F-219 SUPPLEMENT
YTW–26–02–T–5–250–050
YTW–20–03–G–Q–400–085
(2.00 mm) .0787"
YTW–12–10–S–6–300–215
YTW SERIES
HIGH-DENSITY BOARD STACKER
SPECIFICATIONS
For complete specifications
see www.samtec.com?YTW
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
RoHS Compliant:
Yes
Lead–Free Solderable:
Wave only
Mates with:
YTQ, YTS, YTE
OTHER
SOLUTIONS
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
(2.00 mm)
.0787" pitch
Choice of 4, 5 or 6 row
YTW
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
TAIL
SPEC
02 thru 50
= 20 µ" (0.51 µm)
Gold contact area,
Gold flash on tail
–G
–S
= Four
Row
–Q
–5
–6
–“XXX”
= Stacker
Height
In inches
(0.13 mm)
.005"
increments
Note:
This Series is non-standard,
non-returnable.
= 30 µ" (0.76 µm)
Gold contact area,
Tin on tail
(Style –01 &
–02 not available)
300
= Five
Row
= Six
Row
Example: –250
= (6.35 mm)
.250"
Other Solutions
2 mm Shunt
See 2SN Series.
No. of
rows
x
(2.00)
.0787
06
= 10 µ" (0.25 µm)
Gold contact area,
Tin on tail
–L
–T
LEAD
STYLE
OAL
(8.20) .323
(9.60) .377
(13.60) .535
(14.10) .555
(15.10) .594
(17.10) .673
(19.10) .751
(11.60) .456
(15.60) .614
(10.08) .397
Low Profile
See YTT &
TMM Series.
= Tin
01
295
Right-angle
Four Row
See TMM Series.
(2.00)
.0787
TYP
POST
No. of positions x (2.00) .0787
(0.51) .020 SQ
(1.27)
.050 MIN
STACKER
HEIGHT
See
OAL
Chart
Shrouded
Four Row
Vertical &
Right-angle
See TMMS Series.
(2.00)
.0787
–01
–02
–03
–04
–05
–06
–07
–09
–10
–11
= Tail Length
In inches
(0.13 mm) .005"
increments
Example: -150
= (3.81 mm) .150"
–“XXX”
= Polarized Position
–“XXX”
ROW OPTION
STACKER HEIGHT
(3.05) .120 MIN
(4.06) .160 MIN
TAIL
(0.00) .000 MIN
–Q
–5 & –6
(2.00) .0787
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
