QED422, QED423 Plastic Infrared Light Emitting Diode
August 2005
QED422, QED423
Plastic Infrared Light Emitting Diode
Features
■
■
■
■
■
■
■
λ
= 880 nm
Chip material = AlGaAs
Package type: Plastic TO-46
Matched Photosensor: QSD722/723/724
Medium Wide Emission Angle, 30°
High Output Power
Package material and color: clear, purple tinted, plastic
Description
The QED422/423 is an 880 nm AlGaAs LED encapsulated in a
clear, purple tinted, plastic TO-46 package.
Package Dimensions
0.190 (4.83)
0.178 (4.52)
REFERENCE
SURFACE
0.220 (5.59)
0.030 (0.76)
NOM
0.800 (20.3)
MIN
0.050 (1.27)
CATHODE
0.100 (2.54)
NOM
Ø 0.215 (5.46)
NOM
45°
0.020 (0.51)
SQ. (2X)
R 0.022 (0.56)
Schematic
ANODE
CATHODE
NOTES:
1. Dimensions for all drawings are in inches (mm).
2. Tolerance of ± .010 (.25) on all non-nominal
dimensions unless otherwise specified.
©2005 Fairchild Semiconductor Corporation
1
www.fairchildsemi.com
QED422, QED423 Rev. 1.0.0
QED422, QED423 Plastic Infrared Light Emitting Diode
Absolute Maximum Ratings
(T
A
= 25°C unless otherwise specified)
Parameter
Operating Temperature
Storage Temperature
Soldering Temperature (Iron)
(2,3,4)
Soldering Temperature (Flow)
(2,3)
Continuous Forward Current
Reverse Voltage
Power
Dissipation
(1)
Symbol
T
OPR
T
STG
T
SOL-I
T
SOL-F
I
F
V
R
P
D
Rating
-40 to + 100
-40 to + 100
240 for 5 sec
260 for 10 sec
100
5
200
Unit
°C
°C
°C
°C
mA
V
mW
Notes:
1. Derate power dissipation linearly 2.67 mW/°C above 25°C.
2. RMA flux is recommended.
3. Methanol or isopropyl alcohols are recommended as cleaning agents.
4. Soldering iron 1/16" (1.6 mm) minimum from housing
Electrical/Optical Characteristics
(T
A
=25°C)
Parameter
Peak Emission Wavelength
Emission Angle
Forward Voltage
Reverse Current
Radiant Intensity QEC422
Radiant Intensity QEC423
Rise Time
Fall Time
Test Conditions
I
F
= 100 mA
I
F
= 100 mA
I
F
= 100 mA, tp = 20 ms
V
R
= 5 V
I
F
= 100 mA, tp = 20 ms
I
F
= 100 mA, tp = 20 ms
I
F
= 100 mA
Symbol
λ
PE
2
Θ
1/2
V
F
I
R
I
E
I
E
t
r
t
f
Min
—
—
—
—
10
20
—
—
Typ
880
30
—
—
—
—
800
800
Max
—
—
1.8
10
40
—
—
—
Units
nm
Deg.
V
µA
mW/sr
mW/sr
ns
ns
2
QED422, QED423 Rev. 1.0.0
www.fairchildsemi.com
QED422, QED423 Plastic Infrared Light Emitting Diode
Fig. 1 Normalized Radiant Intensity vs. Forward Current
I
e
- NORMALIZED RADIANT INTENSITY
10
Normalized to:
I
F
= 100 mA Pulsed
t
pw
= 100
µs
Duty Cycle = 0.1 %
T
A
= 25°C
2.0
Fig. 2 Forward Voltage vs. Ambient Temperature
I
F
= 50 mA
V
F
- FORWARD VOLTAGE (V)
I
F
= 100 mA
1.5
1
0.1
1.0
I
F
= 20 mA
I
F
= 10 mA
0.01
0.5
Normalized to:
I
F
Pulsed
t
pw
= 100
µs
Duty Cycle = 0.1 %
-20
0
20
40
60
80
100
0.001
1
10
100
1000
0.0
-40
I
F
- FORWARD CURRENT (mA)
T
A
- AMBIENT TEMPERATURE (°C)
Fig. 3 Normalized Radiant Intensity vs. Wavelength
1.0
Fig. 4 Radiation Diagram
110
120
130
140
100
90
80
70
60
50
40
30
20
10
0
1.0
0.8
0.6
0.4
0.2
0.0
0.2
0.4
0.6
0.8
1.0
NORMALIZED RADIANT INTENSITY
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
180
775
800
825
850
875
900
925
950
150
160
170
λ(nm)
3
QED422, QED423 Rev. 1.0.0
www.fairchildsemi.com
QED422, QED423 Plastic Infrared Light Emitting Diode
