WGKA80SJTB: DescriptionRectangular Mil-Spec Connector 3Row Straight Recptl I/O; CategoryThe connector Military specifications/military types Rectangular military specifications connector; File Size423KB，2 Pages; ManufacturerAirBorn

Download Datasheet Parametric Compare View All

WGKA80SJTB Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	WGKA80SJTB	-	-	View	Buy Now

WGKA80SJTB Overview

Rectangular Mil-Spec Connector 3Row Straight Recptl I/O

WGKA80SJTB Parametric

Parameter Name	Attribute value
Maker	AirBorn
Product Category	Rectangular Mil-Spec Connector
product	I/O Connectors
Number of locations	80 Position
Number of rows	3 Row
Termination type	Crimp
Installation style	Board Mount
Contact type	Socket (Female)
Contact plating	Gold
MIL type	MIL-DTL-55302
series	WG
Installation angle	Straight
Current rating	5 A
Shell material	Polyphenylene Sulfide (PPS)
Contact material	Beryllium Copper
Pitch	2.54 mm
Insulation resistance	5000 MOhms
Maximum operating temperature	+ 125 C
Minimum operating temperature	- 65 C
Factory packaging quantity	1

Preview

Download Datasheet

View All

WGKA80SJTB Related Products

	WGKA80SJTB	WGKA160SJTB	WGKA50SJTB	WGKA104SJTB	WGKA92SJTB	WGKA62SJTB
Description	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O	Rectangular Mil-Spec Connector 3Row Straight Recptl I/O
Maker	AirBorn	AirBorn	AirBorn	AirBorn	AirBorn	AirBorn
Product Category	Rectangular Mil-Spec Connector	Rectangular Mil-Spec Connector	Rectangular Mil-Spec Connector	Rectangular Mil-Spec Connector	Rectangular Mil-Spec Connector	Rectangular Mil-Spec Connector
product	I/O Connectors	I/O Connectors	I/O Connectors	I/O Connectors	I/O Connectors	I/O Connectors
Number of locations	80 Position	160 Position	50 Position	104 Position	92 Position	62 Position
Number of rows	3 Row	3 Row	3 Row	3 Row	3 Row	3 Row
Termination type	Crimp	Crimp	Crimp	Crimp	Crimp	Crimp
Installation style	Board Mount	Board Mount	Board Mount	Board Mount	Board Mount	Board Mount
Contact type	Socket (Female)	Socket (Female)	Socket (Female)	Socket (Female)	Socket (Female)	Socket (Female)
Contact plating	Gold	Gold	Gold	Gold	Gold	Gold
MIL type	MIL-DTL-55302	MIL-DTL-55302	MIL-DTL-55302	MIL-DTL-55302	MIL-DTL-55302	MIL-DTL-55302
series	WG	WG	WG	WG	WG	WG
Installation angle	Straight	Straight	Straight	Straight	Straight	Straight
Current rating	5 A	5 A	5 A	5 A	5 A	5 A
Shell material	Polyphenylene Sulfide (PPS)	Polyphenylene Sulfide (PPS)	Polyphenylene Sulfide (PPS)	Polyphenylene Sulfide (PPS)	Polyphenylene Sulfide (PPS)	Polyphenylene Sulfide (PPS)
Contact material	Beryllium Copper	Beryllium Copper	Beryllium Copper	Beryllium Copper	Beryllium Copper	Beryllium Copper
Pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Insulation resistance	5000 MOhms	5000 MOhms	5000 MOhms	5000 MOhms	5000 MOhms	5000 MOhms
Maximum operating temperature	+ 125 C	+ 125 C	+ 125 C	+ 125 C	+ 125 C	+ 125 C
Minimum operating temperature	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C
Factory packaging quantity	1	1	1	1	1	1
