Voltage Application
General Description
The MAXM17532 evaluation kit (EV kit) is a demonstra-
tion circuit of the MAXM17532 42V,100mA ultra-small,
high efficiency, current mode, synchronous step-down
DC-DC switching power module. The EV kit operates
over a wide input-voltage of 10V to 42V and provides up
to 100mA load current with a 5V output voltage. The EV
kit is programmed to switch at a frequency of 600kHz.
The module is simple to use and easily configurable
with minimal external components. It features cycle-by-
cycle peak current-limit protection, undervoltage lockout
(EN/UVLO), and thermal shutdown.
The EV kit comes with the compact 10-pin 2.6mm x
3mm x 1.5mm uSLIC™ package MAXM17532 module
installed, and is rated to operate over the full industrial/
automotive -40°C to +125°C temperature range.
Quick Start
Recommended Equipment
● 42V DC power supply
● Dummy load capable of sinking 100mA
Digital voltmeter (DVM)
● 100MHz dual-trace oscilloscope
● MAXM17532EVKIT#, MAXM17532 evaluation kit
Procedure
The MAXM17532 EV kit is fully assembled and tested.
Please follow the steps below to verify the board opera-
tion.
Caution: Do not turn on the power supply until all
connections are completed.
1)
2)
3)
Set the power supply at a voltage between 10V and
42V. Disable the power supply.
Connect the positive and negative terminals of the
power supply to VIN and GND PCB pads, respectively.
Connect the positive and negative terminals of the
100mA load to VOUT and GND PCB pads respec-
tively, and the set the load to 0A.
Connect the DVM across the VOUT PCB pad and the
GND PCB pad closest to VOUT PCB pad.
Enable the input power supply.
Verify the DVM across output display 5V.
Increase the load up to 100mA to verify the output
voltage is 5V using DVM.
Features
● Wide 10V to 42V Input
● ±1.75% Feedback Voltage Accuracy
● Output: 5V,100mA
● Internally Compensated
● All Ceramic Capacitors and Ultra-Compact Solution
● PFM or Forced-PWM Mode of Operation
● Shutdown Current as Low as 1.2μA (typ)
● Programmable Soft-Start and Prebias Startup
● Open-Drain Power Good Output (RESET pin)
● Programmable EN/UVLO Threshold
● Hiccup Overcurrent Protection (OCP)
● Overtemperature Protection (OTP)
● Complies with CISPR22 (EN55022) Class B
Conducted and Radiated Emissions
● Passes Drop, Shock, and Vibration Standards–
JESD22-B103, B104, B111
● -40°C to +125°C Industrial/Automotive
Temperature Range
4)
5)
6)
7)
Ordering Information
appears at end of data sheet.
uSLIC is a trademark of Maxim Integrated Products, Inc.
319-100067; Rev 1; 8/18
