F-219
TML–108–02–G–D–SM
TML–120–01–L–D–RA
TML–132–02–L–D–SM
(1.27 mm) .050"
TML SERIES
SHROUDED MICRO HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?TML
Insulator Material:
Black Liquid Crystal Polymer
Insulation Resistance:
5000 MW min
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
Mates with:
SMS, RSM
Surface mount,
right-angle and
through-hole designs
APPLICATIONS
SMS
(10.92)
.430
TML
(11.40)
.449
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.15 mm) .006" max*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
TML
RSM
(1.27 mm)
.050"
(2.54 mm)
.100"
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
TML
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
D
TAIL
OPTION
OTHER
OPTION
FILE NO. E111594
ALSO AVAILABLE
(MOQ Required)
• Other sizes
• Other platings
(Standard sizes)
05, 08,
10, 20, 32
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= 10 µ" (0.25 µm)
Gold on post,
Gold flash on tail
–L
= Right-angle
–RA
–“XXX”
= Polarized
position
(Specify
position of
omitted pin)
–G
= Surface Mount
(For locking clip add –LC)
(1.27)
.050
–SM
02
(1.27) .050 x No. of
Positions + (3.18) .125
(1.27) .050 x No. of
Positions + (0.64) .025
(1.27) .050
(9.40)
.370
(6.60)
.260
(0.76)
.030
(2.54)
.100
POST
LEAD
HEIGHT
STYLE
(A)
(3.05)
–01
.120
–02
–03
(5.84)
.230
(4.32)
.170
A
Surface Mount
(1.75)
.069
(3.68)
.145
(3.05)
.120
01
(3.56)
.140
(0.46) .018 SQ TYP
(2.54)
.100
(9.65)
.380
(7.62)
.300
A
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(0.38)
.015
(2.67)
.105
(0.51) .020 DIA TYP
Through-Hole
(1.14)
.045
(2.54)
.100
Right-angle
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
