F-219 (Rev 23JAN19)
MOLC–120–01–L–Q–LC
MOLC–150–02–L–Q
MOLC–135–02–L–Q–LC
(1.27 mm) .050"
MOLC SERIES
QUAD ROW TERMINAL STRIP
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?MOLC
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
3.8 A per pin
(4 pins powered)
Voltage Rating:
165 VAC/230 VDC
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
Mates with:
FOLC
Ultra high-density
four row design
APPLICATIONS
FOLC
MATED
HEIGHT
MOLC
Choice of
through-hole
or surface mount
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max (20-25)
(0.15 mm) .006" max (30-50)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
HIGH-SPEED CHANNEL PERFORMANCE
Rating based on Samtec reference
channel. For full SI performance data
visit Samtec.com or contact
SIG@samtec.com
LEAD STYLE MATED
MOLC FOLC HEIGHT*
(5.97)
–01
.235
(7.75)
–11 –01
.305
(11.43)
–31
.450
*Processing conditions
will affect mated height.
G b p s
8
Locking clip option
MOLC
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
Q
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
20, 25, 30, 35,
40, 45, 50
(Standard sizes)
= Through-hole
(Specify from chart)
–‘X’1
–02
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
= Locking
Clip
(Manual
placement
required)
–LC
OTHER
SOLUTIONS
• Surface mount design with
Tiger Buy
™
contacts
(see TOLC/SOLC Series)
LEAD
STYLE
= Surface Mount
(5.59)
.220
(3.38)
.133
= Mixed Technology
–M1
= Pick &
Place Pad
(–02 only)
–P
MIXED
TECHNOLOGY
No. of positions x (1.27) .050 + (2.54) .100
No. of positions x (1.27) .050 + (0.76) .030
ALSO AVAILABLE
(MOQ Required)
• Other sizes
• Alignment pins
• Other platings
A
(5.59)
.220
(7.34)
.289
(11.05)
.435
B
(3.38)
.133
(3.66)
.144
(3.05)
.120
(1.40)
.055
–01
–11
–31
(2.59)
.102
A1
B1
C1
D1
(1.27)
.050
TYP
= Tape &
Reel
(–02 only)
–TR
(6.35)
.250
(1.42)
.056
–LC OPTION
(8.26)
.325
(8.13)
.320
(0.46) .018
DIA TYP
(1.27)
.050 TYP
(5.59)
.220
(2.59)
.102
B
A
(0.64)
(0.25)
.025
.010
(0.36) .014 TYP
TYP
Through-hole = No. of positions x
(1.27) .050 + (1.65) .065
Surface Mount = No. of positions x
(1.27) .050 + (1.52) .060
(3.30)
.130
SURFACE
MOUNT
(0.25)
.010
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
THROUGH-
HOLE
(1.90)
.075
Optional
Locking
Clip (–LC)
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
