Technical Data 10192
Effective June 2016
Supersedes January 2014
Up to 400 A Class J ferrule and
knifeblade power distribution fuse blocks
Features and benefits:
•
Combination power distribution block and fuse
block reduces wire connections and total panel
components, using up to 65 percent less panel
space and reducing installation time and labor
by an average of 33 percent when compared
with traditional fuse block/power distribution
block solutions.
A 200,000 amp withstand rating helps achieve
a higher assembly short-circuit current rating
(SCCR) for compliance with NEC
®
sections
110.10, 409.110(4), 409.22, 440.4(B), 670.3(A)(4)
and 670.5.
Optional see-through cover enhances safety
with IP20 finger-safe protection, lockout/tagout
capability and open circuit indication.
Available in 1-, 2- and 3-pole configurations to
meet stocking requirements.
To reduce inventory, assembly time and labor,
modular single-pole blocks snap-together for
tool-less assembly of multiple poles at point of
use.
Blocks rated up to 60 amps feature DIN-Rail
and panel mount versatility, which allows one
product to be used for multiple applications
without incurring additional inventory cost.
•
30 and 60 amp modular ferrule
blocks.
100, 200 and 400 amp
modular knifeblade blocks.
•
•
•
Catalog symbols:
•
•
•
•
•
JM60030-_MW_
JM60060-_MW_
JM60100-_MW_
JM60200-_MW_
JM60400-_MW_
•
Description:
Bussmann
®
series Class J fuse block features
power distribution capability.
This patented design simplifies panel layouts
and uses up to 65 percent less panel space.
Additionally, it lowers inventory costs while
reducing installation time and labor by an average
of 33 percent.
Furthermore, this design uses fewer wire
connections, reducing watts loss and overall
operating temperature of the panel.
Technical Data 10192
Effective June 2016
Class J ferrule and knifeblade power distribution fuse blocks
Specifications:
Fuse class
•
Operating and storage temperature range
•
•
Blocks: -40°C to +120°C
Covers:
•
Non-indicating -40°C to +120°C
•
Class J
Ratings
•
•
•
Indicating -20°C to +90°C
Volts: 600 V
Amps: up to 400 A
Withstand rating (SCCR): 200 kA Sym RMS
Materials
•
•
Base: Thermoplastic
Terminals: Tin-plated aluminum
Agency information
•
Blocks:
•
UL
®
Listed E14853 – IZLT
•
Conductors
•
75°C/90°C Cu/Al (unless otherwise noted)
CSA
®
Certified 47235 — 6225-01
•
•
Covers: UL Listed UL E58836 – JDVS
RoHS compliant
Accessories:
•
Optional IP20 finger-safe covers in indicating and non-indicating
versions. Order one for each pole.
Universal marker labels for 30 and 60 amp blocks, Bussmann
series catalog number TM26CB.
DIN-Rail end stops for blocks rated up to 60 A, Bussmann series
catalog numbers BRKT-ND or BRKT-NDSCRW2.
Poles
•
•
1-, 2-, 3-pole
•
Mounting
•
•
30 and 60 amp blocks DIN-Rail and panel mount
100, 200 and 400 amp blocks panel mount only
Recommended fuses (order separately)
Description
Ultimate protection Low-Peak™ LPJ
time-delay fuses
Advanced protection Limitron™ JKS
fast-acting fuses
High speed Class J DFJ drive fuses
Amps
up to 60
70 to 600
up to 60
70 to 600
up to 600
Data sheet no.
1006
1007
1026
1027
1048
Flammability ratings
•
•
Blocks: UL 94V0, self-extinguishing
Covers: UL 94HB, self-extinguishing
Available two-port lineside lug
for easy daisy-chain wiring
configuration. See catalog
number table for applicable
catalog numbers.
Standard phase barriers
for additional safety
Optional see-through, snap-on
cover for easy visual inspection
Finger grips on cover
for easy removal
Lockout/tagout feature
improves safety
Probe holes for easy testing
without removing cover
Vent slots improve cooling
(no fuse derating necessary)
Optional open fuse indication
speeds troubleshooting
Tool-less interlocking modular design
for easy point-of-use assembly
DIN-Rail or panel mounting on each
pole provides installation flexibility
(DIN-Rail mounting applies to 30
and 60 A blocks only)
Multi-port loadside lug
for power distribution to
multiple branch circuit
connections
Ports on power distribution lugs rated
for dual-wire application, increasing the
number of branch circuit connections
(see catalog number table for details)
Marker label provision
for easy circuit
identification (applies to
30 and 60 A blocks only)
2
Eaton.com/bussmannseries
Class J ferrule and knifeblade power distribution fuse blocks
Technical Data 10192
Effective June 2016
Catalog numbers:
Optional
covers*
Fuse
amp
range
Lineside (conductors per port)
Poles
1
N/A
up to 30
2
3
1
2
3
1
CVR-J-60060
CVRI-J-60060**
35 - 60
2
3
1
2
3
1
CVR-J-60100-M
70 - 100
CVRI-J-60100-M**
2
3
1
CVR-J-60200-M
110-200
CVRI-J-60200-M**
2
3
Cu/Al (1) 250kcmil-6
Cu (2) 2-6
1
2-6
600kcmil
31 (275)
Cu 1/0-14
Al 1/0-12
1
Cu 2-14
Al 2-8
2
Cu 2-14
Al 2-8
1
Cu 2-14
Al 2-8
2
Cu 2-14
Al 2-8
1
Conductors
Ports/
pole
Torque AWG
2-3
4-6
8
10-14
2-4
6-10
12-14
2-3
4-6
8
10-14
2-4
6-10
12-14
N•m
(lb-in)
5.6 (50)
5.1 (45)
4.5 (40)
4.0 (35)
5.6 (50)
4.5 (40)
1.7 (15)
5.6 (50)
5.1 (45)
4.5 (40)
4.0 (35)
5.6 (50)
4.5 (40)
1.7 (15)
Cu (1) 8-14
Cu (2) 12-14***
4
Al (1) 8 Str
Al (1) 10 Sol
Cu (1) 8-14
Cu (2) 12-14***
4
Al (1) 8 Str
Al (1) 10 Sol
Cu 2-14
Al 2-8
1
Cu (1) 8-14
Cu (2) 12-14***
4
Al (1) 8 Str
Al (1) 10 Sol
Loadside (conductors per port)
Conductors
Ports/
pole
Torque
AWG
Cu (1) 8
N•m
(lb-in)
3.4 (30)
Catalog no.
JM60030-1MW14
JM60030-2MW14
JM60030-3MW14
JM60060-1MW12
†
JM60060-2MW12
†
JM60060-3MW12
†
JM60060-1MW14
†
JM60060-2MW14
†
JM60060-3MW14
†
JM60060-1MW24
JM60060-2MW24
JM60060-3MW24
JM60100-1MW14
JM60100-2MW14
JM60100-3MW14
JM60200-1MW16
JM60200-2MW16
JM60200-3MW16
Cu (1) 10-14 2.8 (25)
Cu (2) 12-14 3.4 (30)
Al (1) 8-10
2-3
4-6
8
10-14
Cu (1) 8
3.4 (30)
5.6 (50)
5.1 (45)
4.5 (40)
4.0 (35)
3.4 (30)
Cu (1) 10-14 2.8 (25)
Cu (2) 12-14 3.4 (30)
Al (1) 8-10
Cu (1) 8
3.4 (30)
3.4 (30)
Cu (1) 10-14 2.8 (25)
Cu (2) 12-14 3.4 (30)
Al (1) 8-10
4-6
3.4 (30)
4.0 (35)
2.8 (25)
2.3 (20)
3.4 (30)
4.0 (35)
2.8 (25)
2.3 (20)
3.4 (30)
5.6 (50)
5.0 (45)
4.5 (40)
4.5 (40)
4.0 (35)
4.5 (40)
5.6 (50)
5.0 (45)
4.5 (40)
4.5 (40)
4.0 (35)
4.5 (40)
1/0-3; Cu (2) 4-6 5.6 (50)
4-6; Cu (2) 8
8; Cu (2) 10-14
10-14
250kcmil-1
5.0 (45)
4.5 (40)
4.0 (35)
42 (375)
Cu (1) 4-14
Al (1) 4-8
4
Cu (2) 10-14***
8
Cu 10-14
(2) 10-14
4-6
Cu (1) 4-14
Al (1) 4-8
6
Cu (2) 10-14***
8
10-14
(2) 10-14
2-3
JM60400-1MW16
JM60400-2MW16
1
2
Cu/Al (1) 600kcmil-4
Cu/Al (2) 3/0-4
57 (500)
51 (450)
Cu (1) 2-14
Al (1) 2-8
Cu (2) 8-14***
500kcmil-4
1
Cu (2) 3/0-4
Al (2) (3/0-4
6
4-6
8
(2) 8
10-14
(2) 10-14
2-3
4-6
8
JM60400-3MW16
CVR-J-60400-M
225-400
CVRI-J-60400-M**
JM60400-1MW26
JM60400-2MW26
3
57 (500)
34 (300)
1
2
Cu/Al 350kcmil-6
2
350kcmil-1
42 (375)
JM60400-3MW26
3
2-6
31 (275)
Cu (1) 2-14
Al (1) 2-8
Cu (2) 8-14***
6
(2) 8
10-14
(2) 10-14
*
**
***
†
Order one cover per pole.
With open fuse indication. 90 V minimum and closed circuit required for illumination.
Dual wire rated lugs with same wire size and stranding.
Rated for 75°C Cu/Al conductors. Conductors with higher ratigns may be used with appropriate derating.
Eaton.com/bussmannseries
3
Technical Data 10192
Effective June 2016
Class J ferrule and knifeblade power distribution fuse blocks
30 A dimensions — mm (in)
Catalog nos. JM60030-(poles)MW14 — One port in, four ports out (covers not available)
27.7
1.09
17.2
.68
12.4
.49
89.2
3.51
6.2
.24
87.0
3.43
R2.9
.11
R2.5
.10
29.0
1.14
56.7
2.23
84.3
3.32
6.5
.26
58.2
2.29
46.2
1.82
16.2
.64
30.2
1.19
4
Eaton.com/bussmannseries
Class J ferrule and knifeblade power distribution fuse blocks
Technical Data 10192
Effective June 2016
60 A dmensions — mm (in)
Catalog nos. JM60060-(poles)MW12 — Two ports in, one port out
12.7
.50
25
.98
31.3
1.23
9
.35
9
.35
19.8
.78
6.5
.26
5.3
.21
93.7
3.69
R2.9
.11
R2.5
.10
38.9
1.53
76.6
3.02
114.3
4.50
65.3
2.57
53.3
2.10
15.8
.62
18.3
.72
37.7
1.48
With optional cover, see catalog number table on page three for available versions
119 [4.7]
Eaton.com/bussmannseries
5
