54AC161
•
54ACT161 Synchronous Presettable Binary Counter
November 1998
54AC161
•
54ACT161
Synchronous Presettable Binary Counter
General Description
The ’AC/’ACT161 are high-speed synchronous modulo-16
binary counters. They are synchronously presettable for ap-
plication in programmable dividers and have two types of
Count Enable inputs plus a Terminal Count output for versa-
tility in forming synchronous multistage counters. The ’AC/
’ACT161 has an asynchronous Master Reset input that over-
rides all other inputs and forces the outputs LOW.
n
n
n
n
n
n
Synchronous counting and loading
High-speed synchronous expansion
Typical count rate of 125 MHz
Outputs source/sink 24 mA
’ACT161 has TTL-compatible inputs
Standard Microcircuit Drawing (SMD)
— ’AC161: 5962-89561
— ’ACT161: 5962-91722
Features
n
I
CC
reduced by 50%
Logic Symbols
Pin Names
CEP
CET
CP
MR
P
0
–P
3
PE
Q
0
–Q
3
TC
DS100274-1
Description
Count Enable Parallel Input
Count Enable Trickle Input
Clock Pulse Input
Asynchronous Master Reset Input
Parallel Data Inputs
Parallel Enable Inputs
Flip-Flop Outputs
Terminal Count Output
IEEE/IEC
DS100274-2
TRI-STATE
®
is a registered trademark of National Semiconductor Corporation.
FACT
™
is a trademark of Fairchild Semiconductor Corporation.
© 1998 National Semiconductor Corporation
DS100274
www.national.com
Connection Diagrams
Pin Assignment
for DIP and Flatpak
The Terminal Count (TC) output is HIGH when CET is HIGH
and counter is in state 15. To implement synchronous multi-
stage counters, the TC outputs can be used with the CEP
and CET inputs in two different ways.
DS100274-3
Pin Assignment
for LCC
Figure 1
shows the connections for simple ripple carry, in
which the clock period must be longer than the CP to TC de-
lay of the first stage, plus the cumulative CET to TC delays of
the intermediate stages, plus the CET to CP setup time of
the last stage. This total delay plus setup time sets the upper
limit on clock frequency. For faster clock rates, the carry loo-
kahead connections shown in
Figure 2
are recommended. In
this scheme the ripple delay through the intermediate stages
commences with the same clock that causes the first stage
to tick over from max to min in the Up mode, or min to max
in the Down mode, to start its final cycle. Since this final
cycle requires 16 clocks to complete, there is plenty of time
for the ripple to progress through the intermediate stages.
The critical timing that limits the clock period is the CP to TC
delay of the first stage plus the CEP to CP setup time of the
last stage. The TC output is subject to decoding spikes due
to internal race conditions and is therefore not recom-
mended for use as a clock or asynchronous reset for
flip-flops, registers or counters.
Logic Equations: Count Enable = CEP
•
CET
•
PE
TC = Q
0
•
Q
1
•
Q
2
•
Q
3
•
CET
Mode Select Table
PE
X
L
DS100274-4
CET
X
X
H
L
X
CEP
X
X
H
X
L
Action on the Rising
Clock Edge (
N
)
Reset (Clear)
Load (P
n
→
Q
n
)
Count (Increment)
No Change (Hold)
No Change (Hold)
H
H
H
Functional Description
The ’AC/’ACT161 count in modulo-16 binary sequence.
From state 15 (HHHH) they increment to state 0 (LLLL). The
clock inputs of all flip-flops are driven in parallel through a
clock buffer. Thus all changes of the Q outputs (except due
to Master Reset of the ’161) occur as a result of, and syn-
chronous with, the LOW-to-HIGH transition of the CP input
signal. The circuits have four fundamental modes of opera-
tion, in order of precedence: asynchronous reset, parallel
load, count-up and hold. Five control inputs — Master Reset,
Parallel Enable (PE), Count Enable Parallel (CEP) and
Count Enable Trickle (CET) — determine the mode of opera-
tion, as shown in the Mode Select Table. A LOW signal on
MR overrides all other inputs and asynchronously forces all
outputs LOW. A LOW signal on PE overrides counting and
allows information on the Parallel Data (P
n
) inputs to be
loaded into the flip-flops on the next rising edge of CP. With
PE and MR HIGH, CEP and CET permit counting when both
are HIGH. Conversely, a LOW signal on either CEP or CET
inhibits counting.
The ’AC/’ACT161 use D-type edge-triggered flip-flops and
changing the PE, CEP and CET inputs when the CP is in ei-
ther state does not cause errors, provided that the recom-
mended setup and hold times, with respect to the rising edge
of CP, are observed.
H = HIGH Voltage Level
L = LOW Voltage Level
X = Immaterial
State Diagram
DS100274-5
www.national.com
2
Absolute Maximum Ratings
(Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC
)
DC Input Diode Current (I
IK
)
V
I
= −0.5V
V
I
= V
CC
+ 0.5V
DC Input Voltage (V
I
)
DC Output Diode Current (I
OK
)
V
O
= −0.5V
V
O
= V
CC
+ 0.5V
DC Output Voltage (V
O
)
DC Output Source
or Sink Current (I
O
)
DC V
CC
or Ground Current
per Output Pin (I
CC
or I
GND
)
Storage Temperature (T
STG
)
Junction Temperature (T
J
)
CDIP
−0.5V to +7.0V
−20 mA
+20 mA
−0.5V to V
CC
+ 0.5V
−20 mA
+20 mA
−0.5V to V
CC
+ 0.5V
Recommended Operating
Conditions
Supply Voltage (V
CC
)
’AC
’ACT
Input Voltage (V
I
)
Output Voltage (V
O
)
Operating Temperature (T
A
)
54AC/ACT
Minimum Input Edge Rate (∆V/∆t)
’AC Devices
V
IN
from 30% to 70% of V
CC
V
CC
@
3.3V, 4.5V, 5.5V
Minimum Input Edge Rate (∆V/∆t)
’ACT Devices
V
IN
from 0.8V to 2.0V
V
CC
@
4.5V, 5.5V
2.0V to 6.0V
4.5V to 5.5V
0V to V
CC
0V to V
CC
−55˚C to +125˚C
125 mV/ns
±
50 mA
±
50 mA
−65˚C to +150˚C
175˚C
125 mV/ns
Note 1:
Absolute maximum ratings are those values beyond which damage
to the device may occur. The databook specifications should be met, without
exception, to ensure that the system design is reliable over its power supply,
temperature, and output/input loading variables. National does not recom-
mend operation of FACT
™
circuits outside databook specifications.
DC Characteristics for ’AC Family Devices
Symbol
Parameter
V
CC
(V)
V
IH
Minimum High Level
Input Voltage
V
IL
Maximum Low Level
Input Voltage
V
OH
Minimum High Level
Output Voltage
3.0
4.5
5.5
3.0
4.5
5.5
3.0
4.5
5.5
54AC
T
A
=
−55˚C to +125˚C
Guaranteed Limits
2.1
3.15
3.85
0.9
1.35
1.65
2.9
4.4
5.4
(Note 2)
V
IN
= V
IL
or V
IH
3.0
4.5
5.5
V
OL
Maximum Low Level
Output Voltage
3.0
4.5
5.5
2.4
3.7
4.7
0.1
0.1
0.1
(Note 2)
V
IN
= V
IL
or V
IH
3.0
4.5
5.5
I
IN
I
OLD
I
OHD
I
CC
Maximum Input
Leakage Current
Minimum Dynamic
Output Current (Note 3)
Maximum Quiescent
5.5
5.5
5.5
5
Units
Conditions
V
OUT
= 0.1V
V
or V
CC
− 0.1V
V
OUT
= 0.1V
V
or V
CC
− 0.1V
I
OUT
= −50 µA
V
I
OH
= −12 mA
V
I
OH
= −24 mA
I
OH
= −24 mA
I
OUT
= 50 µA
V
0.5
0.5
0.5
V
µA
mA
mA
µA
I
OL
= 12 mA
I
OL
= 24 mA
I
OL
= 24 mA
V
I
= V
CC
, GND
V
OLD
= 1.65V Max
V
OHD
= 3.85V Min
V
IN
= V
CC
www.national.com
5.5
±
1.0
50
−50
160
