F-219
FC1–25–02–T–WT
ZF1–25–01–T–WT
FC1–20–01–T
ZF1–10–01–T–WT
(1.00 mm) .0394"
ZF1, FC1 SERIES
FLAT FLEXIBLE CABLE (FFC) SOCKET
Mates with:
FJ
ZF1
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?ZF1
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Sn over 40 µ" (1.02 µm) Ni
Weld Tab:
Phosphor Bronze
Operating Temp Range:
-55 °C to +105 °C
RoHS Compliant:
Yes
NO. OF
POSITIONS
LEAD
STYLE
PLATING
OPTION
WT
–WT
= Weld
Tab
OPTION
–05, –10, –15,
–16, –20, –25, –30
(1.50)
.059
(No. of pins x (1.00) .03937)
+ (5.85) .230
01
= Contact
Bottom
–01
–02
= Matte Tin
–T
= Tape & Reel
Packaging
–TR
(0.25)
.010
= Contact
Top
(10 positions
only)
APPLICATION
ALSO
AVAILABLE
(MOQ Required)
• Other positions
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
(No. of pins x (1.00) .03937) + (7.00) .276
(5.30) .209
(3.00)
.118
(1.00)
.03937
(4.9) .19
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
Note:
Some lengths,
styles and options
are non-standard,
non-returnable.
Mates with:
FJ
FC1
SPECIFICATIONS
NO. OF
POSITIONS
LEAD
STYLE
PLATING
OPTION
OPTIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?FC1
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Sn over 50 µ" (1.27 µm) Ni
ALSO AVAILABLE
Operating Temp Range:
(MOQ Required)
-55 °C to +105 °C
• Low insertion force
Max Cycles:
25 with FJ
contacts available
RoHS Compliant:
Yes
–05, –10, –15, –20 & –25
= Vertical
– 01
– 02
= Tin
–T
= Horizontal
= Locking Clip
(Manual
placement
required)
(–01 only)
–LC
(No. of pins x (1.00) .03937)
+ (2.33) .092
01
(No. of pins x (1.00) .03937)
+ (1.00) .03937
03
(2.77)
.109
02
(1.00) .03937
(1.40)
.055
(1.42)
.056
= Weld Tab
(–02 only)
–WT
–K
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
= (4.00 mm) .158"
DIA Polyimide film
Pick & Place Pad
(–01 only)
– LC OPTION
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
= Tape & Reel
Packaging
(5.18)
.204
(6.35)
.250
(4.09)
.161
(0.30) .012
(1.19)
.047
–TR
– 01
– 02
Note:
Some lengths,
styles and options
are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
