F-219
EC2–12
EHT–120–01–F–D–SM–LC
(2.00 mm) .0787"
EHT–112–01–L–D
EHT, EC2 SERIES
SHROUDED IDC EJECTOR HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?EHT
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
Mates with:
TCSD
Ten standard
sizes mate with
common 2 mm IDC
cable assemblies
Ejector
latches
(Locks TCSD cable to EHT header)
(9.65)
.380
EJECTOR HEADER CAP
(9.65)
.380
No. of positions x (2.00) .0787
+ (19.89) .783
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
EC2
NO. PINS PER ROW
05, 08, 10, 12, 13,
15, 17, 20, 22, 25
Straight
through-hole,
right-angle, or
surface mount
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
EHT
1
NO. PINS
PER ROW
01
PLATING
OPTION
D
TAIL
OPTION
OTHER
OPTION
ALSO AVAILABLE
(MOQ Required)
• Other platings
05, 08, 10, 12, 13,
15, 17, 20, 22, 25
= Gold flash on post,
Matte Tin on tail
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–F
Leave blank
for Through-hole
= Polarized Position
–“XX”
–SR
–LC
–L
= Right-angle
–RA
= Surface Mount
–SM
= Strain Relief
(Leave Blank for
no strain relief)
No. of positions x (2.00) .0787
+ (13.79) .543
(2.00)
.0787
02
(4.51)
.178
(2.00)
.0787
01
(2.54)
.100
(7.62)
.300
(0.51)
.020
(3.05)
.120
(12.19)
.480
(8.89)
.350
–SM
= Locking Clip
(–SM only)
(Manual placement
required)
(8.26)
.325
(9.53)
x
.375 (6.02)
.237
(8.58)
.338
–P
= (6.50 mm) .256"
DIA Polyimide Film
Pick & Place Pad
(–SM only)
–K
(15.07)
.593
(0.50)
.020 SQ
(9.40)
.370
(3.05)
.120
= Pick & Place Pad
(–SM only)
–P
(2.90)
.114
(2.00)
.0787
= Tape & Reel
(–SM only)
–TR
–SR
–RA
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(Latch removed for clarity)
Due to technical progress, all designs, specifications and components are subject to change without notice.
(1.52)
.060
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
