Note: Unbalanced is measured between ground-signal-ground conductors. Balanced is measured between conductors within a pair.
C
Environmental
D
IS
UL File No.: E42769, Style No: 21008
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
O
N
TI
Capacitance:
Inductance:
Propagation Delay:
Velocity of Propagation:
ED
N
U
Temperature Rating:
-20°C to +80°C
Flammability Rating:
USA: UL VW-1 EU: IEC 332-1 & -3
fo
Marking:
rt
Color: Blue / Off-White Pairs
119
Ω
14.6 pF/ft [ 47.9 pF/m ]
0.21 μ"/ft [ 0.69 μ"/m ]
1.73 ns/ft [ 5.68 ns/m ]
59%
he
Insulation:
N
Physical
ew
Se
rie
TS-0762-D
Sheet 1 of 2
s
3M
™
Twisted Pair Flat Cable
.050" 28 AWG Stranded, Mass Terminable, Halogen Free Polyolefin
Number of
Conductors
10 (5 pair)
14 (7 pair)
16 (8 pair)
20 (10 pair)
24 (12 pair)
26 (13 pair)
34 (17 pair)
40 (20 pair)
50 (25 pair)
60 (30 pair)
64 (32 pair)
A
2100 Series
Dimension B
0.450 ± .010 [ 11.43 ]
0.650 ± .010 [ 16.51 ]
0.750 ± .010 [ 19.05 ]
0.950 ± .010 [ 24.13 ]
1.250 ± .010 [ 31.75 ]
1.150 ± .010 [ 29.21 ]
3M Part
Number
2100/10TP
2100/14TP
2100/16TP
2100/20TP
2100/24TP
2100/26TP
2100/34TP
2100/40TP
2100/50TP
2100/60TP
2100/64TP
Dimension A
0.50 [ 12.7 ]
0.70 [ 17.8 ]
0.80 [ 20.3 ]
1.00 [ 25.4 ]
1.20 [ 30.5 ]
1.30 [ 33.0 ]
1.70 [ 43.2 ]
2.00 [ 50.8 ]
2.50 [ 63.5 ]
3.00 [ 76.2 ]
3.20 [ 81.3 ]
1.650 ± .015 [ 41.91 ]
1.950 ± .015 [ 49.53 ]
2.450 ± .015 [ 62.23 ]
Section thru Twist
.100 [ 2.54 ] Ref
Blue
( See note 1 )
-2
34
4
fo
.050 Typ
[ 1.27 ]
rt
Off
White
28 AWG 7 X 36 ( 7 X 0.127) Tinned
Stranded Copper Conductors
Off-White Carrier
Section thru Flat
ee
TS
B
he
N
ew
.07 Ref
[ 1.8 ]
.043 .003
[ 1.09 ]
H
Inch
[mm]
50 8 mm
[2 ]
-S
ED
F1
0
.0
Inch
±.1
Tolerance Unless Noted
.00
±.01
.000
±.005
Ordering Information
N
TI
N
Note:
1. Blue edge conductor designates wire one of pair one.
2. Dimension B pertains to bonded area only.
500 18 mm
[ 19.7 ]
See note 4
U
[ ] Dimensions for Reference Only
C
O
2100/XX TP XX
Number of Conductors
(See Table)
Blank = Standard
SF = Splice Free
D
IS
Note:
3. Available in standard lengths of 30 m and 100 m per roll, please specifiy when ordering.
4. Standard product has a 50 mm flat on 500 mm repeat (2" bond on 19.7" repeat). For special
requirements, please contact your 3M sales representative. The flat can be specified anything
over 25 mm (1"), the repeat can be specified from 16.5 cm to 1.2 m (6.5" to 48").
0
2.950 ± .015 [ 74.93 ]
3.150 ± .015 [ 80.01 ]
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
Se
rie
TS-0762-D
Sheet 2 of 2
s
Important Notice
Warranty; Limited Remedy; Limited Liability.
This product will be free from defects in material and manufacture for a period of one (1) year from the time of purchase.
3M MAKES NO OTHER WARRANTIES
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
If this product is defective within the
warranty period stated above, your exclusive remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the 3M product.
Except
where prohibited by law, 3M will not be liable for any indirect, special, incidental or consequential loss or damage arising from this 3M product, regardless of
All statements, technical information, and recommendations related to 3M’s products are based on information believed to be reliable, but the accuracy or completeness
is not guaranteed. Before using this product, you must evaluate it and determine if it is suitable for your intended application. You assume all risks and liability associated
with such use. Any statements related to the product which are not contained in 3M’s current publications, or any contrary statements contained on your purchase order
shall have no force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
TI
N
U
ED
-S
ee
TS
-2
34
4
fo
rt
3M is a trademark of 3M Company.
he
N
ew
H
F1
0
0
Se
rie
s
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
