EuroMag Series PCB Mount Pluggable Terminal Blocks
Terminal Blocks:
Single Row
EM2535 Series
EuroMag Terminal Blocks
Header (Mates with EM2525, EM2485 &
EM3105 Series); 5.00 Centers
SPECIFICATIONS
Rating:
16A, 300V
Center Spacing:
0.197” (5.00mm)
Consult factory for 0.394” (10.00mm)
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin-Plated
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Recommended PCB Hole Diameters:
0.055” (1.40mm)
Construction:
Mold-to-Length
Agency Information:
File E62622; CE Certified
EM253505VC
EM253508HO
Dimensions - in (mm)
VERTICAL - CLOSED
L
EuroMag Series
Plug & Header
0.47
(12.0)
Edge Connectors,
One-Sided Boards
0.17
(4.2)
0.039
(1.00)
0.039
(1.00)
Position
02
03
04
05
06
07
08
09
10
11
12
13
Open
L (mm)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
Closed
L (mm)
12.0
17.0
22.0
27.0
32.0
37.0
42.0
47.0
52.0
57.0
62.0
67.0
Position
14
15
16
17
18
19
20
21
22
23
24
Open
L (mm)
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
110.0
115.0
120.0
Closed
L (mm)
72.0
77.0
82.0
87.0
92.0
97.0
102.0
107.0
112.0
117.0
122.0
0.14
(3.5)
0.197
(5.00)
0.11
(2.7)
9.1
(0.36)
0.15
(3.8)
Compliance
References
HORIZONTAL - OPEN
L
EM2535VC
0.039
(1.0)
To convert to inches, divide by 25.4
0.47
(12.0)
0.10
(2.5)
0.17
(4.2)
0.197
(5.00)
0.08
(2.0)
0.039
(1.0)
0.36
(9.1)
Part Numbering System
EM2535
nnnnnn nn
Series
02
to
24
# of Positions
n
Orientations
n
Side Base
Mating Plugs:
EM2525 pg.
85
EM2485 pg.
86
EM3105 pg.
87
H
- horizontal
V
- vertical
O
- open
C
- closed
For additional product information, visit
www.eaton.com/connectors
88
PCB Design
