Voltage/frequency ratio - Energy Saving, quadratic
U/f
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
EMC filter
Assembly style
Prospective line Isc
Maximum transient current
Nominal switching frequency
Switching frequency
Asynchronous motor control
profile
Synchronous motor control profileVector control without sensor, standard
Communication port protocol
Type of polarization
Option card
CANopen
Modbus
No impedance Modbus
APOGEE FLN communication card
BACnet communication card
CC-Link communication card
Controller inside programmable card
DeviceNet communication card
Ethernet/IP communication card
Fipio communication card
I/O extension card
Interbus-S communication card
LonWorks communication card
METASYS N2 communication card
Modbus Plus communication card
Modbus TCP communication card
Modbus/Uni-Telway communication card
Multi-pump card
Profibus DP communication card
Profibus DP V1 communication card
Complementary
Product destination
Supply voltage limits
Supply frequency
Network frequency
Continuous output current
Asynchronous motors
Synchronous motors
425...759 V
50...60 Hz (- 5...5 %)
47.5...63 Hz
10 Aat 4 kHz, 500 V 3 phases
10 Aat 4 kHz, 690 V 3 phases
9 Aat 4 kHz, 575 V 3 phases
0.1...500 Hz
1...100 in open-loop mode, without speed feedback
Output frequency
Speed range
1/4
Speed accuracy
Torque accuracy
Transient overtorque
Braking torque
Regulation loop
Motor slip compensation
+/- 10 % of nominal slip 0.2 Tn to Tn torque variation without speed feedback
+/- 15 % in open-loop mode, without speed feedback
130 % of nominal motor torque, +/- 10 %for 60 s
30 % without braking resistor
<= 125 % with braking resistor
Frequency PI regulator
Adjustable
Automatic whatever the load
Can be suppressed
Not available in voltage/frequency ratio (2 or 5 points)
1 LED red presence of drive voltage
<= power supply voltage
Between power and control terminals
With an IP21 or an IP31 kit: 3-strand IEC cableat 104 °F (40 °C), copper 70 °C PVC
Without mounting kit: 1-strand IEC cableat 113 °F (45 °C), copper 70 °C PVC
Without mounting kit: 1-strand IEC cableat 113 °F (45 °C), copper 90 °C XLPE/EPR
With UL Type 1 kit: 3-strand UL 508 cableat 104 °F (40 °C), copper 75 °C PVC
