F-213 SUPPLEMENT
BTMM–106–01–T–S
BTSW–110–01–T–D
(2,00 mm) .0787"
(2,54 mm) .100"
BTMM, BTSW SERIES
BTMM–110–01–T–D
BTSW–210–01–T–S
BTMM–150–01–T–D
LOW PROFILE SQUARE POST JUMPER
SPECIFICATIONS
For complete specifications
see www.samtec.com?BTMM
Insulator Material:
Black Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
BTMM
1
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
–T
01 thru 50
No. of positions x (2,00) .0787
02
–S
= Single Row
“XXX”
= Polarized
Position
(Specify position
of omitted pin)
(Leave blank for
no option)
= Matte Tin
–D
= Double Row
(2,00)
.0787
01
(3,94)
.155
01
(0,50) .020 SQ
(2,57)
.101
(1,50)
.059
(2,00) .0787
(1,50)
.059
(2,60)
.102
(4,00)
.157
(8,00)
.315 (4,00)
.157
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
–S
SINGLE ROW
DOUBLE ROW
–D
SPECIFICATIONS
For complete specifications
see www.samtec.com?BTSW
Insulator Material:
Black Glass Filled
Polyester
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C
RoHS Compliant:
Yes
Lead–Free Solderable:
Wave Only
BTSW
PIN
CENTERS
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
–S
–1
= (2,54 mm) .100"
(All positions filled)
01 thru 50
= (2,54 mm) .100" Pin Center
–T
= Matte Tin
= Single
Row
–LL
= Locking
Lead
–2
= (5,08 mm) .200"
(Every other position filled
starting at –01 and ending
in last position)
02 thru 25
= (5,08 mm) .200" Pin Center
02
–D
= Double
Row
“XXX”
= Polarized
Position
(Specify
position of
omitted pin)
(Leave blank
for no option)
(5,08)
.200
01
01
APPLICATION
(2,80)
.110
(2,54)
.100
(2,54) .100
(0,64) .025 SQ
No. of Positions x (2,54) .100
(5,08) (10,16)
.400
.200
(2,54)
.100
(2,54)
.100
(2,54)
.100
(5,08)
.200
(2,69)
.106
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
SINGLE ROW
DOUBLE ROW
–D
–S
WWW.SAMTEC.COM
