Part Number:
Status:
Overview:
Description:
1511200320
Active
Milli-Grid Connector System
2.00mm Pitch Milli-Grid Header, Surface Mount, Dual Row, Right-Angle, 0.75µm Gold
(Au) Plating, without Peg, without Pick and Place Tape, 20 Circuits, Low-Halogen, Tape
and Reel
Documents:
3D Model
Drawing (PDF)
Product Specification PS-151117-0001-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
CURRENT-MAX-NUMERIC
Overview
PITCH-MATING-NUMERIC
Product Literature Order No
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
First Mate / Last Break
Flammability
Glow-Wire Capable
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Packaging Specification PK-151120-3000 (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/88/2018 (15
January 2019)
Halogen-Free
Status
Low-Halogen
For more information, please visit Contact US
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
LR19980
E29179
PCB Headers
151120
Board-to-Board, Signal, Wire-to-Board
2.0
Milli-Grid Connector System
2.00
987651-5501
Milli-Grid
889056764049
No
20
20
Black
No
94V-0
Under Evaluation
No
None
Yes
Copper Alloy
Gold over Nickel
Tin over Nickel
Liquid Crystal Polymer
1.151/g
2
Right Angle
No
None
Embossed Tape on Reel
2.00mm
2.00mm
0.750µm
2.000µm
Yes
Yes
Yes
No
Yes
Search Parts in this Series
151120 Series
Mates With
Milli-Grid Receptacle Housing (Low-
Halogen) 151192 <br>Milli-Grid Receptacle
Housing 51110 <br>Milli-Grid PCB
Receptacles 78787 , 78788 , 79107 , 79109
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
-55° to +105°C
Surface Mount
2.0A
125V AC
011
SMC&WAVE
001
265
PK-151120-3000
PS-151117-0001-001
SD-151120-0001
