No melting of resin part that affects to performance
Current rating
Ratings
(Note 3)
Operating temperature range
Operating humidity range
-35 - 85°C (Note 1)
20 - 80%
Voltage rating
Items
1. Insulation resistance
2. Withstanding voltage
3. Contact resistance
4. Vibration resistance
5. Humidity resistance
Storage temperature range
Storage humidity range
-10 - 60°C (Note 2)
40 -70% (Note 2)
Condition
Measured at DC 100V
AC 150V for one minute
Measured at 100mA (DC or 1000Hz)
Frequency: 10 to 55Hz, single amplitude of 0.75mm,
3 directions, 10 cycles for each direction
Exposed for 96 hours at the temperature of 40±2°C
and the humidity of 90 to 95%
(-55°C: 30 minutes
➝
5 to 35°C: 2 to 3 minutes
➝
85°C: 30 minutes
➝
5 to 35°C: 2 to 3 minutes)
5 cycles
30 mating and un-mating cycles
Reflow: At the recommended temperature profile
Manual soldering: The temperature of the soldering
iron of 350°C for 3 seconds
6. Temperature cycle
7. Number of mating
and un-mating cycles
8. Resistance to
soldering heat
(Note 1) This shall include the temperature rise caused by current flow.
(Note 2) The term “storage” refers to products stored for long period of time prior to mounting on the board and use. The operating
temperature and humidity range covers the non-conducting conditions of connectors after being mounted on the board and the
temporary storage conditions during transportation.
(Note 3) Current rating shall be set according to the value of the temperature rise of only connector part.
(Note 4) The specification shown above represents general requirements for this series. Please refer to “Delivery Specification” for a specific official agreement.
■Material
Product
Part
Material
Finish
Specification
Receptacle
Plug
Shell
Insulator
Contacts
Metal fitting
Insulator
Contacts
Outer metal shell
Outer metal shell
LCP (Liquid Crystalline Polymer)
Phosphor bronze
Phosphor bronze
LCP
Phosphor bronze
Stainless steel
Stainless steel
Black color
Gold plated
Tin plated
Black color
Gold plated
Tin plated
Tin plated
UL94V-0
-------------
-------------
UL94V-0
-------------
-------------
-------------
■Ordering
information
Please use the information below when identifying the specification of the product based on the numbering.
Please select a product based on the ordering information described on page 4 to 8 of this catalog when ordering.
