F-219
MTMS–130–02–G–D–100
MTMS–110–02–G–D–100
MTMS–125–51–G–S–200
(1.27 mm) .050"
MTMS, HMTMS SERIES
MODIFIED MICRO TERMINAL
SPECIFICATIONS
For complete specifications
see www.samtec.com?MTMS
or www.samtec.com?HMTMS
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
Mates with:
SMS, SLM, RSM
Position anywhere
in the body with
(3.05 mm) .120"
minimum tail
PROCESSING
Lead-Free Solderable:
Yes
Single row
and double row
Ideal for board
stacking
applications
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
POST
HEIGHT
OPTION
ALSO AVAILABLE
(MOQ Required)
• Other platings
01
thru
50
= Modified Standard
MTMS
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
= Single
Row
–S
= Modified High Temp
HMTMS
= 10 µ" (0.25 µm)
Gold on post,
Gold flash on tail
–G
= Double
Row
–D
= “B”
Dimension
(Specify Post
Height in
inches
(0.13 mm)
.005"
increments)
–“XXX”
–“XXX”
= Polarized
Position
(Specify
position of
omitted pin)
(1.27) .050 x No. of Positions
(2.48)
.098
50
02
01
100
LEAD
STYLE
–01
–02
–25*
–51
–52
–53
–54
–55
–56
–57
–58
–59
–60
OAL
(11.43) .450
(8.13) .320
(8.38) .330
(10.41) .410
(10.80) .425
(12.83) .505
(14.10) .555
(15.49) .610
(15.88) .625
(16.51) .650
(17.91) .705
(19.18) .755
(20.96) .825
B
(Maximum
when C =
(3.05 mm) .120")
(5.84) .230
(2.54) .100
(3.18) .125
(4.83) .190
(5.21) .205
(7.24) .285
(8.51) .335
(9.91) .390
(10.29) .405
(10.92) .430
(12.32) .485
(13.59) .535
(15.37) .605
(2.54)
.100
01
99
(4.98)
.196
HMTMS –D
BODY DESIGN
B
(0.00) .000
MIN
(2.54)
.100
(0.46) .018 SQ
(1.27) .050 TYP
OAL
(3.05)
C
.120
MIN
*
(0.51)
.020
(0.51) .020 DIA
SINGLE ROW
DOUBLE ROW
*Style -25 tail C = (2.67 mm) .105" min
is available.
Note:
This Series is
non-standard, non-returnable.
Tail DIA is .020" (0.51 mm) for min .120" (3.05 mm).
Balance of tail is .018" (0.46 mm) SQ.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
