BYG23M
www.vishay.com
Vishay General Semiconductor
Ultrafast Avalanche SMD Rectifier
FEATURES
• Low profile package
• Ideal for automated placement
• Glass passivated pellet chip junction
• Low reverse current
• High reverse voltage
• Ultra fast reverse recovery time
• Meets MSL level 1, per J-STD-020, LF maximum peak
of 260 °C
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
SMA
(DO-214AC)
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
I
R
t
rr
V
F
E
R
T
J
max.
Package
Diode variations
1.5 A
1000 V
30 A
5.0 μA
75 ns
1.7 V
20 mJ
150 °C
SMA (DO-214AC)
Single
TYPICAL APPLICATIONS
For use in high frequency rectification and freewheeling
application in switching mode converters and inverters for
consumer, computer, automotive, and telecommunication.
MECHANICAL DATA
Case:
SMA (DO-214AC)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-M3 - halogen-free, RoHS-compliant, and
commercial grade
Base P/NHM3_X - halogen-free, RoHS-compliant, and
AEC-Q101 qualified (“_X” denotes revision code e.g. A, B,...)
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
M3 and HM3 suffix meets JESD 201 class 2 whisker test
Polarity:
Color band denotes the cathode end
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Device marking code
Maximum repetitive peak reverse voltage
Average forward current at T
A
= 65 °C
Peak forward surge current 10 ms single half sine-wave
superimposed on rated load
Pulse energy in avalanche mode, non repetitive
(inductive load switch off) I
(BR)R
= 1 A, T
J
= 25 °C
Operating junction and storage temperature range
V
RRM
I
F(AV)
I
FSM
E
R
T
J
, T
STG
SYMBOL
BYG23M
BYG23M
1000
1.5
30
20
-55 to +150
V
A
A
mJ
°C
UNIT
Revision: 27-Apr-17
Document Number: 89477
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BYG23M
www.vishay.com
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Minimum breakdown voltage
Maximum instantaneous voltage
TEST CONDITIONS
I
R
= 100 μA
I
F
= 1.0 A
T
J
= 25 °C
T
J
= 150 °C
T
J
= 25 °C
T
J
= 125 °C
SYMBOL
V
BR
V
F (1)
BYG23M
1000
1.7
1.35
5
50
75
UNIT
V
V
Maximum reverse current
Maximum reverse recovery time
V
R
= V
RRM
I
R
t
rr
µA
ns
I
F
= 0.5 A, I
R
= 1.0 A, I
rr
= 0.25 A
Note
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance, junction to case
SYMBOL
R
θJC
R
θJA
(1)
Typical thermal resistance, junction to ambient
R
θJA
(2)
R
θJA
(3)
Notes
(1)
Mounted on epoxy-glass hard tissue, 17 mm
2
35 μm Cu
(2)
Mounted on epoxy-glass hard tissue, 50 mm
2
35 μm Cu
(3)
Mounted on Al-oxide-ceramic (Al O ), 50 mm
2
35 μm Cu
2 3
BYG23M
25
150
125
100
°C/W
UNIT
°C/W
ORDERING INFORMATION
(Example)
PREFERRED P/N
BYG23M-M3/TR
BYG23M-M3/TR3
BYG23MHM3_A/H
(1)
BYG23MHM3_A/I
(1)
Note
(1)
AEC-Q101 qualified
UNIT WEIGHT (g)
0.064
0.064
0.064
0.064
PREFERRED PACKAGE CODE
TR
TR3
H
I
BASE QUANTITY
1800
7500
1800
7500
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
7" diameter plastic tape and reel
13" diameter plastic tape and reel
Revision: 27-Apr-17
Document Number: 89477
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BYG23M
www.vishay.com
Vishay General Semiconductor
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
100
1000
V
R
=
V
RRM
Reverse Current (µA)
Forward Current (A)
10
T
J
= 150 °C
T
J
= 25 °C
1
100
10
0.1
0.5
1
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
25
50
75
100
125
150
Forward
Voltage
(V)
Junction Temperature (°C)
Fig. 1 - Max. Forward Current vs. Forward Voltage
Fig. 4 - Reverse Current vs. Junction Temperature
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
0
25
50
75
100
125
150
R
θJA
= 150 K/W
R
θJA
= 25 K/W
V
R
=
V
RRM
Half Sine-Wave
26
24
22
f = 1 MHz
T
J
= 25 °C
Average Forward Current (A)
Diode Capacitance (pF)
20
18
16
14
12
10
8
6
4
2
0
0.1
1
10
100
R
θJA
= 125 K/W
Ambient Temperature (°C)
Reverse
Voltage
(V)
Fig. 2 - Max. Average Forward Current vs. Ambient Temperature
Fig. 5 - Diode Capacitance vs. Reverse Voltage
160
V
R
=
V
RRM
Reverse Power Dissipation (mW)
140
120
100
R
θJA
= 125 K/W
R
θJA
= 175 K/W
100 %
80
60
40
80
%
20
0
25
50
75
100
125
150
Junction Temperature (°C)
Fig. 3 - Max. Reverse Power Dissipation vs. Junction Temperature
Revision: 27-Apr-17
Document Number: 89477
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BYG23M
www.vishay.com
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
SMA
(DO-214AC)
Cathode Band
Vishay General Semiconductor
Mounting Pad Layout
0.066 (1.68)
MIN.
0.074 (1.88)
MAX.
0.065 (1.65)
0.049 (1.25)
0.110 (2.79)
0.100 (2.54)
0.177 (4.50)
0.157 (3.99)
0.012 (0.305)
0.006 (0.152)
0.060 (1.52)
MIN.
0.208 (5.28)
REF.
0.090 (2.29)
0.078 (1.98)
0.060 (1.52)
0.030 (0.76)
0.008 (0.203)
0 (0)
0.208 (5.28)
0.194 (4.93)
Revision: 27-Apr-17
Document Number: 89477
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
