TP5.0SMDJ Series
Working Voltage: 10 to 58 V
Peak Pulse Power: 5000 W
Features
●
●
Surface Mount
Transient Voltage Suppressors
SMC/ DO-214AB
Optimized glass passivated chip
T
j
= 150 °C capability suitable for high
reliability and automotive requirement
5000 W peak pulse power capability with a
10/1000 μs waveform, repetitive rate (duty
cycle):0.01 %
Meet ISO 7637-2 load dump test (varied by
test condition)
High reliability application and automotive
grade AEC Q101 qualified
Low leakage
Uni and Bidirectional unit
Excellent clamping capability
Very fast response time
RoHS compliant
Case: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Solderable per MIL-STD-750, method
2026
Polarity: Color band denotes cathode end
except Bipolar
Mounting position: Any
●
●
●
●
●
●
●
●
Mechanical Data
●
●
●
●
●
Maximum Ratings(T
A
=25℃ unless otherwise noted)
Parameter
Peak power dissipation with a 10/1000μs waveform
(1)
Peak pulse current wih a 10/1000μs waveform
(1)
Power dissipation on infinite heatsink at T
L
= 50 °C
Peak forward surge current, 8.3 ms single half sine-
wave unidirectional only
(2)
Maximum instantaneous forward voltage at 100A for
unidirectional only
Operating junction and storage temperature range
Note:
(1)Non-repetitive current pulse per Fig.5 and derated above T
A
= 25 °C per Fig.1
(2)Measured on 8.3 ms single half sine-wave or equivalent square wave, duty cycle = 4 pulses per minute maximum
Value
Symbol
P
PP
5000
I
PP
See Next Table
P
D
6.5
I
FSM
V
F
T
J
, T
STG
300
3.5
–55 to +150
Unit
W
A
W
A
V
°C
www.dowosemi.cn
P. 1
TP5.0SMDJ Series
Ratings and Characteristics Curves (T
A
=25℃ unless otherwise noted)
Peak Pulse Derating in Percentage of Peak
Power or Current, (%)
AVERAGE FORWARD CURRENT, (A)
AMBIENT TEMPERATURE , (℃)
100
100
150
75
300
0
25
1
Peak Forward Surge Current, (A)
250
200
150
100
50
0
T
J
= T
J
max.
300
8.3 ms Single Half Sine-Wave
100
0
100
40
50
25
0
0
25
50
75
100
125
150
175
200
1
10
Number of Cycles at 60 Hz
100
Ambient Temperature ,T
A
(℃)
Fig. 1 - Pulse Derating Curve
7.0
1000
Fig. 2 - Maximum Non-Repetitive
Surge Current
1
100
0
Steady State Power Dissipation, (W)
50
6.0
6.5
6.5
0
P
PPM
-Peak Pulse
52
22
5.1
20
1000
##
5.0
4.0
3.0
2.0
1.0
0.0
10
1
0
25
50
75
100
125
150
175
200
0.1
1
10
100
1000
Lead Temperature , T
L
(℃)
Pulse Width ,t
d
(μs)
Fig. 3 - Steady State Power Derating Curve
100000
Tr=10μs
100
Peak Value
(Ipp)
T
J
= 25
°C
Pulse Width (td) is defined as the
point where the peak current
0
0
decays to 50 % of Ipp
Half Value = Ipp
0.5
2
76
50
Fig. 4 - Peak Pulse Power Rating Curve
Uni-directional
@zero bias
Bi-directional
@zero bias
10000
58
21
#####
33
13000
42.1
10
Peak Pulse Current , (% )
11200
58
3000
0.2
100
Junction Capacitance,C
J
(pF)
1000
10
33
42
Uni-directional @V
RWM
6160
4500
td
0
1
50
1.5
33
10/1000 μsec.
Waveform
2
as defined
23
R.E.A.
by
3
13
4
10
1
2
Time , (ms)
3
4
100
10
Bi-directional @V 58
33
42.1
RWM
1500
20000 6000
4600
10
33
42.1
2300
58
3200
T
J
=25
°C
22
10
0
1
f=1.0MHz
1
10
100
Reverse Breakdown Voltage,V
BR
(V)
Fig. 5 - Pulse Waveform
Fig. 6 - Typical Junction Capacitance
www.dowosemi.cn
P. 2
TP5.0SMDJ Series
Electrical Characteristics(T
A
=25℃ unless otherwise noted)
Device
Marking
Code
Breakdown Voltage V
BR
@I
T
Maximum Working
Maximum Maximum
Reverse Peak Reverse
Clamping
Reverse
Leakage I
R
Voltage V
C
Voltage
Surge
V
RWM
Current I
PP
@V
RWM
@I
PP
(V)
(A)
(uA)
(V)
5
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
10.0
11.0
12.0
13.0
14.0
15.0
16.0
17.0
18.0
19.0
20.0
22.0
24.0
26.0
28.0
30.0
33.0
36.0
40.0
43.0
45.0
48.0
51.0
54.0
58.0
294.12
275.0
252.0
233.0
216.0
205.0
193.0
181.0
172.0
162.4
155.0
141.0
129.0
119.0
110.0
103.0
93.9
86.1
77.6
72.1
68.8
64.7
60.7
57.5
53.5
17.0
18.2
19.9
21.5
23.2
24.4
26.0
27.6
29.2
30.8
32.4
35.5
38.9
42.1
45.4
48.4
53.3
58.1
64.5
69.4
72.7
77.4
82.4
87.1
93.6
Part Number
(Uni)
Part Number (Bi)
Uni
TP5.0SMDJ10A
TP5.0SMDJ11A
TP5.0SMDJ12A
TP5.0SMDJ13A
TP5.0SMDJ14A
TP5.0SMDJ15A
TP5.0SMDJ16A
TP5.0SMDJ17A
TP5.0SMDJ18A
TP5.0SMDJ19A
TP5.0SMDJ20A
TP5.0SMDJ22A
TP5.0SMDJ24A
TP5.0SMDJ26A
TP5.0SMDJ28A
TP5.0SMDJ30A
TP5.0SMDJ33A
TP5.0SMDJ36A
TP5.0SMDJ40A
TP5.0SMDJ43A
TP5.0SMDJ45A
TP5.0SMDJ48A
TP5.0SMDJ51A
TP5.0SMDJ54A
TP5.0SMDJ58A
TP5.0SMDJ10CA
TP5.0SMDJ11CA
TP5.0SMDJ12CA
TP5.0SMDJ13CA
TP5.0SMDJ14CA
TP5.0SMDJ15CA
TP5.0SMDJ16CA
TP5.0SMDJ17CA
TP5.0SMDJ18CA
TP5.0SMDJ19CA
TP5.0SMDJ20CA
TP5.0SMDJ22CA
TP5.0SMDJ24CA
TP5.0SMDJ26CA
TP5.0SMDJ28CA
TP5.0SMDJ30CA
TP5.0SMDJ33CA
TP5.0SMDJ36CA
TP5.0SMDJ40CA
TP5.0SMDJ43CA
TP5.0SMDJ45CA
TP5.0SMDJ48CA
TP5.0SMDJ51CA
TP5.0SMDJ54CA
TP5.0SMDJ58CA
5SAE
5SAF
5SAG
5SAK
5SAM
5SAP
5SAR
5SAT
5SAV
5SAX
5SAZ
5SBE
5SBF
5SBG
5SBK
5SBM
5SBP
5SBR
5SBT
5SBV
5SBX
5SBZ
5SCE
5SCF
5SCG
Bi
5DAE
5DAF
5DAG
5DAK
5DAM
5DAP
5DAR
5DAT
5DAV
5DAX
5DAZ
5DBE
5DBF
5DBG
5DBK
5DBM
5DBP
5DBR
5DBT
5DBV
5DBX
5DBZ
5DCE
5DCF
5DCG
Min (V)
11.10
12.20
13.30
14.40
15.60
16.70
17.80
18.90
20.00
21.10
22.20
24.40
26.70
28.90
31.10
33.30
36.70
40.00
44.40
47.80
50.00
53.30
56.70
60.00
64.40
Max (V) I
T
(mA)
12.30
13.50
14.70
15.90
17.20
18.50
19.70
20.90
22.10
23.30
24.50
26.90
29.50
31.90
34.40
36.80
40.60
44.20
49.10
52.80
55.30
58.90
62.70
66.30
71.20
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2. Add suffix 'C 'or ' CA ' after part number to specify Bi-directional devices
3. For Bi-Directional devices having V
R
of 10 volts , the I
R
limit is double
Note:
www.dowosemi.cn
P. 3
