Our project competence
for your innovative solutions
Amphenol's development strategy is to partner with customers early in their development process. We bring a high level expertise
to programs in an effort to achieve innovative designs that meet current and future needs. Important elements are especially:
Sample shop
and pre-series
production capability
Stamped bended and milled parts
Injection molding and stamping tools
Engineering tools
Structural analysis with FEM
Dynamic FEM Analysis
3D process simulation of injection molding
Network of service provider
Rapid Prototyping
Simultanous Engineering of Product Design
and Development of Processes
Internal Research &
Testing Laboratory
Mechanical endurance & forces
mechanical shock testing
contact force characteristics
vibration testing (sine or random)
Materials & Surfaces
coating thickness measuring
material hardness
visual inspection by microscope
microsections
2
Product Assessmentaces
operating life testing
electrical parameters
Environmental testing, mating cycles
Contents
C702 F
p. 19
C703 A
p. 8
500 000
C702 A
p. 10
C702 B
p. 12
C702 D
p. 14
C702 C
p. 15
Mating Cycles
300 000
C702 Y
p. 15
100 000
C702 E
p. 16
C707 A
p. 20
< 100 000
C707 B
p. 22
C707 D
p. 23
Free Assembly
PCB Assembly
3
Global Partnership
The Company
Amphenol-Tuchel Electronics GmbH is a global
company and leading manufacturer of electrical
connector solutions.
The superior quality of our product line is a result
of specialized engineering and techniques in con-
junction with leading edge production methods.
Our worldwide production and sales channels
provide local competency in a global market-
place. Amphenol has continually upped the
standards in electrical connector technology
with our many inventions and patents.
Our Smart Card solutions are used in applicati-
ons such as payment terminals, Set Top Boxes,
vending machines, access control units and
also in the automotive market.
Global Partnership
Quality
At Amphenol-Tuchel Electronics, quality is one
of the first considerations during the initial deve-
lopment steps.
For more than 20 years our interdisciplinary pro-
ject teams have guaranteed robust and reliable
Smart Card solutions.
Amphenol-Tuchel is certified in accordance
with ISO 9001, QS 9000, VDA 6.1 and TS
16949, which means that each step in the
process chain ensures a maximum quality level.
Our environmental awareness is oriented
4
Technological Leadership
Amphenol-Tuchel Electronics has obtained its claims
to technical advances and technological leadership from
various technical and technological advantages.
These include high-performance precision pressing
technology, modern injection-molding technology and a
manufacturing and inspection technology which ensures
that all processes operate reliably.
Production flexibility is guaranteed by the use of either
fully automatic production equipment, semi-automatic
production lines or manual manufacture, depending on
the requirements.
5
