F-219
RPCU–G–00.25–BMS–AM
RPBU–01–S–A–RA
RPBU, RPCU SERIES
IP68 SEALED USB PANEL MOUNT
Mates with:
RCU (Single Port only)
SPECIFICATIONS
For complete specifications
see www.samtec.com?RPBU
Insulator Material:
Black Liquid Crystal Polymer
Contact:
Phosphor Bronze
Current Rating:
4.2 A per pin
(1 pin powered)
Operating Temp Range:
-20 °C to +80 °C
Seal:
Silicone
Lead-Free Solderable:
Yes
RPBU
NO. OF
PORTS
PLATING
TYPE
LEAD
STYLE
OPTION
= Single Port
–01
–02
= 30 µ" (0.76 µm)
Gold on contact,
Matte tin on tail
–S
= USB A Type
–A
–B
= Vertical
Through-hole
–VT
= USB B Type
= Dual Port
(–A only)
(45.20) 1.780
(20.50)
.807
A
(16.80)
.661
= Right-angle
–RA
= Locking
Clip
(–VT only)
–LC
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
TYPE –B
(36.20) 1.425
(17.06) .672
TYPE -A
B
C
NO. OF
PORTS
–01
A
(48.15)
1.896
(69.80)
2.748
B
(39.10)
1.539
(60.75)
2.392
C
(20.01)
.788
(42.00)
1.654
DUST CAPS
• DCA-RPBU-01-01-A
• DCA-RPBU-02-01-A
• DCA-RPBU-01-01-B
(3.51)
.138
DIA
(9.53)
.375
(0.65) .026
(0.65) .026
–02
–B–VT
–B–RA
–A–VT
–A–RA
Mates with:
RCU
RPCU
PLATING
SPECIFICATIONS
For complete specifications
see www.samtec.com?RPCU
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Operating Temp Range:
-20 °C to +80 °C
Shield Material:
Phosphor Bronze
Wire:
20 AWG (Power)
25 AWG (Signal)
28 AWG (Drain)
CABLE
LENGTH
END 1
OPTION
END 2
OPTION
= 30 µ" (0.76 µm)
Gold on contact,
Nickel on shell
–G
= (0.25 m) 9.84" Cable
–00.25
–00.50
= USB A Type,
Sealed
–AMS
–BMS
= USB A Type,
Not Sealed
–AM
–BM
–BC
= (0.50 m) 19.68" Cable
Standard lengths
(Assembled Length
= Cable Length
+ (42.8 mm) 1.69")
Cable Length + (42.8) 1.69
= USB B Type,
Sealed
= USB B Type,
Not Sealed
= Blunt Cut
DUST CAPS
• DCA-RPBU-01-01-A
• DCA-RPBU-01-01-B
(20.00)
.787
(15.90)
.626
ALSO
AVAILABLE
(MOQ Required)
• Other wire lengths
–AMS
–AM
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
