Compact Photoelectric Sensor with Built-in Amplifier
E3Z
CSM_E3Z_DS_E_14_1
The Standard for Photoelectric Sensors
with a Secure Track Record of One
Million Sold Yearly.
• Long sensing distance of 30 m for Through-beam Models, 4 m for
Retro-reflective Models, and 1 m for Diffuse-reflective Models.
• Mechanical axis and optical axis offset of less than
±2.5
°
simplifies
optical axis adjustment.
• High stability with unique algorithm that prevents interference of
external light.
Be sure to read
Safety Precautions
on
page 15.
Features
Industry's Top-level Sensing Distance with
Built-in Amplifier
A separately sold filter is available to prevent mutual interference for
Through-beam Models with red lights sources and a sensing
distance of 10 m. Reflective Models include functionality to prevent
mutual interference.
Long-distance, Through-beam Sensors with a detection distance of
30 m (response time: 2 ms) are also available.
Through-beam
30 m
Retro-reflective
with
MSR function
Distance-settable
4m
Diffuse-reflective
20 cm
1m
Low-temperature Operation for Applications in Cold-storage Warehouses
A wider ambient operating range from
−40
to 55°C (main models with connectors). We also provide Sensor I/O Connectors with PUR Cables for
high resistance to cold environments.
Improved Matching of Optical Axis and Mechanical Axis for
Through-beam Models and Retro-reflective Models
The offset between the optical axis and the mechanical axis is kept within
±2.5°,
so the optical axis can
be accurately set simply by mounting the Sensor according to the mechanical axis.
30 m
mechanical 2.5° max.
axis
Optical axis
The receiver
will
always
be
in the range of light diffusion.
Sensor Protection against Incorrect Wiring
The Sensor includes output reverse polarity protection.
(A diode to protect against reverse polarity is added to the output line.)
Through-beam Model receivers and Reflective Models (except the E3Z-LS)
Operation
indicator
(orange)
Stability
indicator
(green)
1
Brown
12 to 24 VDC
Photo-
electric
Sensor
main
circuit
4
Black
100 mA Load
(relay)
max.
ZD
3
Blue
0V
Protection for NPN output models
Complete Compliance with the EU's RoHS Directive
Lead, mercury, cadmium hexachrome, polybrominated biphenyl (PBB), and polybrominated
diphenyl ether (PBDE) have all been eliminated. Also, burnable polyethylene packaging has
been used.
Pb
eco
1
E3Z
Ordering Information
Sensors
[Refer to
Dimensions on page
16.]
Sensing method
Appearance
Connection method
Pre-wired (2 m)
Sensing distance
NPN output
E3Z-T61 2M
Emitter E3Z-T61-L 2M
Receiver E3Z-T61-D 2M
Red light
Infrared light
Model
PNP output
E3Z-T81 2M
Emitter E3Z-T81-L 2M
Receiver E3Z-T81-D 2M
E3Z-T86
Emitter E3Z-T86-L
Receiver E3Z-T86-D
E3Z-T81A 2M
Emitter E3Z-T81-A-L 2M
Receiver E3Z-T81-A-D 2M
E3Z-T86A
Emitter E3Z-T86-A-L
Receiver E3Z-T86-A-D
E3Z-T82 2M
Emitter E3Z-T82-L 2M
Receiver E3Z-T82-D 2M
E3Z-T87
Emitter E3Z-T87-L
Receiver E3Z-T87-D
15 m
Standard M8 connector
E3Z-T66
Emitter E3Z-T66-L
Receiver E3Z-T66-D
E3Z-T61A 2M
Emitter E3Z-T61-A-L 2M
Receiver E3Z-T61-A-D 2M
Through-beam
(Emitter + Receiver)
*3
Pre-wired (2 m)
10 m
Standard M8 connector
E3Z-T66A
Emitter E3Z-T66-A-L
Receiver E3Z-T66-A-D
E3Z-T62 2M
Emitter E3Z-T62-L 2M
Receiver E3Z-T62-D 2M
E3Z-T67
Emitter E3Z-T67-L
Receiver E3Z-T67-D
Pre-wired (2 m)
Standard M8 connector
30m
Pre-wired (2 m)
Emission stop
function
Standard M8 connector
Retro-reflective with
MSR function
Pre-wired (2 m)
*1
Standard M8 connector
Pre-wired (2 m)
Standard M8 connector
Diffuse-reflective
Pre-wired (2 m)
Standard M8 connector
Pre-wired (2 m)
Standard M8 connector
Pre-wired (2 m)
Distance-settable
Refer to
E3Z-LS.
Standard M8 Connector
Pre-wired (2 m)
Standard M8 connector
1 axis
Slit-type Through-
beam
Refer to
E3Z-G.
2 axes
E3Z-T62-G0 2M
*4
E3Z-T82-G0 2M
*4
Emitter E3Z-T62-G0-L 2M Emitter E3Z-T82-G0-L 2M
Receiver E3Z-T62-G0-D 2M Receiver E3Z-T82-G0-D 2M
E3Z-T67-G0
*4
Emitter E3Z-T67-G0-L
Receiver E3Z-T67-G0-D
E3Z-T87-G0
*4
Emitter E3Z-T87-G0-L
Receiver E3Z-T87-G0-D
E3Z-R81 2M
E3Z-R86
E3Z-D81 2M
E3Z-D86
E3Z-D82 2M
E3Z-D87
E3Z-L81 2M
E3Z-L86
E3Z-LS81 2M
E3Z-LS86
E3Z-LS83 2M
E3Z-LS88
E3Z-G81 2M
E3Z-G82 2M
E3Z-G81-M3J
E3Z-G82-M3J
E3Z-L83 2M
E3Z-J88
E3Z-B81 2M
E3Z-B86
E3Z-B82 2M
E3Z-B87
4 m
*2
(100 mm)
E3Z-R61 2M
E3Z-R66
E3Z-D61 2M
E3Z-D66
E3Z-D62 2M
5 to 100 mm
(wide view)
1m
90±30 mm
(narrow
beam)
20 to 40 mm (BGS min setting)
20 to 200 mm (BGS max setting)
40 min. Incident threshold (FGS min setting)
200 min. Incident threshold (FGS max setting)
E3Z-D67
E3Z-L61 2M
E3Z-L66
E3Z-LS61 2M
E3Z-LS66
2 to 20 mm (BGS min setting)
E3Z-LS63 2M
2 to 80 mm (BGS max setting)
E3Z-LS68
E3Z-G61 2M
E3Z-G62 2M
Pre-wired (2 m)
1 axis
2 axes
25 mm
Pre-wired M8 connector
Pre-wired (2 m)
Standard M8 connector
Pre-wired (2 m)
E3Z-G61-M3J
E3Z-G62-M3J
E3Z-L63 2M
Limited-reflective for
transparent glasses
30±20 mm
*2
E3Z-L68
E3Z-B61 2M
E3Z-B66
E3Z-B62 2M
E3Z-B67
Retro-reflective with-
out MSR function for
clear, plastic bottles
Standard M8 connector
*1
Pre-wired (2 m)
Standard M8 connector
500 mm (80 mm)
*2
2 m (500 mm)
*1. The Reflector is sold separately. Select the Reflector model most suited to the application.
*2. The sensing distance specified is possible when the E39-R1S is used. Values in parentheses indicate the minimum required distance between the Sensor and Reflector.
*3. Through-beam Sensors are normally sold in sets that include both the Emitter and Receiver.
Orders for individual Emitters and Receivers are accepted. (Modifications are required for some models. Ask your OMRON representative for details.)
*4. Models with emission stop function. Refer to page 8,
Photoelectric Sensors Technical Guide
for details.
2
E3Z
Variety of Connection Specifications
The models with the connection specifications marked with a black circle in the table are available.
The model number indication is a combination of the basic model and the connection specification.
Example: E3Z-T61-M1TJ 0.3M
Basic model
number
Connection
specification
E3Z-T61
-ECON 0.3M
E3Z-T61
-ECON 0.5M
NPN Output
Model
Model
number
example
E3Z-T61
-M1TJ 0.3M
E3Z-T61 0.5M
E3Z-T61 5M
E3Z-T61
-M1J 0.3M
E3Z-T61
-M3J 0.3M
E3Z-T61
-ECON 2M
Sensing
method
Sens-
ing dis-
tance
Main
features
M12 pre-
Connec-
Pre-wired
wired Smart-
tion
click connec- (cable length:
specifi-
0.5 m)
tor (cable
cation
length: 0.3 m)
Basic
model
number
-M1TJ 0.3M
●
---
---
●
---
●
●
---
---
●
---
---
---
0.5M
●
●
●
●
●
●
●
●
●
●
●
●
●
Pre-wired
(cable length:
5 m)
M12 pre-
e-CON pre-
M8, 4-pin pre-
wired stan-
wired con-
wired con-
dard connec-
nector (cable
nector (cable
tor (cable
length: 0.3 m/
length: 0.3 m)
length: 0.3 m)
0.5 m)
-M1J 0.3M
●
●
---
●
●
●
●
●
---
●
●
---
●
-M3J 0.3M
●
---
---
●
●
●
---
●
---
●
●
---
---
-ECON 0.3M
-ECON 0.5M
●
●
---
●
●
●
●
●
---
●
●
●
●
e-CON pre-
wired con-
nector (cable
length: 2 m)
5M
●
●
---
●
●
●
●
●
---
●
●
●
●
.
-ECON 2M
●
●
---
●
●
●
●
●
---
●
●
●
●
15 m
Through-
beam
10 m
30 m
Retro-
reflective
4m
100 mm
Diffuse-
reflective
(narrow-
beam re-
flective)
Infrared
E3Z-T61
light
Red
light
E3Z-T61A
2-ms re-
E3Z-T62
sponse
MSR
E3Z-R61
function
Wide
view
Long
dis-
tance
Narrow
beam
E3Z-D61
1m
E3Z-D62
90 mm
200 mm
80 mm
E3Z-L61
Distance-
settable
FGS
E3Z-LS61
function
Small
spot
E3Z-LS63
Slit-type
25 mm
1 optical
E3Z-G61
axis
2 optical
E3Z-G62
axes
E3Z-B61
No MSR
function E3Z-B62
Retro-
reflective
for clear,
plastic
bottles
500 mm
2m
Clamp-type e-CON pre-wired connectors are also available for models shaded in
Add "-ECON-C 2M" after the basic model number to specify the connectors.
*1. The Reflector is sold separately. Select the Reflector model most suited to the application.
*2. The sensing distance specified is possible when the E39-R1S is used. Values in parentheses indicate the minimum required distance between the Sensor and Reflector.
*3. Through-beam Sensors are normally sold in sets that include both the Emitter and Receiver.
Orders for individual Emitters and Receivers are accepted. (Modifications are required for some models. Ask your OMRON representative for details.)
Accessories (Order Separately)
Slit
(A Slit is not provided with Through-beam Sensors) Order a Slit separately if required.
[Refer to
Dimensions
on page 18.]
Slit width
0.5-mm dia.
1-mm dia.
2-mm dia.
0.5
×
10 mm
1
×
10 mm
2
×
10 mm
Sensing distance
E3Z-T@@
E3Z-T@@A
50 mm
35 mm
200 mm
150 mm
800 mm
550 mm
1m
700 mm
2.2 m
1.5 m
5m
3.5 m
Minimum detectable object
(typical)
0.2-mm dia.
0.4-mm dia.
0.7-mm dia.
0.2-mm dia.
0.5-mm dia.
0.8-mm dia.
Model
E39-S65A
E39-S65B
E39-S65C
E39-S65D
E39-S65E
E39-S65F
Contents
One set
(contains Slits for
both the Emitter and
Receiver)
Reflectors
(Reflector required for Retroreflective Sensors) A Reflector is not provided with the Sensor. Be sure to order a Reflector separately.
[Refer to
Dimensions
on
E39-L/F39-L/E39-S/E39-R]
Name
E3Z-R
3 m (100 mm)
(rated value)
4 m (100 mm)
(rated value)
5 m (100 mm)
2.5 m (100 mm)
3.5 m (100 mm)
3 m (100 mm)
1.5 m (50 mm)
700 mm (150 mm)
1.1 m (150 mm)
1.4 m (150 mm)
Sensing distance (typical)*
E3Z-R@K
E3Z-B@1/-B@6
2 m (100 mm)
---
(rated value)
3 m (150 mm)
500 mm (80 mm)
(rated value)
(rated value)
---
---
---
---
---
---
---
---
---
---
---
E3Z-B@2/-B@7
---
Model
E39-R1
E39-R1S
E39-R2
E39-R9
E39-R10
E39-R1K
E39-R3
E39-RS1
E39-RS2
E39-RS3
Quantity
1
1
1
1
1
1
1
1
1
1
Remarks
Reflector
2 m (500 mm)
(rated value)
---
---
---
Fog Preventive
Coating
Small Reflector
Tape Reflector
500 mm (80 mm)
(rated value)
---
---
---
---
2 m (500 mm)
(rated value)
---
---
---
---
•
Retro-reflective
models are not
provided with
Reflectors.
•
The MSR function
is enabled.
Note: The actual sensing distance may be reduced to approximately 70% of the typical sensing distance when using a Reflector other than E39-R1 or E39-R1S.
*1. Refer to
Reflectors
on
E39-L/F39-L/E39-S/E39-R
for details.
*2. Values in parentheses indicates the minimum required distance between the Sensor and Reflector.
Mutual Interference Protection Filter
A Filter is not provided with the Sensor (for the through-beam E3Z-T@@A). Order a Filter separately if required.
