NTCALUG01A Series
www.vishay.com
Vishay BCcomponents
NTC Thermistors, Standard Lug Sensors
FEATURES
• Easy mounting using ring tongue terminal
• Rugged construction
• Cable of PTFE insulation according to
NEMA HP-3, type E, rated 600 V
RMS (1)
• AEC-Q200 qualified (grade 1)
• UL recognized, file E148885
(UL category XGPU2)
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
Design Tools
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
(1)
Formerly MIL-W-16878/4, type E
Available
• SPICE models available:
www.vishay.com/doc?29178
• NTC curve computation:
www.vishay.com/thermistors/ntc-curve-list/
APPLICATIONS
Suitable for surface sensing applications, especially when a
good electrical insulation and a good thermal contact with
the chassis is required.
QUICK REFERENCE DATA
PARAMETER
Resistance value at 25 °C
(1)
Tolerance on
R
25
-value
(1)
B
25/85
-value
Tolerance on B
25/85
-value
Operating temperature range at:
Zero dissipation
Dissipation factor
(2)
Thermal time constant
(2)
Min. dielectric withstanding
voltage between terminals and lug
Insulation resistance between
terminals and lug at 500 V
DC
Climatic category
(LCT / UCT / days)
Weight
-40 to +150
23
7.5
1500
min. 100
40 / 150 / 56
1.6
g
VALUE
4.7K to 100K
± 1 to ± 5
3435 to 4190
± 0.5 to ± 1.5
UNIT
%
K
%
°C
mW/K
s
V
AC
M
DESCRIPTION
A NTC thermistor chip is soldered to AWG#24 stranded
copper leads with PTFE insulation and insulated with epoxy
coating. The insulated sensor is attached to a tin plated
copper ring lug via a middle buffer layer. The lead wires are
twisted and tinned.
PACKAGING
The thermistors are packed in cardboard boxes; the
smallest packaging quantity is 500 units.
MOUNTING
• By means of M3 (Stud 3-4) screw. Leads to be soldered or
crimped
• The device is suitable for screwing e.g. on metal surface
• The leads are suitable for soldering e.g. on PCB
• Consult Vishay for other screw sizes, lead length,
insulation, connector crimping or other features
Notes
(1)
Other
R
-values, B
25
25/85
-values, and tolerances are available
upon request
(2)
Measured with screw mounted on an aluminum heatsink of
100 cm
2
, thickness 1.5 mm, in still air at T
amb
= +25 °C
Revision: 14-Sep-17
Document Number: 29092
1
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
NTCALUG01A Series
www.vishay.com
Vishay BCcomponents
DIMENSIONS
in millimeters
T
D4
D3
D2
D1
L2
E
L1
L
1
Refer to the
ordering
table
L
2
3.8 ± 1
Ø D
1
3.7 +0.2 / -0
Ø D
2
7.2 ± 0.2
Ø D
3
5.5 +0.3 / -0.2
L3
T
1.0
L
3
15.70 ± 0.3
E
6.2 ± 0.2
D
4
1.12 ± 0.1
ELECTRICAL DATA AND ORDERING INFORMATION
R
25
()
4700
10 000
10 000
10 000
10 000
10 000
10 000
10 000
10 000
10 000
47 000
100 000
100 000
R
25
-TOL.
(± %)
3
1
1
1
1
1
1
2
3
5
3
1
2
B
25/85
(K)
3984
3435
3984
3984
3435
3984
3435
3984
3984
3984
4090
4190
4190
B
25/85
-TOL.
(± %)
0.5
1
0.5
0.5
1
0.5
1
0.5
0.5
0.5
1.5
1.5
1.5
L
1
(mm)
38.1 ± 3.8
38.1 ± 3.8
38.1 ± 3.8
80 ± 5
80 ± 5
160 +10 / -5
160 +10 / -5
38.1 ± 3.8
38.1 ± 3.8
38.1 ± 3.8
38.1 ± 3.8
38.1 ± 3.8
38.1 ± 3.8
DESCRIPTION
NTC Lug01 4.7K 3 % 3984K
PTFE AWG#24 38 mm
NTC Lug01 10K 1 % 3435K
PTFE AWG#24 38 mm
NTC Lug01 10K 1 % 3984K
PTFE AWG#24 38 mm
NTC Lug01 10K 1 % 3984K
PTFE AWG#24 80 mm
NTC Lug01 10K 1 % 3435K
PTFE AWG#24 80 mm
NTC Lug01 10K 1 % 3984K
PTFE AWG#24 160 mm
NTC Lug01 10K 1 % 3435K
PTFE AWG#24 160 mm
NTC Lug01 10K 2 % 3984K
PTFE AWG#24 38 mm
NTC Lug01 10K 3 % 3984K
PTFE AWG#24 38 mm
NTC Lug01 10K 5 % 3984K
PTFE AWG#24 38 mm
NTC Lug01 47K 3 % 4090K
PTFE AWG#24 38 mm
NTC Lug01 100K 1 % 4190K
PTFE AWG#24 38 mm
NTC Lug01 100K 2 % 4190K
PTFE AWG#24 38 mm
SAP MATERIAL AND
ORDERING NUMBER
NTCALUG01A472H
NTCALUG01A103FL
NTCALUG01A103F
NTCALUG01A103F800
NTCALUG01A103F800L
NTCALUG01A103F161
NTCALUG01A103F161L
NTCALUG01A103G
NTCALUG01A103H
NTCALUG01A103J
(1)
NTCALUG01A473H
NTCALUG01A104F
NTCALUG01A104G
UL RECOGNIZED
(Y / N)
N
Y
Y
Y
Y
Y
Y
Y
Y
Y
N
N
N
Note
(1)
NTCALUG01A103J identical to NTCALUGE2C90169 = 2381 645 90169
Revision: 14-Sep-17
Document Number: 29092
2
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
