NHD-2.7-12864WDW3
Graphic OLED Display Module
NHD-
2.7-
12864-
WD-
W-
3-
Newhaven Display
2.7” Diagonal Size
128 x 64 Pixel Resolution
Model
Emitting Color: White
+3.3V Power Supply
Newhaven Display International, Inc.
2661 Galvin Ct.
Elgin IL, 60124
Ph: 847-844-8795
Fax: 847-844-8796
www.newhavendisplay.com
nhtech@newhavendisplay.com
nhsales@newhavendisplay.com
Document Revision History
Revision
-
1
Date
6/9/2017
7/25/2017
Description
Initial Release
Update Storage Temperature range
Changed by
ML
ML
Functions and Features
128 x 64 pixel resolution
Built-in SSD1322 controller
Parallel or Serial MPU interface
Single, low voltage power supply
Power options via on-board jumpers
RoHS compliant
[2]
Mechanical Drawing
1
2
3
6 (MAX)
2.50
16.87
P2.54*19 = 48.26
20-⌀1.0
2.50
A
32.69 (V.A.)
30.69 (A.A.)
4-
2.50
Active Area 2.7"
128 x 64 Pixels
B
61.41 (A.A.)
63.41 (V.A.)
74.20
77
82
(0,28)
C
(0,0)
D
The information contained herein is the exclusive property of Newhaven Display International, Inc. and shall not be copied, reproduced, and/or disclosed in any format without permission.
P
1
Common 64
( Row 64 )
Common 127
( Row 1 )
Notes:
1. Display Color: White
2. Interface: 8-bit 68XX/80XX Parallel, 3-/4-wire SPI
3. Controller: SSD1322
O
R
Segment 366,367
( Column 1 )
Segment 112,113
( Column 128 )
Detail A
Common 0
( Row 64 )
R
P
1
Driver IC Memory Mapping
( 256 x 64 in 480 x 128 )
(0,92)
Y
R
A
T
E
I
4
Rev
-
5
Description
Initial release
55.40
6
Date
6/9/17
1
20
A
47.50
42.50
2
B
0.48
0.45
C
0.48
0.45
Detail A
Common 63
( Row 1 )
D
Unit
mm
Gen. Tol.
±0.3
06/09/17
Date
Part Number:
NHD-2.7-12864WDW3
2
3
[3]
4
5
6
Interface Description
Parallel Interface:
Pin No.
1
2
3
Symbol
VSS
VDD
N.C. (BC_VDD)
External
Connection
Power Supply
Power Supply
-
Function Description
Ground
Supply Voltage for OLED module
No Connect by default. Can be configured to provide independent
supply voltage (2.8V – 12V DC) for boost converter.
(refer to On-Board Jumper Options section below)
Data/Command select
signal, D/C=0: Command, D/C=1: Data
6800-interface:
Read/Write select signal, R/W=1: Read, R/W=0: Write
8080-interface:
Active LOW Write signal
6800-interface:
Operation Enable signal, falling edge triggered
8080-interface:
Active LOW Read signal
8-bit bi-directional Data Bus
No Connect by default. Can be configured for external VCC (+15V).
(refer to On-Board Jumper Options table below)
Active LOW Reset signal
Active LOW Chip Select signal
Active LOW Shutdown control pin for boost converter
(pulled HIGH via on-board 15kΩ resistor)
Can be made a No Connect by removing resistor R1.
MPU Interface select signal
MPU Interface select signal
4
5
D/C
R/W or /WR
MPU
MPU
6
E or /RD
MPU
7-14
15
16
17
18
DB0 – DB7
N.C. (VCC)
/RES
/CS
/SHDN (N.C.)
MPU
-
MPU
MPU
MPU
19
20
BS1
BS0
MPU
MPU
Serial Interface:
Pin No.
1
2
3
Symbol
VSS
VDD
N.C. (BC_VDD)
External
Connection
Power Supply
Power Supply
-
Function Description
Ground
Supply Voltage for OLED module
No Connect by default. Can be configured to provide independent
supply voltage (2.8V – 12V DC) for boost converter.
(refer to On-Board Jumper Options table below)
Data/Command select
signal, D/C=0: Command, D/C=1: Data
(tie LOW for 3-wire Serial Interface)
Ground
Serial Clock signal
Serial Data Input signal
No Connect
Ground
No Connect by default. Can be configured for external VCC (+15V).
(refer to On-Board Jumper Options section below)
Active LOW Reset signal
Active LOW Chip Select signal
Active LOW Shutdown control pin for boost converter
(pulled HIGH via on-board 15kΩ resistor)
Can be made a No Connect by removing resistor R1.
MPU Interface select signal
MPU Interface select signal
4
5-6
7
8
9
10-14
15
16
17
18
D/C
VSS
SCLK
SDIN
N.C.
VSS
N.C. (VCC)
/RES
/CS
/SHDN (N.C.)
MPU
Power Supply
MPU
MPU
-
Power Supply
-
MPU
MPU
MPU
19
20
BS1
BS0
MPU
MPU
[4]
Interface Selection
MPU Interface Pin Selections
Pin
Name
BS1
BS0
6800 Parallel
8-bit interface
1
1
8080 Parallel
8-bit interface
1
0
3-wire
Serial
Interface
0
1
4-wire
Serial
Interface
0
0
MPU Interface Pin Assignment Summery
Bus
Interface
8-bit 6800
8-bit 8080
3-wire SPI
4-wire SPI
D7
Data/Command Interface
D6 D5 D4 D3
D2
D1
D[7:0]
D[7:0]
Tie LOW
NC
SDIN
Tie LOW
NC
SDIN
D0
Control Signals
E
R/W /CS
D/C
E
R/W /CS
D/C
/RD /WR /CS
D/C
Tie LOW
/CS Tie LOW
Tie LOW
/CS
D/C
/RES
/RES
/RES
/RES
/RES
SCLK
SCLK
On-Board Jumper Options
Default Jumper Setting
R4
R5
Open
R7
Open
Description
(default)
OLED controller and boost converter + OLED panel are powered from VDD
(pin #2). This allows the full module to be powered by a single low-voltage supply.
Close
Jumper Option #1 - Independent Supply Voltage for Boost Converter
(BC_VDD)
R4
Open
R5
R7
Open
Description
Boost converter + OLED panel are powered from BC_VDD (pin #3). OLED controller is
still powered from VDD (pin #2). This allows for increased efficiency through the boost
converter, by allowing a supply voltage up to +12V at its input, BC_VDD (pin #3).
Close
Jumper Option #2 – External Supply Voltage for OLED Panel
(VCC)
R4
Open
R5
Open
R7
Description
OLED panel is powered from VCC (pin #15) – boost converter is not used.
OLED controller is still powered from VDD (pin #2). This allows for maximum module
efficiency, and drastically reduced total current consumption.
Close
Default Jumper Setting
Jumper Option #1
Jumper Option #2
For detailed electrical information on each jumper option, please see the Electrical Characteristics table below.
[5]
