Pressure sensors
C38 series
Applications
Industrial
Automotive
Medical
Features
Piezoresistive MEMS technology
Small dimensions: 1.65 × 1.65 mm
Square diaphragm
Measured media (back side):
Non-aggressive gases and fluids.
Unsuitable for substances which react with
glass or silicon.
Wheatstone bridge with mV output,
ratiometric to supply voltage
Rated pressure ranges 1.6 up to 40 bar
Outstanding long-term stability
Delivery mode
Tape
Dimensional drawings
B58601E38**B650
Gauge pressure sensor die
BL SEN PS PD SD
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 2 of 9
2016-09-02
Pressure sensors
C38 series
B58601E38**B650
Gauge pressure sensor die
Technical data
Absolute maximum ratings
Parameter
Supply voltage
Maximum supply soltage
Temperature ranges
2)
Symbol
Conditions
1)
Min.
Typ.
Max.
Unit
V
DD
Without damage
10
V
Operating temperature range
Storage temperature range
Pressure ranges
Operating pressure ranges
Over pressure
Burst pressure
T
a
T
st
–40
–40
–40
4)
5)
6)
135
140
150
°C
°C
°C
For t <15 min
3)
p
r
p
ov
p
berst
Gauge pressure
Gauge pressure
Gauge pressure
10
3
5
25
bar
p
r
p
r
Electrical specifications
Parameter
Symbol
Conditions
7)
Min.
Typ.
Max.
Unit
Supply voltage / bridge resistance
Operating supply voltage
Total bridge resistance
Temperature coefficient
of total bridge resistance
Output signal @ V
DD
= 5 V
Offset
Sensitivity
Temperature coefficient
of offset
Temperature coefficient
of the sensitivity
Pressure hysteresis
V
o
S
TCV
0
TCV
0
α
S
β
S
pHys
–
+
V
DD
R
S
α
Rs
β
Rs
1.0
8)
5.0
4.0
2.3
6
4.6
2.7
8
V
kΩ
10 /K
10 /K
–6
2
–3
@ 25 °C
@ 25 °C
3.4
2.0
0
9)
@ 25 °C
@ 25 °C
Unglued
10)
13)
–25
+25
See next table
See next table
See next table
mV
mV/bar
µV/VK
µV/VK
10 /K
10 /K
% FS
–6
2
12)
–3
11)
@ 25 °C
16)
15)
–2.5
0
–0.1
–2.2
5
–1.9
8
0.1
Long-term stability (Full scale normal output FSON = 120 mV)
Temperature hysteresis of offset
Temperature cycle drift of offset
High temperature drift of offset
Long term stability of offset
THV
0
TCDV
0
HTDV
0
LTSV
0
17)
17)
17)
17)
–0.2
–0.1
–0.25
–0.3
±0.1
±0.05
±0.1
0.15
0.2
0.1
0.25
0.3
% FSON
% FSON
% FSON
% FSON
BL SEN PS PD SD
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 3 of 9
2016-09-02
Pressure sensors
C38 series
Symbols and Terms
1)
2)
B58601E38**B650
Gauge pressure sensor die
3)
4)
5)
6)
7)
Maximum power supply V
DD
This is the maximal allowed voltage, which may be applied to the piezoresistive bridge circuit without damage.
Operating temperature range T
a
This is the operating Temperature range T
a,min
to T
a,max
. Because most of the sensor parameters depend on assembling
conditions like gluing, wire bonding etc, the die has to be tested over the operating temperature range by the customer
fully assembled. For design verification and process control samples, mounted in AK transducer package (AK2 series)
are tested over the temperature range of T
min
to T
max
.
Storage temperature range T
st
If the pressure sensor dies are stored in the temperature range T
st,min
to T
st,max
without applied voltage power supply, this
will not affect the performance of the pressure sensor dies.
Operating pressure range p
r
In the operating pressure range 0 to p
r,max
the pressure sensor die output characteristic is as defined in this specification.
Over pressure p
OV
Pressure cycles in the pressure range 0 to p
ov
do not affect the performance of the pressure sensor dies.
Burst pressure p
berst
Up to the burst pressure p
berst
the diaphragm of the sensor die will not be destroyed mechanically. This parameter is
tested at room temperature on samples mounted on an aluminium socket by increasing the applied pressure until the
diaphragm is destroyed. Since the burst pressure depends on several assembling conditions, this parameter has to be
verified by the customer with his assembling possibilities.
Operating power supply V
DD
The pressure sensor parameters are defined for a power supply voltage of V
DD
= 5 V. In the operating power supply
voltage range V
DD,min
to V
DD,max
the ratiometric parameters r(V
DD
) like sensitivity, offset voltage and the temperature
coefficient of the offset voltage are defined by:
r
(
V
DD
)
=
r(5[ V ])
8)
V
DD
5[ V ]
Total bridge resistance R
S
The total bridge resistance is defined between pad X5 and X2, (see the dimensional drawing in this data sheet) of the
closed piezoresistive bridge circuit. The total bridge resistance is in a good approximation the output impedance of the
piezoresistive bridge circuit. This parameter is tested completely on a wafer (wafer level test measurement).
Temperature coefficients of resistance
α
Rs
and
β
Rs
:
The temperature coefficients of resistance are tested for design verification on samples, mounted on AK transducer
package (AK2 series) over the temperature range T
min
to T
max
with T
R
= 25 °C.
The temperature coefficients of first and second order are defined with the polynomial:
9)
R
S
(T )
=
R
S
(T
=
25
°
C )
1
+ α
Rs
T
−
25
°
C
+ β
Rs
T
−
25
°
C
10)
(
)
(
)
2
11)
The coefficients
α
Rs
and
β
Rs
are calculated using the three measurement points of R
s
(T) at T
meas,min
, T
R
and T
meas,max
.
Offset voltage V
0
The offset voltage V
0
is the output voltage V
out
(p = 0 bar gauge) at zero gauge pressure and for a bridge voltage power
supply V
DD
= 5 V. This parameter is tested completely on a wafer (wafer level test measurement).
Since the offset voltage depends on several assembling conditions, this parameter has to be verified by the customer
with his assembling possibilities.
Temperature coefficient of offset voltage TCV
0
The temperature coefficients of offset voltage are defined for a bridge voltage power supply V
DD
= 5 V.
These parameters strongly depend on assembly conditions like gluing, wire bonding etc.
The temperature coefficients of offset voltage are tested for design verification on samples, mounted on AK transducer
package (AK2 series) over the temperature range T
min
to T
max
.
Therefore TCV
0+
and TCV
0-
are defined for the measurement temperature range by:
TCVo
+
=
V
o
(T
max
)
−
V
o
(25
°
C)
T
max
−
25
°
C
TCVo
−
=
V
o
(T
min
)
−
V
o
(25
°
C)
T
min
−
25
°
C
Since the TCV
0
depends on several assembling conditions, this parameter has to be verified by the customer with his
assembling possibilities.
BL SEN PS PD SD
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 5 of 9
2016-09-02
