F-219
TMM–110–01–S–D–SM
EXTENDED LIFE
PRODUCT
HIGH MATING
CYCLES
10 YEAR MFG
WITH 30 µ" GOLD
TMM–112–01–F–S–SM
(2.00 mm) .0787"
TMM–130–05–L–S–SM
TMM SERIES
LOW-PROFILE SMT HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?TMM
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating:
3.2 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Voltage Rating:
281 VAC mated with SQW;
250 VAC mated with SQT
RoHS Compliant:
Yes
Board Mates:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS
Cable Mates:
TCSD
OTHER SOLUTIONS
Through-
hole
2 mm Shunt
Specify
2SN–BK–G
for 2 mm
shunt with
Gold plating.
(4.45)
.175
(1.95)
.077
(3.99)
.157
(2.00 mm)
.0787" pitch
Available with optional
• Pick & place pads
• Alignment pins
• Tape & reel packaging
(2.77 mm)
.109" Low Profile
(2.00 mm)
.0787"
pitch
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.15 mm) .006" max*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
TMM
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
PLATING
OPTION
ROW
OPTION
SM
OTHER
OPTION
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
02 thru 40
= Gold flash on post,
Matte Tin on tail
–F
= Single
Row
–S
FILE NO. E111594
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= 30 µ" (0.76 µm)
Gold on post,
Matte Tin on tail
–L
= Double
Row
–D
= Alignment Pin
(Metal or plastic at
Samtec’s discretion)
(5 positions minimum)
(–D only)
–A
ALSO AVAILABLE
(MOQ Required)
• Other platings
01
–S
–T
No. of positions x
(2.00) .0787
= Polarized Position
(Specify position of
omitted pin)
–“XXX”
–P
(1.97)
.078
= Matte Tin
40
02
80
= Pick & Place Pad
(3 positions minimum)
LEAD STYLE
–01
(3.94)
.155
A
(1.91) .075
(1.65) .065
(4.27) .168
MATES WITH
SQT, SQW, ESQT,
(3.20) .126 TLE, SMM, MMS, TCSD
CLT
CLT-BE
= Tape & Reel Packaging
(3 thru 36 positions only)
–TR
–04
–05
–06
01
79
(0.50) .020 SQ
(1.27)
.050 TYP
(1.50)
.059
A
(7.06)
.278
–D
(1.27)
.050
(4.83)
.190
–S
(5.00)
.197
(5.08)
.200
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(2.00)
.0787
Due to technical progress, all designs, specifications and components are subject to change without notice.
–P
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
