Electrical Specifications @ 25°C - Operating Temperature -40°C to +125°C
Part
Number
PH9384.011NL
PH9384.012NL
PH9384.021NL
PH9384.034NL
PH9384.035NL
PH9384.043NL
PH9384.083NL
PH9384.089NL
Inductance
(1-3)
(μH
±35%)
538
538
538
680
680
538
538
538
Leakage Inductance
(1-3) with
Capacitance
(4-6) shorted (1, 2, 3) to (4, 5, 6)
(μH MAX)
(pF MAX)
0.8
0.6
1.6
0.6
0.7
0.8
2.0
0.6
20
30
15
30
30
20
15
30
DCR (1-3)
(Ω MAX)
0.30
0.33
0.30
0.35
0.35
0.30
0.30
0.30
DCR (4-6)
(Ω MAX)
0.40
0.65
0.25
0.52
0.65
0.30
0.22
0.42
MAX (1-3)
1
(V-μsec Max)
24
24
24
27
27
24
24
24
Turns Ratio
(1:3) (6:4)
1CT : 1CT
1CT : 2CT
2CT : 1CT
3CT : 4CT
3CT : 5CT
4CT : 3CT
8CT : 3CT
8CT :9CT
4000
Isolated Voltage
(Vrms)
Notes:
1. The maximum volt-usec rating limits the peak flux density to 3600 gauss when used in
bi-polar drive application with 200KHz. For unipolar drive applications or a bi-polar drive
with 350kHz, a maximum volt-usec could be 60% of the listed value. For Push-Pull top-
ology, where the voltage is applied across half the primary winding turns, the maximum
volts-use needs to be derated by 50%.
2. Optional Tape & Reel packing can be ordered by adding a “T” suffix to the part
number (i.e. PH9384.012NL becomes PH9384.012NLT). Pulse complies to industry
standard tape and reel specification EIA481.
3. The “NL” suffix indicates an RoHS-compliant part number.
Mechanical
PH9384.XXXXNL
9.2 MAX
1.0
4X3.05
Schematic
1
6
2
9.5
12.5 MAX
13.5
5
PH9384.XXXNL
DATE CODE
CTRY ORIGIN
3
PRIMARY
SUGGESTED LAND PATTERN
4
SECONDARY
0.60
Weight
...........................0.85grams
Tape & Reel
........................400/reel
Tray
......................................55/tray
Dimensions:
Inches
mm
d 0.13
6 SURFACES
7.6 MAX
4X3.05±0.25
0.30
(0.7)
Unless otherwise specified,
all tolerances are
±
.010
0,25
1
power.pulseelectronics.com
P775.D (06/17)
http://www.power.pulseelectronics.com/contact
High Isolation Power Transformers
Toroid Platform SMD
Application
PH9384NL is a series of high isolation power supply transformer drivers. Intended to operate in a fixed duty cycle
Push Pull topology, it is a part of a low cost solution for delivering lower power (up to 3W) from a low voltage
source. A typical implementation would be an isolated RS-485/RS-232 power supply driver circuit, the design is
compatible with the MAXIM™ MAX253 IC.
A schematic diagram for the Push Pull converter topology is given below.
V
IN
V
CC
D1
PH9384
V
OUT
DRIVER
IC
D2
GND
For a fixed 50% duty cycle mode of operation, the output voltage is simply determined by the input voltage and
turns ratio. So, with the available turns ratios, a variety of output voltages can be selected.
MAXIM is a registered trademark of Maxim Integrated Products.
