SS12 - SS115
Taiwan Semiconductor
CREAT BY ART
1A, 20V - 150V Surface Mount Schottky Barrier Rectifiers
FEATURES
- Low power loss, high efficiency
- Ideal for automated placement
- Guardring for overvoltage protection
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
DO-214AC (SMA)
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound, UL flammability classification rating 94V-0
Moisture sensitivity level: level 1, per J-STD-020
Part No. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
Indicated by cathode band
Weight:
0.066 g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@ 1 A, T
J
=25°C
@ 1 A, T
J
=100°C
T
J
=25°C
Maximum reverse current @ rated V
R
Voltage rate of change (Rated V
R
)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
T
J
=100°C
T
J
=125°C
dV/dt
R
θJL
R
θJA
T
J
T
STG
- 55 to +125
I
R
6
-
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
SS
12
20
14
20
SS
13
30
21
30
SS
14
40
28
40
SS
15
50
35
50
1
40
SS
16
60
42
60
SS
19
90
63
90
SS
110
100
70
100
SS
115
150
105
150
UNIT
V
V
V
A
A
V
F
0.5
0.4
0.2
0.75
0.65
5
-
10000
28
88
0.8
0.7
0.1
-
2
0.95
0.85
V
mA
V/μs
°C/W
- 55 to +150
- 55 to +150
°C
°C
Document Number: DS_D1411020
Version: P15
SS12 - SS115
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
PART NO.
SUFFIX
PACKING CODE
R3
R2
SS1xx
(Note 1)
H
M2
F3
F2
F4
N/A
E3
E2
G
PACKING CODE
SUFFIX
PACKAGE
SMA
SMA
SMA
Folded SMA
Folded SMA
Folded SMA
Clip SMA
Clip SMA
PACKING
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
1,800 / 7" Plastic reel
7,500 / 13" Plastic reel
Note 1: "xx" defines voltage from 20V (SS12) to 150V (SS115)
EXAMPLE
PREFERRED
PART NO.
SS16HR3G
PART NO.
SS16
PART NO.
SUFFIX
H
PACKING CODE
R3
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CUURVE
1.2
AVERAGE FORWARD CURRENT(A)
PEAK FORWARD SURGE CURRENT (A)
40
FIG. 2 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
8.3ms Single Half Sine-Wave
30
1
0.8
0.6
0.4
0.2
0
50
60
70
80
90
100 110 120 130 140 150 160 170
LEAD TEMPERATURE (
°
C)
RESISTIVE OR
INDUCTIVE LOAD
SS15-SS115
SS12-SS14
20
10
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
FIG. 3 TYPICAL FORWARD CHARACTERISTICS
100
INSTANTANEOUS FORWARD CURRENT(A)
INSTANTANEOUS REVERSE CURRENT (mA)
FIG. 4 TYPICAL REVERSE CHARACTERISTICS
100
SS12-SS14
SS15-SS115
T
J
=125°C
10
10
SS15-SS16
1
1
SS12-SS14
SS115
0.1
T
J
=75°C
0.1
SS19-SS110
0.01
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
FORWARD VOLTAGE (V)
0.01
T
J
=25°C
0.001
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE.(%)
Document Number: DS_D1411020
Version: P15
SS12 - SS115
Taiwan Semiconductor
FIG. 5 TYPICAL JUNCTION CAPACITANCE
FIG. 6 TYPICAL TRANSIENT THERMAL IMPEDANCE
100
1000
SS12-SS14
SS15-SS16
SS19-SS115
CAPACITANCE (pF)
TRANSIENT THERMAL
IMPEDANCE (°C/W)
10
100
f=1.0MHz
Vslg=50mVp-p
1
10
0.1
1
10
100
REVERSE VOLTAGE (V)
0.1
0.01
0.1
1
T-PULSE DURATION(s)
10
100
PACKAGE OUTLINE DIMENSIONS
DO-214AC (SMA)
DIM.
A
B
C
D
E
F
G
H
Unit (mm)
Min
1.27
4.06
2.29
1.99
0.90
4.95
0.10
0.15
Max
1.58
4.60
2.83
2.50
1.41
5.33
0.20
0.31
Unit (inch)
Min
0.050
0.160
0.090
0.078
0.035
0.195
0.004
0.006
Max
0.062
0.181
0.111
0.098
0.056
0.210
0.008
0.012
SUGGESTED PAD LAYOUT
Symbol
A
B
C
D
E
Unit (mm)
1.68
1.52
3.93
2.41
5.45
Unit (inch)
0.066
0.060
0.155
0.095
0.215
MARKING DIAGRAM
P/N =
G=
YW =
F=
Specific Device Code
Green Compound
Date Code
Factory Code
Document Number: DS_D1411020
Version: P15
SS12 - SS115
Taiwan Semiconductor
