DMP2004TK-7: DescriptionDrain-source voltage (Vdss): 20V Continuous drain current (Id) (at 25°C): 430mA Gate-source threshold voltage: 1V @ 250uA Drain-source on-resistance: 1.1Ω @ 430mA, 4.5V Maximum power dissipation ( Ta=25°C): 150mW Type: P-channel; CategoryDiscrete semiconductor MOS (field effect tube); File Size389KB，6 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric View All

DMP2004TK-7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DMP2004TK-7	-	-	View	Buy Now

DMP2004TK-7 Overview

Drain-source voltage (Vdss): 20V Continuous drain current (Id) (at 25°C): 430mA Gate-source threshold voltage: 1V @ 250uA Drain-source on-resistance: 1.1Ω @ 430mA, 4.5V Maximum power dissipation ( Ta=25°C): 150mW Type: P-channel

DMP2004TK-7 Parametric

Parameter Name	Attribute value
Drain-source voltage (Vdss)	20V
Continuous drain current (Id) at 25°C	430mA
Gate-source threshold voltage	1V @ 250uA
Drain-source on-resistance	1.1Ω @ 430mA,4.5V
Maximum power dissipation (Ta=25°C)	150mW
type	P channel

Preview

Download Datasheet

View All

DMP2004TK

P-CHANNEL ENHANCEMENT MODE MOSFET

Features



Low On-Resistance

Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

ESD Protected Gate

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data



Case: SOT523

Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish



Matte Tin Annealed over Alloy 42

leadframe. Solderable per MIL-STD-202, Method 208

Terminal Connections: See Diagram

Weight: 0.002 grams (Approximate)

SOT523

ESD PROTECTED

Gate Protection

Diode

Top View

Equivalent Circuit

Ordering Information

(Note 4)

Part Number

DMP2004TK-7

Notes:

Case

SOT523

Packaging

3,000/Tape & Reel

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.

2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and

Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website

https://www.diodes.com/design/support/packaging/diodes-packaging/.

Marking Information

PAB

PAB = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: F = 2018)

M = Month (ex: 9 = September)

Date Code Key

Year

2006

Code

Month

Code

Jan

2007

Feb

…

Mar

2014

Apr

2015

May

2016

Jun

2017

Jul

2018

Aug

2019

Sep

2020

Oct

2021

Nov

2022

Dec

DMP2004TK

Document number: DS30932 Rev. 7 - 2

1 of 6

www.diodes.com

October 2018
