F-219
PHT–110–04–L–S
PHF–130–01–L–D
PHT–125–01–L–D
(2.54 mm) .100"
PHF–110–04–L–S
PHT, PHF SERIES
PRESS-FIT HEADERS & SOCKETS
PHT Board Mates:
SSW, SSQ, ESW,
ESQ, BCS, BSW,
CES, SLW, PHF, SSM
PHT Cable Mates:
IDSD, IDSS
PHF Board Mates:
TSW, MTSW, MTLW,
EW, ZW, TSS, ZSS,
TSM, TSSH, PHT, DW, HW
= (single row only)
PHT
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
01
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
= Single
Row
–S
–“XXX”
= Polarized
Position
02 thru 50
50
(2.49)
.098
(2.54) .100
SPECIFICATIONS
For complete specifications
see www.samtec.com?PHT
or www.samtec.com?PHF
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (PHT/PHF):
4.8 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C with Gold
(PHF) Insertion Depth:
(3.68 mm) .145" to
(6.35 mm) .250"
RoHS Compliant:
Yes
No. of positions x (2.54) .100
= Double
Row
100
(2.54) (5.02)
.100 .198
99
(0.64)
.025
SQ
–D
LEAD
STYLE
–01
–02
–03
A
(2.54)
.100
(5.08)
.200
(7.62)
.300
(10.16)
.400
(5.84)
.230
A
A
(3.10)
.122
(3.10)
.122
A
(3.10)
.122
(0.31)
.012
A
(3.10)
.122
–04
STYLE
–02, –03 & –04
STYLE
–01
(1.19)
.047
STYLE
–01
STYLE
–02, –03 & –04
PROCESSING
Contact ipg@samtec.com
PHF
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
= (single row only)
01
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Single
Row
–S
–“XXX”
= Polarized
Position
02 thru 50
01
(2.41)
.095
ALSO AVAILABLE
(MOQ Required)
• Other platings
No. of positions x (2.54) .100 + (0.51) .020
= Double
Row
02
(2.54) (4.95)
.100 .195
–D
(2.54) .100
01
LEAD
STYLE
–01
–02
–03
–04
A
(8.50) .335
(11.05) .435
(13.59) .535
(16.13) .635
TOOLING
• Press-Fit
PHT: CAT-PT-PH-1XX-X-X
PHF: CAT-PT-PH-1XX-X-B
For more information, visit
www.samtec.com/tooling
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
A
A
A
A
A
STYLE
–03 & –04
STYLE
–02
STYLE
–01
(1.19)
.047
(0.31)
.012
STYLE
–01
STYLE
.123
–02
(3.12)
STYLE
–03 & –04
