NOTES:
1. FOR WAVESOLDERING (SOLDER BATH TEMPERATURE 265°C FOR 8 SEC.
AND SOLDER PREHEAT 150°C FOR 180 SEC.)
2. IP RATING: IP 67
3. SEALED TO WITHSTAND PRESSURE UP TO 1,45 PSI
FOR 30 MINUTES
AFTER HIGH TEMPERATURE EXPOSURE
4. METALSHELL: ZINC DIE CAST;
min. 50µin NICKEL PLATING over COPPER
5. INSULATORS: PBT GF UL 94 V-0, BLACK
6. O-RING: SILICONE PER ASTM D2000 70 SHORE A
7. RUBBER GASKET: TPE
8. SEALING COMPOUND: EPOXY RESIN UL 94 V-0; BLACK
9. CONTACTS: COPPER ALLOY
PLATING (SEE PART NO):
o
PLEASE ADD 1 for 30µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD 3 for 8µin HARD GOLD over min. 50µin NICKEL
10. REAR SPACER CLIPS: COPPER ALLOY;
min. 200µin TIN over 80µin NICKEL
PCB-HOLE:
n
3,1
`
0,1; PCB THICKNESS 1,6mm
11. HEXLOCKING SCREWS: STAINLESS STEEL
12. PCB-HOLE DRILLINGS and
RECOMMENDED PANEL CUT-OUT ON SHEET 2
13. RECOMMENDED TORQUE FOR MOUNTING SCREW
35Ncm (3.1 in.LB) / max.67Ncm (6 in.LB)
14. CONNECTOR IS PART MARKED: 15-00052
o
CONEC ABC
(5:1)
D
12,23
+ 0,4
- 0,3
D
11,5
+ 0,4
- 0,3
0,4
8,6
+ 0,3
-
b
0
5,99
+ 0,3
-
3,6
+ 0,25
-0
8,23
+ 0,25
-0
RUBBER GASKET
PLACED ON TOP SURFACE
OF MALE INSULATOR
POS. 1
C
78
+ 0,3
-0
63,5
`
0,13
b
POS. 22
POS. 43
C
55,32
+ 0,23
- 0,02
21,1
+ 0,3
-0
10°
n
0,6
`
0,05
(62x)
b
B
O-RING
15-00052
o
CONEC ABC
SEALING
COMPOUND
B
9,4
SEE NOTE 14
4,6
4-40 UNC
4-40 UNC
b
SW 4,8
AT ALL TIMES WATER RESISTANT CONNECTORS NOT
IN USE SHOULD BE COVERED WITH A CONEC WATER
RESISTANT CAP OR WATER TIGHT HOOD.
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
scale:
material:
title:
2:1 (5:1)
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
see notes
A
A
name
NAME:
TITLE:
17.10.08
22.10.08
Petker
Fischer
D-SUB MALE HD
62pos. SOLDER PIN STRAIGHT
with rear spacer clip and hexlocking screw
dwg no:
Inventor 10
DIN-
R
COMPANY NAME:
5xb
a
Ä3435
Origin
24.09.09
HS
15K1A310
part no:
B
A
A3
sh:
1
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
rev. description
D
date
name
C
15-00052
o
(see note 9)
F
E
F
E
D
C
B
A
D
P.C.B. HOLE DRILLINGS
D
49,467
`
0,05
2,413
`
0,1
1,207
`
0,1
n
3,1
`
0,1
(2x)
7,04
`
0,03
1,98
`
0,1
24,71
`
0,1
1
+ 0,1
n
0,9
- 0
(62x)
C
63,5
`
0,13
1,98
`
0,1
C
RECOMMENDED PANEL CUT-OUT
59,1
`
0,1
i
0,26 A
B
B
11,4
`
0,1
B
n
3,1
`
0,05
(2x)
4
`
R3,
10°
`
1°
i
0,26 B
0,13
63,5
`
0,1
A
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
R
scale:
material:
title:
3:1
see sheet 1
A
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
A
name
NAME:
TITLE:
17.10.08
22.10.08
Petker
Fischer
P.C.B. HOLE DRILLINGS
PANEL CUT-OUT
D-SUB Male 62pos. HD Solder pin straight
dwg no:
Inventor 10
DIN-
COMPANY NAME:
a
Origin
15K1A310
part no:
A3
sh:
2
A
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
rev. description
D
date
name
C
see sheet 1
F
E
B
