Industrial System
w w w.ieiworld.com
IKARPC-07A
Features
●
●
●
●
Vehicle Computer Series
7” sunlight readable TFT LCD with projected capacitive touchscreen
Optional HSUPA/GPRS/GSM, Wi-Fi and Bluetooth
Built-in GPS receiver
Built-in OBD-II/J1939
3.75G/HSUPA
Bluetooth
Wi-Fi
Fanless
Operating
Temperature
High
Brightness
Touchscreen
Camera
OBD-II
Specifications
Model Name
Color
Chassis
Dimensions (WxHxD) (mm)
System Fan
Chassis Construction
Size
Resolution
Brightness (cd/m )
2
IKARPC-07A-A9
Black C + Silver
210 x 154 x 28
Fanless
PC + ABS plastic
7"
1024 × 3 (RGB) × 600
500
700:1
0.05 (W) × 0.15 (H)
130° (H) / 140° (V)
Projected capacitive touch with USB interface
Freescale™ i.MX 6 Cortex™-A9 (quad-core, 1.0 GHz)
N/A
On-board 1 GB SDRAM
1 x SD slot (supports SD 2.0, max. 32 GB)
On-board 8 GB iNAND flash
N/A
On-board Wi-Fi 802.11a/b/g/n
Bluetooth 3.0+HS
PCIe Mini WCDMA/HSDPA/HSUPA (Built-in)
13.56 MHz ISO4443 A/B, read-write capable,
ISO 14443A (MIFARE), ISO 14443B (FeliCa)
On board GPS
1 x 10/100 LAN
1 x OBD-II/J1939
1 x USB 2.0
1 x Audio line-out (R+L)
1 x Audio line-in
1 x RS-232
4-bit digital I/O (2-bit input, 2-bit output)
Video input
N/A
2
N/A
1 x on board SIM card slot
1 x GPS, 1 x WWAN
1 x Full-size PCIe Mini (reserved for WWAN)
1 x Speaker (2 W)
5-megapixel CMOS
Power/BT/Wi-Fi/3G
1 x Power botton
Cigarette lighter power cable, DC 9 V~30 V
12 V @ 0.8 A
VESA 75
-20°C ~ 60°C with air flow
-30°C ~ 70°C
10% ~ 95%, non-condensing
Half-sine wave shock 5G, 11ms, 3 shocks per axis
MIL-STD-810F 514.5C-2 (with SSD)
0.9 kg/2.1 kg
CE/FCC/E-Mark/IP 54 compliant front panel
Android 4.2.2
IKARPC-07A-BT
Black C + Silver
210 x 154 x 28
Fanless
PC + ABS plastic
7"
1024 × 3 (RGB) × 600
500
700:1
0.05 (W) × 0.15 (H)
130° (H) / 140° (V)
Projected capacitive touch with USB interface
Intel® Atom™ processor E3826 (dual-core, 1.46 GHz, 7W)
SoC
On-board 2 GB SDRAM
1 x Micro SD slot (supports SD 2.0, max. 32 GB)
N/A
1 x mSATA (SATA 3Gb/s) optional
PCIe Mini Wi-Fi 802.11a/b/g/n/ac (optional)
BT 4.0/3.0+HS (combo with WLAN optional module)
PCIe Mini WCDMA/HSDPA/HSUPA (optional)
N/A
On board GPS
1 x GbE LAN
1 x OBD-II/J1939
1 x USB 2.0
1 x Audio line-out (R+L)
1 x Audio line-in
1 x RS-232
4-bit digital I/O (2-bit input, 2-bit output)
N/A
1
1
1 x HDMI
2 x on board SIM card slot
1 x GPS, 1 x WWAN
1 x Full-size PCIe Mini (reserved for mSATA module),
1 x Full-size PCIe Mini (reserved for WWAN module),
1 x Half-size PCIe Mini (reserved for WLAN module)
1 x Speaker (2 W)
2-megapixel CMOS
Power/HDD/Wi-Fi/3G
1 x Power botton
Cigarette lighter power cable, DC 9 V~30 V
12V @ 1.25 A
VESA 75
-20°C ~ 60°C with air flow
-30°C ~ 70°C
10% ~ 95%, non-condensing
Half-sine wave shock 5G, 11ms, 3 shocks per axis
MIL-STD-810F 514.5C-2 (with SSD)
0.9 kg/2.1 kg
CE/FCC/E-Mark/IP 54 compliant front panel
Microsoft® Windows® Embedded 8,
Microsoft® Windows® Embedded Standard 7 E
Display
Contrast Ratio
Pixel Pitch (mm)
Viewing Angle (H/V)
Touchscreen
CPU
Motherboard
Chipset
System Memory
SD Card
Storage
Flash
mSATA
WLAN
Bluetooth
Communication
WWAN
RFID
GPS
20-pin Connector
24-pin Connector
I/O Interfaces
8-pin Connector
USB 3.0
USB 2.0
Display
SIM
Antenna
Expansions
Multimedia
LED Indicator &
Button
Power
PCIe Mini
Speaker
Camera
Indicator
Button
Power Input
Consumption
Mounting
Operating Temperature
Storage Temperature
Reliability
Humidity
Operating Shock
Operating Vibration
Weight (Net/Gross)
Safety/EMC
OS
Supported OS
IKARPC-07A-2018-V11
Industrial System
w w w.ieiworld.com
Fully Integrated I/O
IKARPC-07A-A9 Rear view
Power Switch
USB 2.0
SD Card Slot
Access Panel
SIM Card Slot
Access Panel
Power Input
3.75G Antenna
GPS Antenna
Video Input
(8-pin)
I/O Connector 2 (24-pin)
I/O Connector 1 (20-pin)
USB 2.0
Dimensions
(Unit: mm)
IKARPC-07A-BT Rear view
Power Switch
USB 3.0
microSD Card Slot
Access Panel
SIM Card Slot
Access Panel
USB 2.0
Power Input
3.75G Antenna
(Optional)
GPS Antenna
HDMI
I/O Connector 2 (24-pin)
I/O Connector 1 (20-pin)
IKARPC-07A-A9
IKARPC-07A-BT
Ordering Information
Part No.
IKARPC-07A-A9-R11
IKARPC-07A-BT-
E3/2G-R11
Description
7” 500 cd/m2 1024 x 600, In Vehicle Panel PC with Freescale iMX6 Qual core Processor,1.0GHz , 1GB SDRAM , 8GB EMMC Flash, 5M Camera,RFID Reader,
OBDII, HSUPA , GPS, WIFI/BT, ROHS
7” 500 cd/m2 1024 x 600 In Vehicle Panel PC with Intel® Atom E3826 1.46GHz, 7W TDP, 2GB DDR3L on board memory, OBDII, GPS on board, 2M Camera,
ROHS
Options
Item
Power adapter
Cigarette lighter
power cable
VESA mount stand
OBD-II cable
Part No.
IVIPOWER-4PIN-R10
32002-004000-100-RS
IVI-MK03-R10
32025-003400-100-RS
Description
Power adapter with 4-pin transfer cable, RoHS
Round cable, power cable, car cigarette lighter cable, 2000 mm, 18 AWG, (A) cigarette lighter (5 A 250 V)+ ψ3 green LED, (B)
MOLEX 5557-0400 P=4.2, SHANGHAI YING YU, RoHS
138mm 75x75 VESA mount stand
Round cable, OBD-II cable, 2000 mm, 24 AWG, (A) OBD-II 16P male, (B) D-sub 9P female, one piece package with label, NIAN
YEONG, RoHS
IKARPC-07A-A9 Series
Item
Part No.
I/O connector
1 cable (20-pin)
I/O connector
2 cable (24-pin)
Video input cable (8-pin)
32024-002400-100-RS
32024-002900-100-RS
32010-001700-100-RS
Description
Round cable, integration cable, I/O cable, 300 mm, 24 AWG, (A)terminal block 3P P=5.08, (B)USB A type female+2 NUT, (C)PCB
jack: RJ-45 8P8C, (D)D-sub 9P male, (E)MOLEX 5557-2000 P=3.0, one piece package with label, RoHS
Round cable, integration cable, I/O cable, 300 mm, 22 AWG, (A)terminal block 8P, P=5.08, (B)MOLEX 43025-2400 P=3.0, (C)D-sub
9P male, (D)phone jack 3.5_3P+NUT, (E)phone jack 3.5_5P+NUT, one piece package with label, RoHS
Round cable, video cable, 300 mm, 26 AWG, (A)MOLEX 43025-0800 P=3.0, (B)RCA jack, yellowx4, RoHS
IKARPC-07A-BT Series
Item
Part No.
I/O connector
1 cable (20-pin)
I/O connector
2 cable (24-pin)
OS: Windows
Embedded 7 (DVD-ROM)
OS: Windows
Embedded 8 (DVD-ROM)
Wireless kit
WWAN kit
32024-003000-100-RS
32124-003700-100-RS
IKARPC-07A-BT-
WES7P-R10
IKARPC-07A-WE8S-R10
IKARPC-WIFI-KIT01-R10
IKARPC-3G-KIT02-R10
Description
Round cable, integration cable, I/O cable, 300 mm, 24 AWG (A)terminal block 3P P=5.08, (B)USB A type female+2 NUT, (C)PCB
jack: RJ-45 8P8C, (D)D-sub 9P male, (E)MOLEX 5557-2000 P=3.0, one piece package with label, RoHS
Round cable, integration cable, I/O cable, 300 mm, 22 AWG, (A)terminal block 8P P=5.08, (B)MOLEX 43025-2400 P=3.0, (C)D-sub
9P male, (D)phone jack 3.5_3P+NUT, (E)phone jack 3.5_5P+NUT, one piece package with label, RoHS
OS image with Windows® Embedded Standard 7 E for IKARPC-07A-BT Series, DVD-ROM, RoHS
OS image with Windows® Embedded Standard 8 E for IKARPC-07A-BT Series, WE8S license label, DVD-ROM, RoHS
1T1R wifi module kit for embedded system, IEEE 802.11b/g/n, 1 x wifi module, RoHS
F260 3.75G module kit for embedded system, with BT V2.1, RoHs
Packing List
Product
IKARPC-07A-A9
Item
Power Cable
GPS/GSM Antenna
Power Cable
IKARPC-07A-BT
Screw pack
GPS/GSM Antenna
Part No.
32002-001900-100-RS
32506-000100-100-RS
32002-001900-100-RS
44045-020031-RS
32506-000100-100-RS
Qty
1
1
1
2
1
Description
Round cable, power cable, 3000mm, RoHS
Integration antenna, GPS/GSM, RG 174, 5000mm/5000mm, PPF-5423SA5X-999, Magnetic mount:
φ55x22mm, 1575.42MHz/850MHz/900MHz/1800MHz/1900MHz, SMA plug x 2
Round cable, power cable, 3000mm, RoHS
Screw pack
Integration antenna, GPS/GSM, RG 174, 5000mm/5000mm, PPF-5423SA5X-999, Magnetic mount:
φ55x22mm, 1575.42MHz/850MHz/900MHz/1800MHz/1900MHz, SMA plug x 2
IKARPC-07A-2018-V11
