F-219
PMSS–05–18–K–03.50–D–LUS
PMSDT–02–24–K−03.50−D−LUS
(4.19 mm) .165"
PMSD, PMSDT, PMSS, PMSST SERIES
POWER MATE CABLE ASSEMBLY
DISCRETE WIRE JUMPER CABLE
®
SPECIFICATIONS
For complete specifications
see www.samtec.com?PMSD,
www.samtec.com?PMSDT,
www.samtec.com?PMSS or
www.samtec.com?PMSST
Insulator Material:
Valox 457
Contact Material:
Phosphor Bronze
Plating:
Sn over 50 µ"
(1.27 µm) Ni
Operating Temp Range:
-10 °C to +105 °C (PVC)
®
-40 °C to +105 °C (*Teflon )
Voltage Rating:
22 & 24 AWG =
300 VAC/424 VDC (PVC)
16,18 & 20 AWG =
424 VAC/600 VDC (PVC)
24 AWG =
®
300 VAC/424 VDC (*Teflon )
Wire:
16 to 24 AWG
RoHS Compliant:
Yes
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
PMSD/IPBT
WIRE
CURRENT RATING
GAUGE
(PER PIN)
16 AWG
10.3 A
18 AWG
8.8 A
22 AWG
5.7 A
24 AWG
5.2 A
2 PINS POWERED
Mates with:
IPBT
Plastic latch
Wire range
from 16-24
AWG
Keyed
polarization
Single or
Double end
option
• Individually
shrouded contacts
• Plastic latches
TYPE
PINS
PER ROW
WIRE
GAUGE
K
–K
ASSEMBLED
LENGTH
END
OPTION
LATCH
OPTION
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
= Double Row
PVC Cable
FILE NO. E111594
PMSD
COMPONENTS
• For body, see
www.samtec.com?IPBD
• For contacts, see
www.samtec.com?CC69L
www.samtec.com?CC69R
= Double Row
*Teflon
®
Cable
(24 AWG only)
PMSDT
PMSS
(Standard sizes)
*Only
available for
double row
–02,
–03, –04,
–05,–08,
–10, –15*
(20 AWG/
600 volts)
–16
–18
–206
–22
–24
= Keyed
Polarization
–“XX.XX”
= Wire
Length
in Inches
(88.90 mm)
03.50" min.
= Single End
–S
= Double End
(Latch required)
–D
(4.19)
.165
= Single Row
PVC Cable
ALSO AVAILABLE
(MOQ Required)
• Color coded cables
(*Teflon® N/A)
• Other sizes/pin counts
• 20 AWG/300 Volts
= Single Row
*Teflon
®
Cable
(24 AWG only)
PMSST
No. of Positions
x (4.19) .165
+ (1.02) .040
05
02 01
= Plastic Latch up,
straight
–LUS
–LDS
(5.41)
.213
(7.95)
.313
= Plastic Latch down,
straight
Assembled
Length
± (3.18)
.125
PMSS/PMSST
No. of Positions
x (4.19) .165
+ (1.02) .040
(4.19)
05
.165
02 01
= Plastic Latch up,
crossed
–LUX*
–LDX*
Notes:
For wiring option information
refer to drawing on web.
Teflon
®
cable is intended for
crimp only. Contact Samtec for
solderable cable applications.
Some lengths, styles and
options are non-standard,
non-returnable.
= Plastic Latch down,
crossed
(12.14)
.478
*(PMSD/PMSDT only)
10
06
PMSD/PMSDT
–D–LUS
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
