EV-AD5443/46/53SDZ: DescriptionData conversion IC development tool EVALUATION BOARD IC; CategoryEmbedded solution Engineering tools Analog and digital IC development tools Data conversion IC development tools; File Size703KB，25 Pages; ManufacturerADI; Websitehttps://www.analog.com; Environmental Compliance

Download Datasheet Parametric View All

EV-AD5443/46/53SDZ Overview

Data conversion IC development tool EVALUATION BOARD IC

EV-AD5443/46/53SDZ Parametric

Parameter Name	Attribute value
Maker	ADI
Product Category	Data conversion IC development tools
product	Evaluation Boards
type	DAC
Working power voltage	2.5 V to 5.5 V
Encapsulation	Bulk
Description/Function	Combination evaluation board
series	AD5443
Interface Type	Serial
used for	AD5443/5446/5453
Maximum operating temperature	+ 125 C
Minimum operating temperature	- 40 C
Factory packaging quantity	1
unit weight	163.293 g

Preview

Download Datasheet

View All

Data Sheet

FEATURES

8-/10-/12-Bit High Bandwidth

Multiplying DACs with Serial Interface

AD5426/AD5432/AD5443

GENERAL DESCRIPTION

The

AD5426/AD5432/AD5443

are CMOS 8-, 10-, and 12-bit

current output digital-to-analog converters (DACs), respectively.

These devices operate from a 2.5 V to 5.5 V power supply,

making them suitable for battery-powered applications and

many other applications.

These DACs use a double buffered, 3-wire serial interface that is

compatible with SPI, QSPI™, MICROWIRE, and most DSP

interface standards. In addition, a serial data out pin (SDO)

allows for daisy-chaining when multiple packages are used.

Data readback allows the user to read the contents of the DAC

and latches are filled with 0s and the DAC outputs are at zero scale.

As a result of manufacturing on a CMOS submicron process,

the parts offer excellent 4-quadrant multiplication characteristics

with large signal multiplying bandwidths of 10 MHz. The applied

external reference input voltage, V

REF

, determines the full-scale

output current. An integrated feedback resistor, R

, provides

temperature tracking and full-scale voltage output when combined

with an external current to voltage precision amplifier.

The

AD5426/AD5432/AD5443

DACs are available in small,

10-lead MSOPs.

The

EV-AD5443/46/53SDZ

evaluation board is available for

evaluating DAC performance. For more information, see the

UG-327

evaluation board user guide.

2.5 V to 5.5 V supply operation

50 MHz serial interface

10 MHz multiplying bandwidth

2.5 MSPS update rate

INL of ±1 LSB for 12-bit DAC

±10 V reference input

Low glitch energy < 2 nV-s

Extended temperature range −40°C to +125°C

10-lead MSOP

Pin-compatible 8-, 10-, and 12-bit current output DACs

Guaranteed monotonic

4-quadrant multiplication

Power-on reset with brownout detection

Daisy-chain mode

Readback function

0.4 µA typical power consumption

APPLICATIONS

Portable battery-powered applications

Waveform generators

Analog processing

Instrumentation

Programmable amplifiers and attenuators

Digitally controlled calibration

Programmable filters and oscillators

Composite video

Ultrasound

Gain, offset, and voltage trimming

REF

FUNCTIONAL BLOCK DIAGRAM

AD5426/

AD5432/

AD5443

8-/10-/12-BIT

R-2R DAC

OUT

DAC REGISTER

POWER-ON

RESET

INPUT LATCH

SYNC

SCLK

SDIN

CONTROL LOGIC AND

INPUT SHIFT REGISTER

SDO

03162-001

GND

Figure 1.

Protected by U.S. Patent No. 5,689,257.

Document Feedback

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

Technical Support

www.analog.com

Rev. H

Information furnished by Analog Devices is believed to be accurate and reliable. However, no

responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other

rights of third parties that may result from its use. Specifications subject to change without notice. No

license is granted by implication or otherwise under any patent or patent rights of Analog Devices.

Trademarks and registered trademarks are the property of their respective owners.

AD5426/AD5432/AD5443

TABLE OF CONTENTS

Features .............................................................................................. 1

Applications ....................................................................................... 1

General Description ......................................................................... 1

Functional Block Diagram .............................................................. 1

Revision History ............................................................................... 2

Specifications..................................................................................... 3

Timing Characteristics ................................................................ 5

Absolute Maximum Ratings ............................................................ 6

ESD Caution .................................................................................. 6

Pin Configuration and Function Descriptions ............................. 7

Typical Performance Characteristics ............................................. 8

Terminology .................................................................................... 14

Theory of Operation ...................................................................... 15

Data Sheet

Circuit Operation ....................................................................... 15

Single-Supply Applications ....................................................... 17

Adding Gain ................................................................................ 17

DACs Used as a Divider or Programmable Gain Element ... 18

Reference Selection .................................................................... 18

Amplifier Selection .................................................................... 18

Serial Interface ............................................................................ 20

PCB Layout and Power Supply Decoupling................................ 22

Overview of the AD5426/AD5432/AD5443 and Related DACs .. 23

Outline Dimensions ....................................................................... 24

Ordering Guide .......................................................................... 24

REVISION HISTORY

9/15—Rev. G to Rev. H

Deleted Positive Output Voltage Section and Figure 45;

Renumbered Sequentially.............................................................. 17

Changes to Adding Gain Section ................................................. 17

Changed Overview of AD54xx and AD55xx Devices Section

to Overview of the AD5426/AD5432/AD5443 and Related

DACs Section .................................................................................. 23

Changes to Ordering Guide .......................................................... 24

6/13—Rev. F to Rev. G

Change to General Description Section ........................................ 1

Changes to Ordering Guide .......................................................... 24

7/12—Rev. E to Rev. F

No Change to Content, Changed V

Values in 7/12 Revision

History Only ...................................................................................... 2

7/12—Rev. D to Rev. E

Changed V

= 3 V to V

= 2.5 V ............................. Throughout

Changes to Table 2 ............................................................................ 4

Changes to Table 4 ............................................................................ 7

Change to Daisy-Chain Mode Section ........................................ 20

Change to Ordering Guide ............................................................ 24

4/12—Rev. C to Rev. D

Changed V

= 2.5 V to V

= 3 V ............................. Throughout

Changes to General Description Section ...................................... 1

Deleted Microprocessor Interface Section, ADSP-21xx to

AD5426/AD5432/AD5443 Interface Section, Figure 51,

Figure 52, Table 11, ADSP-BF5x to AD5426/AD5432/AD5443

Interface Section, Figure 53 and Figure 54; Renumbered

Sequentially ..................................................................................... 21

Deleted 80C51/80L51 to AD5426/AD5432/AD5443 Interface

Section, Figure 55, MC68HC11 Interface to AD5426/AD5432/

AD5443 Interface Section, Figure 56, MICROWIRE to

AD5426/AD5432/AD5443 Interface Section, Figure 57,

PIC16C6x/7x to AD5426/AD5432/AD5443, and Figure 58 .... 22

Deleted Evaluation Board for the AD5426/AD5432/AD5443

Series of DACs Section, Operating the Evaluation Board

Section, and Power Supplies Section ........................................... 23

Deleted Figure 59 and Figure 60................................................... 24

Updated Outline Dimensions ....................................................... 24

Changes to Ordering Guide .......................................................... 24

Deleted Figure 61............................................................................ 25

Deleted Figure 62............................................................................ 26

2/09—Rev. B to Rev. C

Changes to Low Power Serial Interface Section and Daisy-

Chain Mode Section....................................................................... 20

Updated Outline Dimensions ....................................................... 28

11/08—Rev. A to Rev. B

Changes to Ordering Guide .......................................................... 28

5/05—Rev. 0 to Rev. A

Updated Format .................................................................. Universal

Changes to Specifications .................................................................3

Changes to Figure 42...................................................................... 16

Change to Figure 45 ....................................................................... 17

Change to Figure 46 ....................................................................... 18

Changes to Table 7, Table 8, and Table 9 ..................................... 19

Additions to Microprocessor Interface Section.......................... 21

2/04—Revision 0: Initial Version

Rev. H | Page 2 of 24
