F-219 SUPPLEMENT
SCPE–G–02.00–S–O–NP
SCPU–17–G–02.00–AMS–AM
SCPE, SCPU, SCPFE SERIES
IP68 SEALED USB & ETHERNET PLUGS
Mates with:
SCRES
TYPE
PLATING
WIRE
LENGTH
END
OPTION
O
–O
NP
–NP
SPECIFICATIONS
For complete specifications
see www.samtec.com?SCPE
Insulator Material:
Polycarbonate
Contact Material:
Phosphor Bronze
Shield Material:
Phosphor Bronze
Wire:
24 AWG
Overmold:
PA66 GF13 FR
Current Rating:
3.8 A per pin (1 pin powered)
Operating Temp Range:
-40 °C to +70 °C
RoHS Compliant:
Yes
= Sealed
Circular
Ethernet
Cable Plug
SCPE
= 50 µ"
(1.27 µm)
Gold on
Contact,
Nickel on
Shell
–G
= (1 m) 39" Cable
–01.00
–02.00
= Double Ended
(Both Ends Sealed)
–D
–S
= Outdoor
Rated
= (2 m) 79" Cable
Standard lengths
= Cat 5e
(No polarization
mates with
SCRES –C5E)
= Single Ended
(End No. 1 Sealed)
Assembled Length = Wire Length + (3.0) .12
(42.00)
1.65
DUST CAP
• DCA-17-02
END NO. 1
–S SHOWN
END NO. 2
(–S)
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
FIELD TERMINATION KIT
• Ethernet Field Termination Kit available for long cable run and small-opening applications
so housings can be customer-installed after the runs are complete.
• SCPFE-17-G-01 Series (For cable outside diameter range of 5.00-5.75 mm)
• SCPFE-17-G-02 Series (For cable outside diameter range of 5.75-6.50 mm)
ALSO
AVAILABLE
(MOQ Required)
• Other wire
lengths
Mates with:
SCRUS
SPECIFICATIONS
For complete specifications
see www.samtec.com?SCPU
Insulator Material:
Glass Filled Thermoplastic
Contact Material:
Copper Alloy
Shield Material:
CRS
Wire:
20 AWG (Power)
25 AWG (Signal)
28 AWG (Drain)
Sealed Overmold:
PA66 GF13 FR
Operating Temp Range:
-20 °C to +75 °C
RoHS Compliant:
Yes
SCPU
SHELL
SIZE
PLATING
WIRE
LENGTH
END 1
OPTION
END 2
OPTION
(Standard USB only)
–17
–10
(Mini USB only)
(28.00)
1.102
(42.00) 1.65
= 30 µ"
(0.76 µm)
Gold on
Contact,
Nickel on
Shell
–G
= (1 m) 40" Cable
–01.00
–02.00
= USB A Type,
Sealed
–AMS
–BMS
–MBS
= Mini USB B Type,
Sealed
(–10 only)
= USB A Type,
Not Sealed
MBS
–AM
= (2 m) 79" Cable
Standard lengths
(Assembled Length
= Wire Length
+ (19.5 mm) .77")
= USB B Type,
Sealed
= Mini USB B
Type, Sealed
(–10 only)
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
–MBS
–AMS
–BMS
ALSO
AVAILABLE
(MOQ Required)
• Other wire lengths
• Other end options
DUST CAPS & PANEL PLUG
• Dust Caps: DCA-17-01 or DCA-10-01
• Panel Plug: SCPPA-17-01
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
–AM
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
